- Page 1 HPSBB 0412 13.8V/4A/7Ah v.1.0 Buffer, switching power supply unit. Edition: 1’st from 31th of December 2010 Supercedes edition: -------------...
-
Page 2: Table Of Contents
Features of the power supply unit: Uninterruptible power supply 9.5÷ 13.8V DC Protections: • • Controlling of battery charging and maintaining SCP short-circuit protection • • Protecting of battery against excessive OVP overvoltage protection • • discharging (UVP) Surge protection •... -
Page 3: Block Diagram
1.2. Block diagram (fig.1). Fig.1. The block diagram of the power-supply. 1.3. Description of elements and power-supply connectors ( tab.1, tab.2, fig.2). Element no. Description [Fig. 2] Power supply module Power supply connectors (see: tab.2) Green LED indicates DC voltage at the power-supply output Potentiometer, adjustment of the output voltage BAT+/GND: battery outputs +BAT=red, - BAT=black TAMPER, contact of antisabotage protection (NC) - Page 4 Fig.2. The view of the power supply.
-
Page 5: Technical Parameters
1.4. Technical parameters: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operation parameters (tab.6) (tab. 3) Electrical parameters Supply voltage 85÷264V AC; 50÷60Hz, 120÷370V DC Power frequency 50÷60Hz lub DC Supply power P 55W max. Current consumption 0.5A@230VAC max. -
Page 6: Installation
(tab.6) Operation parameters Operation temperature -10ºC...+40ºC (see: chart 1) Storage temperature +5ºC...+40ºC Relative humidity 30%...90%, without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insolation unacceptable Vibrations and impulse waves during transport According to PN-83/T-42106 Chart 1. Allowable output current from the power supply depending on ambient temperature. 2. -
Page 7: Overload Or Short Circuit Of The Power Supply Output (Scp Operation)
The circuit of the shock protection shall be performed with a particular care, i.e. the yellow and green protection wire of the power cable shall be connected from one side to the terminal marked by the symbol of in the casing of the power-supply. Operation of the power-supply without the properly made and fully operational circuit of the shock protection is UNACCEPTABLE! It can result in failure of devices and electric shock. - Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (manufacturer) grants a two-year quality warranty for the equipment, starting from the date of purchase placed on the purchase order. 2. Should such purchase order be missing when the claim is submitted, the three-year guarantee period is counted from the date of the manufacturing of the device.
