- Page 1 MSRK 1512 v.2.1 MSRK 13,8V/1A Buffer switch mode power supply module Edition: 4 from 16.09.2013 Supersedes the edition: 3 from 16.12.2011...
- Page 2 MSRK1512 Features: DC 13,8V/1A uninterruptible power supply LED indication FAC indication of the AC power collapse high efficiency 78% adjustable times indicating AC power failure battery charging and maintenance control protections: excessive discharging (UVP) protection ...
- Page 3 MSRK1512 1.3. Description of components and connectors Table 1. Elements of the PSU module pcb (fig. 2). Element no. Description ; pins - configuration of UVP battery protection function protection (disconnection) of the battery off protection (disconnection) of the battery on ;...
- Page 4 MSRK1512 Electrical parameters (tab. 3). Mains supply 18V÷22V AC 30VA min. (np. AWT150) Current up to 1,8 A Power frequency 50Hz Power 34 W Efficiency Output voltage 11,0 V÷ 13,8 V DC – buffer operation 10,0 V÷ 13,8 V DC – battery-assisted operation...
- Page 5 MSRK1512 The device should be installed in the metallic enclosure (cabinet). In order to meet the UE requirements, the rules concerning: supply, development and shielding ought to be followed- accordingly to the application. The module requires 20-22V AC power supply with galvanic separation (transformer insulation).
- Page 6 THE GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a five-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
