Item #1001 748 139
Model # FCS60680-ST
USE AND CARE GUIDE
NORWICH 4PC DEEP SEATING SET - CHAIR
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY NORWICH FCS60680-ST
Summary of Contents for HAMPTON BAY NORWICH FCS60680-ST
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
- Page 2 Table of Contents Table of Contents........2 Pre-Assembly.
-
Page 3: Warranty
Warranty 3 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED Its remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Hardware Included
Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6x15 Combination Bolt 16 + 1 M6x30 Combination Bolt Hex Wrench PACKAGE CONTENTS Part Description Quantity Bucket Rear Leg Left Connection Bar Right Connection Bar... - Page 5 Assembly Attaching the Rear Leg to the Bucket Place the bucket (A) on a soft surface. Attach the rear leg (B) to the bucket (A) using M6x30 combination bolts (BB). Do not tighten the bolts at this step. NOTE: Loosely tighten all the bolts using hex wrench (CC). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 6 Assembly (continued) Attaching the Left Connection Bar to the Bucket and Rear Leg Attach the left connection bar (C) to the bucket (A) and rear leg (B) using M6x15 combination bolts (AA). Do not tighten the bolts at this step. NOTE: Loosely tighten all the bolts using hex wrench (CC).
- Page 7 Assembly (continued) Attaching the Right Connection Bar to the Bucket and Rear Leg Attach the right connection bar (D) to the bucket (A) and rear leg (B) using M6x15 combination bolts (AA). Do not tighten the bolts at this step. NOTE: Loosely tighten all the bolts using hex wrench (CC).
-
Page 8: Care And Cleaning
Assembly (continued) Checking the Chair Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (CC). Turn the chair right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
-
Page 10: Important Safety Instructions
ITEM #1001 748 139 MODEL #FCS60680-ST Norwich 4pc Deep Seating - Table Use and Care Guide Important Safety Instructions SAVE THESE INSTRUCTIONS This table was made for the explicit purpose of providing outdoor functions and is not to be used as a toy. WARNING: This product is intended for normal outdoor use;... -
Page 11: Year Frame Limited Warranty
Warranty 3 YEAR FRAME LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three years. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover commercial use, hardware, acts of nature, re, freezing and abusive use.
