Item #1005 045 398
Model #FCS60637-ST
USE AND CARE GUIDE
HARMONY COVE 4PC SLING DEEP SEATING SET - BLUE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and co
e you have placed in Hampton Bay through the purchase of this set. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY FCS60637-ST
Summary of Contents for HAMPTON BAY FCS60637-ST
- Page 1 We appreciate the trust and co e you have placed in Hampton Bay through the purchase of this set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of contents ..............2 Pre-assembly ................3 Planning assembly ..............3 Important Safety Instructions ........Hardware included ..............3 Save These Instructions ............2 Chair Package contents ............4 Read All Instructions Before Use ..........Table Package contents ............5 Warranty ................ -
Page 3: Warranty
Warranty 3 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and a two year limited w arranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Chair Package Contents
Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Quantity Part Description Right leg Left leg Chair Seat Chair Back... - Page 5 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Quantity Part Description Table top Table leg...
-
Page 6: Loveseat Package Contents
Pre-Assembly (continued) LOVESEAT PACKAGE CONTENTS Quantity Part Description Right leg Left leg Loveseat Seat Loveseat Back... -
Page 7: Chair Assembly
Chair Assembly ATTACH THE CHAIR SEAT TO THE CHAIR BACK Place the chair back (D) upside down on a soft surface. Attach the chair seat (C) to the chair back (D) using M6x20 combination bolts (AA). NOTE : Loosely tighten the bolts using the hex wrench (CC). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 8 Chair Assembly (continued) ATTACH THE RIGHT ARM TO THE CHAIR SEAT AND CHAIR BACK Attached the right arm (A) to the chair seat (C) and chair back (D) using M6x20 combination bolts (AA). NOTE : Loosely tighten the bolts using the hex wrench (CC).
- Page 9 Chair Assembly (continued) ATTACH THE LEFT ARM TO THE CHAIR SEAT AND CHAIR BACK Attach the left arm (B) to the chair seat (C) and chair back (D) using M6x20 combination bolts (AA). NOTE : Loosely tighten the bolts using the hex wrench (CC). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 10 Chair Assembly (continued) TIGHTEN ALL BOLTS Once all of the bolts are in place, fully tighten all the bolts using hex wrench (CC). Turn the table right side up. Ensure all connections are secure before use.
- Page 11 Table Assembly CONNECTING THE TABLE LEG TO THE TABLE TOP Place the table top (G) upside down on a soft surface. Attach the table legs (H) to the table top (G) using M8x50 combination bolts (BB). NOTE : Loosely tighten the bolts using the wrench (DD). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Table Assembly (continued) TIGHTENING ALL BOLTS Once all of the bolts are in place, fully tighten all the bolts using wrench (DD). Turn the table right side up. Ensure all connections are secure before use.
-
Page 13: Loveseat Assembly
Loveseat Assembly ATTACH THE LOVESEAT SEAT TO THE LOVESEAT BACK Place the loveseat back (F) upside down on a soft surface. Attach the loveseat seat (E) to the loveseat back (F) using M6x20 combination bolts (AA). NOTE : Loosely tighten the bolts using the hex wrench (CC). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 14 Loveseat Assembly (continued) ATTACH THE RIGHT ARM TO THE LOVESEAT SEAT AND LOVESEAT BACK Attach the right arm (A) to the loveseat seat (E) and loveseat back (F) using M6x20 combination bolts (AA). NOTE : Loosely tighten the bolts using the hex wrench (CC).
- Page 15 Loveseat Assembly (continued) ATTACH THE LEFT ARM TO THE LOVESEAT SEAT AND LOVESEAT BACK Attach the left arm (B) to the loveseat seat (E) and loveseat back (F) using M6x20 combination bolts (AA). NOTE : Loosely tighten the bolts using the hex wrench (CC). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 16: Care And Cleaning
Loveseat Assembly (continued) TIGHTEN ALL BOLTS Once all of the bolts are in place, fully tighten all the bolts using hex wrench (CC). Turn the loveseat chair right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame with a damp cloth and dry thoroughly. - Page 17 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. Factory chair ID # FCS60637...
