Item #1004 441 320
Model #FCS60610R-ST
USE AND CARE GUIDE
CRESTRIDGE 7PC DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY CRESTRIDGE FCS60610R-ST
Summary of Contents for HAMPTON BAY CRESTRIDGE FCS60610R-ST
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Table of Contents........2 Pre-Assembly. -
Page 3: Warranty
Warranty 2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Hardware Included
Pre-assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6x15 Combination Bolt 38+2 M6x30 Combination Bolt 36+1 M6x25 Bolt 12+1 M6x25 Combination Bolt Hex Wrench CHAIR PACKAGE CONTENTS Part Description Quantity Sling Bucket Right Arm Left Arm Connector Bar Support Bar... - Page 5 Pre-assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table Rim Table Leg Support Tube Leg Connector Tile HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 6: Chair Assembly
Chair Assembly Connecting The Sling Bucket, Connector Bar And Support Bar To The Right Arm Place the right arm (B) on a soft surface. Attach the sling bucket (A) to the right arm (B) using M6x30 combination bolts (BB). Attach the connector bar (D) to the right arm (B) using M6x15 combination bolts (AA). - Page 7 Chair Assembly (continued) Securing The Support Bar Turn the chair right side up. Tighten the support bar (E) to the two chair arms (B & C) using M6x25 bolts (CC). Do not tighten all bolts at this step. Tightening All Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (EE).
- Page 8 Table Assembly Attaching The Table Legs And The Support Tubes To The Table Rim Place the table rim (F) upside down on a soft surface. Attach the table legs (G) and support tubes (H) to the table rim (F) using M6x15 combination bolts (AA). Do not tighten all bolts at this step.
-
Page 9: Care And Cleaning
Table Assembly (continued) Tightening All Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (EE). Turn the table right side up and carefully place the tiles (J) into the table rim (F). Ensure all connections are secure before use. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. For certification use only...
