Item #0000 000 000
Model #FRS71051R-ST
USE AND CARE GUIDE
WILLENDALE STEEL WICKER 3PC DEEP SEATING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive to continually create
quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WILLENDALE FRS71051R-ST and is the answer not in the manual?

Questions and answers

Related Manuals for HAMPTON BAY WILLENDALE FRS71051R-ST

Summary of Contents for HAMPTON BAY WILLENDALE FRS71051R-ST

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive to continually create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents........2 Pre-Assembly.

  • Page 3: Warranty

    Warranty 3 YEAR FRAME WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three years. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive use.

  • Page 4: Chair Package Contents

    Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Chair Bucket Right Arm Left Arm Connection Bar...
  • Page 5 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table Top Leg Connector Table Leg HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.

  • Page 6: Chair Assembly

    Chair Assembly Connecting the Chair Bucket and the Connection Bar to the Right Arm Place the right arm (B) on a soft surface. Attach the chair bucket (A) and the connection bar (D) to the right arm (B) using M6x15 combination bolts (AA). Do not tighten all bolts at this step.
  • Page 7 Chair Assembly (continued) Connecting the Chair Bucket and the Connection Bar to the Left Arm Place the left arm (C) on a soft surface. Attach the chair bucket (A) and the connection bar (D) to the left arm (C) using M6x15 combination bolts (AA). Do not tighten all bolts at this step.
  • Page 8 Chair Assembly (continued) Connecting the Chair Bucket to the Left Arm and the Right Arm Turn the chair right side up. Attach the chair bucket (A) to the left arm (C) and the right arm (B) using M6x15 combination bolts (AA). Do not tighten all bolts at this step.
  • Page 9 Chair Assembly (continued) Tightening All Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (BB). Ensure all connections are secure before use. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 10 Table Assembly Connecting the Table Legs to the Table Top Place the table top (E) upside down on a soft surface. Attach the table legs (G) to the table top (E) using M6x15 combination bolts (AA). Do not tighten all bolts at this step. NOTE: Loosley tighten all the bolts using hex wrench (BB).
  • Page 11 Table Assembly (continued) Connecting the Leg Connector to the Table Legs Attach the leg connector (F) to the table legs (G) using M6x15 combination bolts (AA). Do not tighten all bolts at this step. NOTE: Loosley tighten all the bolts using hex wrench (BB). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.

  • Page 12: Care And Cleaning

    Table Assembly (continued) Tightening All Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (BB). Turn the table right side up. Ensure all connections are secure before use. Care Care and Cleaning For best results, clean the frame with a damp cloth and dry thoroughly.
  • Page 13 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
