USE AND CARE GUIDE
TACANA 7-PIECE WOVEN DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TACANA FRS50421H-ST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HAMPTON BAY TACANA FRS50421H-ST

  • Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Chair Package Contents ............4 Table Package Contents ............5 Warranty ................
  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
  • Page 4: Chair Package Contents

    Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Backrest Right arm Left arm Seat Pillow Seat cushion HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 5 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table top Table leg Long bolt Umbrella ring HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 6: Chair Assembly

    Chair Assembly Connecting the seat to the backrest Place the backrest on a soft surface. Connect the seat (D) to the backrest (A) using M6x30 combination bolts (AA) and the hex wrench (EE). Do not fully tighten all the bolts at this step.
  • Page 7 Chair Assembly (continued) Connecting the left arm to the backrest Attach the left arm (C) to the backrest (A) by inserting the tube on the left arm (C) into the tube on the backrest (A). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 8 Chair Assembly (continued) Connecting the left arm to the seat and the backrest Attach the left arm (C) to the seat (D) and the backrest (A) using M6x25 combination bolts (BB). Do not fully tighten all the bolts at this step. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 9 Chair Assembly (continued) Connecting the right arm to the backrest Repeat step 2 to attach the right arm (B) to the backrest (A). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 10 Chair Assembly (continued) Connecting the right arm to the seat and the backrest Attach the right arm (C) to the seat (D) and the backrest (A) using M6x25 combination bolts (BB). Do not fully tighten all the bolts at this step.
  • Page 11 Chair Assembly (continued) Tightening the bolts Once all of the bolts are in place, fully tighten the bolts using the hex wrench (EE). Turn the chair right side up. Ensure all connections are secure before use. Place the seat cushion (F) and the lumbar pillow (E) to complete the assembly of the chair. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 12 Table Assembly Attaching the table leg to the table top Place the table top (G) upside down on a soft place Place the table legs (H) correctly on the corner of the table top (G). Attach the table legs (H) to the table top (G) using M8x90 hex combination bolts (CC), metal sheets (J) and the wrench (FF). Do not fully tighten all the bolts at this step NOTE: Make sure to place metal sheets (J) before inserting M8x90 hex combination bolts (CC).
  • Page 13 Table Assembly (continued) Removing the adjustable feet from the table legs Remove the adjustable feet (K) from the table legs (H) by rotating in the counterclockwise direction. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 14 Table Assembly (continued) Inserting the long bolts into the table legs and the table top Insert the long bolts (I) through the M10 washers (DD) and into the table legs (H). Attach the long bolts (I) to the table top (G) using the wrench (FF). NOTE: Loosely tighten all long bolts (I) using wrench (FF).
  • Page 15 Table Assembly (continued) Tightening the bolts and attaching the adjustable feet to the table legs Once all the bolts are in place, fully tighten all the bolts with the wrench (FF). Attach the adjustable feet (K) to the table legs (H) by rotating in the clockwise direction. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 16: Care And Cleaning

    Table Assembly (continued) Checking the table Turn the table right side up. Place the umbrella cover (M) to the table top (G). Ensure all connections are secure before use. Care and Cleaning □ For best results, clean the frame with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 17 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
