Pulsar PSD 15V/4A Quick Start Manual

power output 4A/15VDC

universal AC input voltage range 90÷264V

 high efficiency 87%
 LED optical signalisation
standby power <0,3W

1. Technical description.
1.1. General description.
Stabilized DC power supply is intended for supply cameras that require stabilised voltage of 15V DC. The unit has a cable
with a DC5.5/2.1 plug. When connected to fuse blocks of the LB4/xx/xx or LB8/xx/xx family, the power supply unit can feed more
equipments (max. 4 or 8). The power supply unit is protected against short-circuit, overload and overvoltage.
1.2. Specifications.
Supply voltage
Current consumption
Supply power
Efficiency
Output voltage
Output current t
AMB
Output current t
AMB
Ripple voltage
Short-circuit protection SCP
Overload protection OLP
Optical signalisation
Operation conditions
Dimensions (LxWxH)
Net/gross weight
Protection class PN-EN 60950-1:2007
Lenght of DC cable
Lenght of AC cable
Storage temperature
* In order to extend the life of the power supply, the load current of 2,8A is recommended.
Graph 1.
Relation between output current and ambient
temperature (instantaneous load).
*
Refer to graph 1
PSD 15V/4A switch mode power supply desktop
Features of the power supply unit:
*
<30°C
=40°C
PSD15040
Edition: 5 from 01.04.2014
Supersedes edition: 4 from 10.03.2014
 efficiency level: V
 protections:
SCP short-circuit protection

overvoltage protection (AC input)

overload (OLP)

 warranty – 2 year from the production date
90 ÷ 264V AC 50÷60Hz
0,55A@230V AC max.
60W max.
87%
15V DC
4A - refer to graph 1.
2,8A - refer to graph 1.
100mV p-p max.
electronic, automatic recovery
150-200% of power supply, automatic recovery
LED – presence of DC voltage
o o
temperature -10 C÷40 C
relative humidity 20%...90%, without condensation
116 x 54 (80) x 35 [mm]
0,29kg / 0,34kg
II (second)
1,45m + plug DC5,5/2,1 female
1,15m + mains plug
-20ºC...+60ºC
Fig.1. Dimension of power supply.
