U-Line 3M PROTECTA H-11083 Instructions

H-11083, H-11084
3M PROTECTA
HOW TO DON A HARNESS
1. Holding harness by back D-ring, ensure straps are unbuckled
and untwisted. (See Figure 1)
2. Slip straps over shoulders so back D-ring is located between
shoulder blades. (See Figure 2)
3. Pull leg straps between legs and buckle to corresponding
ends. Tighten leg straps until snug. (See Figure 3)
NOTE: Leg straps should not be too snug as to obstruct
blood circulation in legs.
4. Buckle chest strap so that it is positioned in mid-chest area.
If adjustable, tighten until snug. (See Figure 4)
NOTE: Chest strap should be 6-8" below the trachea,
but not below the sternum.
5. After buckling all straps, readjust harness fit as needed.
Secure excess strap in elastic loop keepers.
HARNESS CARE
When not in use, hang harness by back D-ring in order to
maintain shape.
NOTE: This chart serves only as a guideline
for harness sizing.
PAGE 1 OF 3
®
HARNESSES
1-800-295-5510
uline.com
INSTRUCTIONS
Figure 1
Figure 3
SIZING CHART
6'8"
6'6"
6'4"
6'2"
6'0"
5'10"
5'8"
SM
5'6"
5'4"
5'2"
5'0"
4'10"
Para Español, vea página 2.
Pour le français, consulter la page 3.
Figure 2
Figure 4
XXL
XL
MED / LG
Weight – Lbs.
0824 IH-11083
D-Ring
