H-6289
SAFETY BOLLARD
CHAIN
TOOL NEEDED
Electric Drill
(Screw Gun)
Mounting Plate x 2
1. Attach mounting plate to bollard using provided
self-tapping screws and nut driver. (See Figure 1)
NOTE: Use a screw gun with an adjustable clutch.
Take care not to overtighten and strip the
threads. DO NOT USE IMPACT TYPE GUNS.
Figure 1
2. Repeat step 1 on second bollard.
PAGE 1 OF 3
1-800-295-5510
uline.com
PARTS
Carabiner x 2
INSTALLATION
Self-Tapping Screw x 8
3. Attach carabiners to mounting plates on both
bollards. (See Figure 2)
Figure 2
4. Connect chain to carabiners. (See Figure 3)
Figure 3
Para Español, vea página 2.
Pour le français, consulter la page 3.
10' Chain
0521 IH-6289
