Instructional Leafl et IL03901003E
DS7 series soft start controllers,
Frame 1 (4–12A)
Effective January 2011
Introduction
Eaton's DS7 solid-state soft start controller is an
electronic, self-contained panel- or enclosure-
mounted motor soft-starting device. It provides
three-phase induction motors with a smooth start,
both mechanically and electrically. The DS7 line
uses four silicon-controlled rectifiers (SCRs) that
are connected in a full wave-power bridge on two
phases. The voltage and current applied to the
motor are controlled by varying the SCR conduc-
tion period. This, in turn, controls the torque devel-
oped by the motor. After the motor reaches speed,
a bypass relay is energized to bypass the SCRs.
The DS7 is designed to fulfill the industrial service
requirements of applications such as chiller start-
ers, pump panels, and machine tools. This device
meets all relevant specifications set forth by UL
508, IEC 60947-4-2, CE, C-Tick, and CSA .
This leaflet covers basic installation and setup. No
publication can take into account every possible
situation. If you require further assistance with any
aspect of this product or a particular application,
contact Eaton.
Inspection
General
Upon receipt of the unit, verify that the catalog
number and unit options stated on the shipping
container match those stated on the order/
purchase form.
Inspect the equipment upon delivery. Report any
carton damage to the carrier prior to accepting the
delivery. Have this information noted on the freight
bill. Eaton is not responsible for damage incurred
in shipping.
Unpacking
Remove all packing material from the unit. Be
sure to remove all packing material from the
lug location.
Check the unit for any signs of shipping damage.
If damage to the product is found after unpacking,
report it to the freight company. Retain the packing
materials for the carrier to review.
Verify that the unit's catalog number and options
match those stated on the order/purchase form.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS7-342SX004N0-N and is the answer not in the manual?

Questions and answers

Summary of Contents for Eaton DS7-342SX004N0-N

  • Page 1 Effective January 2011 DS7 series soft start controllers, Frame 1 (4–12A) Introduction Eaton’s DS7 solid-state soft start controller is an electronic, self-contained panel- or enclosure- mounted motor soft-starting device. It provides three-phase induction motors with a smooth start, both mechanically and electrically. The DS7 line...
  • Page 2: Mounting Instructions

    Requirements Lbs (kg) 10 lb-in (1.2 Nm) 0.8 (0.35) DANGER HAZARDOUS VOLTAGE. WILL CAUSE DEATH OR SERIOUS INJURY. HAZARDOUS VOLTAGE IS PRESENT IN THE OFF/STOP STATUS OF THE SOFT START CONTROLLER WHEN THE LINE VOLTAGE IS ENERGIZED. EATON CORPORATION www.eaton.com...
  • Page 3 XTPAXTPCB DS7-340SX012NO-N DS7-342SX012NO-N Notes Actual motor FLAs vary. Verify these devices cover the motor specific FLA. Selections are based on motor FLA value at 480V. Not to be used with 230V. 24 Vac/Vdc device. 120/230 Vac device. EATON CORPORATION www.eaton.com...
  • Page 4: Control Wiring

    30 mA (with optional fan) 24 Vac/Vdc, 110/230 Vdc • (–) U 100 mA (with optional fan, in bypass) • Figure 4. Direct start control wiring with soft stop Peak current requirement = 250 mA for 50 ms • EATON CORPORATION www.eaton.com...
  • Page 5 — — Feed screw — 175% Possible high starting torque Press, flywheel — 150% Possible high starting torque Drier, rotating — 100% — Blower, axial fan, flaps open — — Blower, centrifugal fan, valve open — — EATON CORPORATION www.eaton.com...
  • Page 6 Note: After a successful START ramp, the bypass relays close and the soft start controller is in a RUN condition. TOR will remain illuminated until RUN command is removed for coast stop or STOP ramp. Auxiliary relay contacts will change state at the same time as the TOR LED. EATON CORPORATION www.eaton.com...
  • Page 7 Correct excessive voltage drop condition. simultaneous Verify the CPT is sized correctly and output voltage is correct. Note: Inspect supply voltage for proper level and stability. Verify that CPT is of sufficient capacity and that it is operating properly. EATON CORPORATION www.eaton.com...
  • Page 8 Technical Resource Center at (877) 386-2273 or visit our Web site at www.eaton.com. Service and repair is available from Eaton or several factory authorized regional service centers. Please contact Eaton’s Product Integrity Center at (800) 345-0434 for the location nearest to you.
