Follow the assembly steps in this P&P Guide. Note: The solder diameter must match the ALE model purchased. Make sure the solder wire diameter is compatible with the wheels Soldering Iron already installed in the ALE control unit.
para manuales - negro plano 200 mm Step 2 Reel Locking Assembly 130 mm 130 mm To assemble the reel locking, its conical side must be pointing downwards (1). Make sure that the reel locking screw is slightly backed out and does not collide with the axis (2).
Step 4 Guide Set Assembly Guide Tube Loosen the guide tube set screw (oppo- Set Screw site direction to that indicated on the tool casing) (1) and insert the guide set. ALE250 Adjust the guide tube length (2). Leave a gap ALE250 of 5 to 7 mm (0.197 to 0.276 in) between the 5-7 mm...
Speed Minimum temp Length 12.0mm º Sleep delay 0min Working hrs Guide kits for different wire diameters are available at JBC’s Off Feeder parameters lock Off Sleep temp º Feeder parameters lock Sleep hrs web site, accessible via this QR code.
Page 8
Step 8 Solder Wire Loading Solder Wire Wheels Guidance Make sure that the solder wire passes through the solder wire guidance (1). Introduce the solder wire into the inlet nozzle (2) until it reaches the wheels (3). Inlet Nozzle Tin reload process Select “Tin Reloaded Process”...
Choose between “continuous”, “discontinuous” and “program” Counters Wire clogging detection mode. Access to Main Menu by pressing , select “Feeder Settings” (1) and then “Mode” (2). For more details see ALE control Language Back Unit Manual or JBC Web www.jbctools.com/auto-feed-stations. Reset...
Ø 1.14 - 1.27 mm / Ø 0.040 in Ø 0.018 - 0.022 in Ø 0.045 - 0.051 in Ref. ALE-910VB (100 V) * Ref. ALE-905B (100 V) Ref. ALE-912B (100 V) * Available to order on the JBC Web site.
