- Page 1 ENZHEN CH HAINWAY I INFORMAT TION TECH NOLOGY C CO.,LTD obile Data a Te mina al C66 U User M Manua...
-
Page 2: Table Of Contents
Content Content ................... 1 Statement ................... 3 Chapter 1 Product intro ..............4 Intro ..................4 Precaution before using battery ........... 5 Charger ................6 Notes ..................7 Chapter 2 Installation instructions ............8 2.1 Appearance................8 2.2 Install Micro SD and SIM cards ..........9 2.3 Battery charge................. - Page 3 6.6 Keyboard ................21 6.7 Network ................... 22 6.8 Keyboard emulator ..............23 Chapter 7 Device characteristic ............24 Appendix ..................26 Restrictions: .................. 26 Simplified EU declaration of conformity ........27 Statement..................28...
-
Page 4: Statement
(licensed program). Except as noted below, such license may not be assigned, sublicensed, or otherwise transferred by the user without prior written consent of Chainway. No right to copy a licensed program in whole or in part is granted, except as permitted under copyright law. -
Page 5: Chapter 1 Product Intro
Chapter 1 Product intro 1.1 Intro C66 is an industrial-grade smart handheld terminal that has been designed and manufactured by Shenzhen chainway information technology co, ltd .It is based on Android 7.1, which runs fast and has a long battery life. To meet the needs of multi-industry applications like logistics express, warehouse inventory, manufacturing, retail, etc.,... -
Page 6: Precaution Before Using Battery
1.2 Precaution before using battery Do not leave battery unused for long time, no matter it is in device or inventory. If battery has been used for 6 months already, it should be check for charging function or it should be disposed correctly. -
Page 7: Charger
1.3 Charger The charger type is GME10D-050200FGu, output voltage/current is 5V DC/2A. The plug considered as disconnect device of adapter. -
Page 8: Notes
1.4 Notes Note: Using the incorrect type battery has danger of explosion. Please dispose the used battery according to instructions. Note: Due to the used enclosure material, the product shall only be connected to a USBInterface of version 2.0 or higher. Theconnection to so called power USB is prohibited. -
Page 9: Chapter 2 Installation Instructions
hapte er 2 In nstalla ation i instru uction 1 App pearan 6 back a nd front a appearan nces are s showing as follow... -
Page 10: Install Micro Sd And Sim Cards
Buttons instruction Button Description 1.Power Located on right side, press to ON/OFF device. Side Located on right side, its function can be defined by software. 2. PTT key button Scanning button located on both sides. There are two scanning 3.SCAN buttons. -
Page 11: Battery Charge
2.3 Battery charge By using USB Type-C contact, the original adaptor should be used for charging the device. Make sure not to use other adaptors to charge the device. -
Page 12: Buttons And Function Area Display
4 Butt tons a nd fun nction n area displa 6 has 6 s side butto ons, NFC C identifica ation area a and 2D D scannin odule loca ates on th he top. H D camera a and flas shlight lo cate at re ear. -
Page 13: Chapter 3 Call Function
Chapter 3 Call function 3.1 Calling numbers 1. Click icon 2. Click number key to input phone numbers. 3. Click icon to call. 4. Click icon to end call. 3.2 Contacts 1. Click contacts to open contacts list. 2. Click icon to add new contacts. -
Page 14: Chapter 4 Barcode Reader-Writer
Chapter 4 Barcode reader-writer 1. In App Center, to open 2D barcode scan test. 2. Press “SCAN” button or click scan key to start scanning, the parameter “Auto interval” can be adjusted. Caution: Please scan codes in correct way otherwise the scanning will be failed. - Page 15 Max. radiant power: 0.6mW Wave length: 655nM IEC 60825-1 (Ed.2.0). 21CFR 1040.10 and 1040.11 standard.
-
Page 16: Chapter 5 Rfid Reader
Chapter 5 RFID reader 5.1 NFC Click App Center, open “NFC” to read and write tag information. -
Page 17: Chapter 6 Other Functions
Chapter 6 Other functions 6.1 PING tool 1. Open “PING” in App Center. 2. Setup PING parameter and select external/internal address. -
Page 18: Bluetooth
6.2 Bluetooth 1. Open “BT Printer” in App Center. 2. In the list of detected devices, click the device that you want to pair. 3. Select printer and click “Print” to start printing contents. -
Page 19: Gps
6.3 GPS 1. Click “GPS” in App Center to open GPS test. 2. Setup GPS parameters to access GPS information. -
Page 20: Volume Setup
6.4 Volume setup 1. Click “Volume” in App Center. 2. Setup volume by requirements. -
Page 21: Sensor
6.5 Sensor 1. Click “Sensor” in App Center. 2. Setup the sensor by requirements. -
Page 22: Keyboard
6.6 Keyboard 1. Click “Keyboard” in App Center. 2. Setup and test the main value of the device. -
Page 23: Network
6.7 Network 1. Click “Network” in App Center. 2. Test WIFI/Mobile signal by requirements. -
Page 24: Keyboard Emulator
6.8 Keyboard emulator The keyboard emulator can be used in multiple operating background and output formats directly. And it includes Prefix/Suffix/Enter/TAB. Please check Keyboard emulator manual for more details. -
Page 25: Chapter 7 Device Characteristic
Chapter 7 Device characteristic Physical characteristics Size 160x76x15.5mm / 6.3*2.99*0.61in ＜260g/9.17oz Weight Display 5.45-inch display, IPS LTPS 1280*720 Touch panel 1 power key, 2 scan keys, 2 volume keys, 1 PTT Battery 4300mAh removable battery , support QC3.0 Expansion Supports up to 128 GB Micro SD card Expansion Slot 1 slot for SIM card, 1 slot for TF card Audio... - Page 26 2G: 850/1900MHz / CDMA EVDO: BC0 3G: 850/1900/MHz 4G: B2, B4, B5, B7, B17 WLAN Support 802.11 a/b/g/n/ac WPAN Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR Data collection Barcode SE4710 scanning RFID NFC 13.56Mhz Developing Environment Chainway software develop kit Language Java Develop Eclipse/Android Studio...
-
Page 27: Appendix
Appendix Restrictions: AT BE BG HR CY CZ DK EE FI FR DE GR HU IE LV LT LU MT NL PL PT RO SK SI ES SE UK This device is restricted to indoor use where operated in the European Community using frequency in 5150MHz-5350MHz to reduce the potential for interference. -
Page 28: Simplified Eu Declaration Of Conformity
Chainway y Informa ation Tech hnology C Co., Ltd clares tha at the rad dio equipm ment type e C66 is in compli ance with rective 20 014/53/EU U. The fu ll text of t the EU d eclaratio n of confo... -
Page 29: Statement
CE Statement Herby, Shenzhen Chainway Information Technology Co., Ltd. declares that this Mobile Data Terminal，C66 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. In accordance with Article 10(2) and Article 10(10), this product allow ed to be used in all EU member states. - Page 30 2422MHz~2462MHz (802.11n(HT40)) For BT/BLE: 2402MHz~2480MHz For GPS: 1.57542GHz For GSM: E-GSM900/GPRS900/EGPRS900: TX: 880MHz~915MHz; RX: 925MHz~960MHz GSM1800/GPRS1800/EGPRS1800: TX: 1710MHz~1785MHz; RX: 1805MHz~1880MHz For WCDMA: UTRA Band I: TX:1920MHz~1980MHz; RX: 2110MHz -2170MHz UTRA Band VIII: TX: 880MHz~915MHz; RX: 925MHz -960MHz LTE Band 1: (UL)1920MHz~1980MHz, (DL)2110MHz~2170MHz LTE Band 3: (UL)1710MHz~1785MHz, (DL)1805MHz~1880MHz...
- Page 31 LTE Band 8: 0.3491W LTE Band 20: 0.2799W LTE Band 38: 0.2529W LTE Band 40: 0.3524W Manufacturer：Shenzhen Chainway Information Technology Co., Ltd. Address：9/F, Building 2, Daqian Industrial Park, Longchang Rd., District 67, Bao'an, Shenzhen, China Tel: +86 755 23223301 Fax: +86 755 23223310 E-mail: liwenzhang@chainway.cn...
- Page 32 on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Page 33 phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure.
- Page 34 DECLARATION OF CONFORMITY I hereby declare that the product Product: Product Name: Mobile Data Terminal Model: C66 Brand Name: Hardware Version: C66_MB_B Software Version: C66_CNCommon_V1.00 Accessories： Adapter Information: Model: DBS15Q Input: AC 100-240V, 50/60Hz, 0.5A Output: DC 5V, 3A / 9V, 2A / 12V, 1.5A...
- Page 35 satisfies all the technical regulations applicable to the product within the scope of Council Directives 2014/53/EU, 2014/35/EU and 2014/30/EU:and declare that the same application has not been lodged with any other notified body. EN 60950-1: 2006+A11: 2009+A1: 2010+A12: 2011+A2: 2013 EN 62479:2010 EN 62209-1:2016 EN 62209-2:2010...
- Page 36 Number r: 2280 ANUFACTU URER or A AUTHORIS SED REPR RESENTAT TIVE: A Address: Shenzhen Chainway Informatio on Technol logy Co., L Ltd. 9/F, Build ing 2, Daq qian Indus strial Park , Longcha ang Rd., D District 67,...
