- Page 1 USER’S MANUAL PP60 pH PERISTLATIC PUMP FOR pH REGULATION www.asekopool.com...
-
Page 2: General Safety Information
General safety information This user manual contain basic information that should be observed during assembly, start-up, operation, and maintenance. Therefore, this user manual must be read by installers and operators prior to assembly and start/up, and must be accessible to every user of this unit. Additionally, all further safety information in this document absolutely must be observed. - Page 3 The chemicals used with the PP60 pH must be handled in a safe manner to prevent damage or personal harm. Aseko recommends you always use personal protective safety equipment when handling the pH and chlorine agents. Refer to the Materials Safety Data Sheet (MSDS).
-
Page 4: What's In The Box
What’s in the box pH probe Long Life #12012 Peristaltic pump #12117 pH probe Long Life Injecrion valve Suction tube weight #12023 #12012 #12005 Measuring Water Valve 2 pcs Dowels and screws PE Tube 1/4” (6.35 mm) transparent #12006 #12008... - Page 5 Accessories pH - Buffer 7,00 Photometer Glue head 1/4” #12134 #13076 #12065 ASEKO Pool Tester #12170 Original Aseko chemicals pH MINUS 20l pH MINUS 5l #12130 #12131 pH PLUS 20l pH PLUS 5l #12120 #12136...
-
Page 6: Technical Information
Peristaltic pump PP60 pH PP60 pH automatically regulates the pH value of the pool water, measured by a standard pH probe. The pH value is shown on the touch display. The touchscreen also serves to set all the necessary parameters. During operation, the required dose of the reagent is calculated from the measured value and the dose is then disposed into the pool water. -
Page 7: Probe Installation
Probe installation Carefully insert the pH probe into the housing. Hand tighten or use the attached plastic wrench socket for probes. Connect the connector and lock it by tightening a connector ring. After probes have been inserted, slightly tightened and connectors have been connected, PP60 pH is ready for connection to the water system of your pool. - Page 8 POOL WATER INLET Max pressure 1 Bar THE WATER OUTLET CAN BE Sampling point REALISED: for callibration Coagulation mixer 1. downstream of filtration 2. to the non-pressure (overflow tank) FROM POOL Besgo TO POOL Heating...
- Page 9 Pool Water Connection Measuring Water valve #12005 Screw the measuring water valve in the glue head D50 with thread G1/4 “#12134, glued to the T-piece. Tighten the measuring water valve into the head by hands only. Do not use pliers or other tools. Glue head D50 with thread 1/4“...
- Page 10 Max 8 m Max 8 m Sampling point Coagulation mixer for callibration FROM POOL Besgo TO POOL Heating...
- Page 11 Pool Chemicals Connection Plug with Screw the injection valve in the glue head D50 with thread G1 / 4 “ #12134, D = 50 with glued to the T-piece. Tighten the injection valve into the head by hands thread 1/4“ only.
- Page 12 Orientation in the menu When the mains cable is plugged in, the touch display of the device lights up. pH liquid type Required Value. Measured Value. By pressing this value enter the required pH value menu OFF - Dosing is turned OFF. Device status Enter the settings.
-
Page 13: Initial Setup
Initial setup PP60 pH is switched on by connecting to the power supply. Turn on the unit Select prefered language. Enter the settings and in the language menu select one of available languages. Test the connections tightness. In the settings menu, select Test dose. The display shows the dose in ml. -
Page 14: Ph Probe Calibration
In Operation Measurement and Calibration pH Probe Calibration Calibration is not possible When pH is being measured in operation, there may be a difference between when the new value differs the value measured by PP60 pH and the actual pH value in water. Proceed to by more than 1 from the the calibration. -
Page 15: Fuse Replacement
PP60 pH maintenance To ensure the optimum efficiency, perform visual checks and maintenance of PP60 pH on a regular basis. Pump Hose Replacement #12073 Replacement tube kit for PP 60 To prevent the pump from failing, it is recommended to replace the hose #12073 every 24 months. - Page 16 ERR – Error messages The measured value did not change after 15 doses of pH If this error pops up, check the following: 1. Agent Run Out • Check liquid levels on a regular basis, refill in time. 2. Dosing Pump does not Dose •...
- Page 17 ERR – Error messages The probe shows a pH> 10 Manually check the pH of the pool water and check the probe. The probe shows pH <4 Manually check the pH of the pool water and check the probe. Too rapid pH change Too rapid change of pH is usually caused by refilling water directly to the skimmer.
- Page 18 Winterizing - storage during winter The device and all accessories must be dismantled, winterized and moved to a suitable location. To disassemble and winterize the PP60 pH, follow the instructions below. Storing of pool chemicals, connecting PE tube and dosing pumps •...
- Page 20 USER’S MANUAL PP60 pH www.asekopool.com...
