SiT6092EB Evaluation Board User Manual
SiT6092EB Evaluation Board User Manual
Contents
1 Introduction ............................................................................................................................................. 1
2 I/O Descriptions ....................................................................................................................................... 2
3 EVB Usage Descriptions ........................................................................................................................... 2
3.1 EVB Configurations........................................................................................................................ 2
3.2 Waveform Capturing Using Active Probe ..................................................................................... 4
3.3 Measuring Jitter and Phase Noise ................................................................................................. 5
3.4 Current Measurement .................................................................................................................. 5
Appendix A .................................................................................................................................................... 6
1
Introduction
The SiT6092EB evaluation board (EVB) is designed for use with SiTime's VCXO in the 6-pin 7.0 x 5.0 mm
packages and LVCMOS output type.
The SiT6092EB supports the following products:
Base Part Number
SiT3807
SiT3808
SiT3809
SiT3907
EVB Features
- Support for all device configuration modes: VCXO, DCXO
- SMA output for direct connection to measurement equipment
- Probing points for accurate waveform measurement
SiTime typically ships the EVB with the VCXO/DCXO mounted using SiTime recommended reflow profile.
The device should only be evaluated in its original soldered down state for best signal integrity and
frequency stability. The device performance is not guaranteed if it is de-soldered and then re-soldered
either manually or via reflow process.
SiT6723EBB manual Rev 1.0
Type
VCXO 1.544 MHz - 49.152 MHz
VCXO
VCXO
DCXO
Page 1 of 10
Output frequency
1 MHz – 80 MHz
80 MHz – 220 MHz
1 MHz – 220 MHz
Package
7.0 x 5.0 mm
7.0 x 5.0 mm
7.0 x 5.0 mm
7.0 x 5.0 mm
www.sitime.com
