SiT6096EBB Evaluation Board User Manual
Contents
1 Introduction ............................................................................................................................................. 1
2 I/O Descriptions ....................................................................................................................................... 2
3 EVB Usage Descriptions ........................................................................................................................... 3
3.1 EVB Configurations........................................................................................................................ 3
3.2 DUT Power Supply Filter ............................................................................................................... 3
3.3 Buffered Clock Output .................................................................................................................. 4
3.4 Waveform Capturing Using Active Probe ..................................................................................... 4
3.5 Measuring Jitter ............................................................................................................................ 5
3.6 Current Measurement .................................................................................................................. 5
Appendix A .................................................................................................................................................... 6
1

Introduction

The SiT6096EBB evaluation board provides the ability to evaluate the functionality of the SiTime low-
frequency oscillators on a simple board that makes it easy to power up the oscillator and observe the
output buffered through an operational amplifier. The analog buffer isolates the device from the
significant loading, which is important for performing best waveform and current measurements.
The SiT6096EBB evaluation board supports 1 Hz to 32.768 kHz oscillators in a 2.0 x 1.2 mm x mm QFN
package including the following products:
Base Part Number
SiT1533
SiT1534
SiT1630
*SiT1534 is also available in a 1.5 x 0.8 WLCSP package. See
SiT6096EBB User Manual | Rev 2.0
Type
µPower Oscillator
µPower Oscillator
µPower Oscillator
SiT6098EBB
Page 1 of 9
Output frequency
32.768 kHz
1 Hz to 32.768 kHz
32.768 kHz or 16.384 kHz
for 1508 support.
Package
2.0 x 1.2 QFN
2.0 x 1.2 QFN*
2.0 x 1.2 QFN
www.sitime.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SiT6096EBB and is the answer not in the manual?

Questions and answers

Summary of Contents for SiTime SiT6096EBB

  • Page 1: Table Of Contents

    The analog buffer isolates the device from the significant loading, which is important for performing best waveform and current measurements. The SiT6096EBB evaluation board supports 1 Hz to 32.768 kHz oscillators in a 2.0 x 1.2 mm x mm QFN package including the following products:...
  • Page 2: O Descriptions

    The oscillator output is best observed using buffered output path through point the SMA connector J1. The buffer can be disconnected, and the output can be directly observed using test point. SiT6096EBB User Manual | Rev 2.0 Page 2 of 9 www.sitime.com...
  • Page 3: Evb Usage Descriptions

    SiT6096EBB Evaluation Board User Manual EVB Usage Descriptions EVB Configurations SiT6096EBB supports multiple configurations for evaluating AC and DC coupled output modes of SiTime oscillator. In addition, this EVB provides the ability to add additional load capacitance and to bypass the output buffer.
  • Page 4: Buffered Clock Output

    To get full amplitude result must be multiplied by 2. When using direct output configuration SiTime recommends active probes with 10 MΩ and <1 pF impedance for proper clock waveform measurement. A passive voltage probe is not recommended as it adds a high capacitive load to the part and the long ground lead clip is not suitable.
  • Page 5: Measuring Jitter

    SiT6096EBB Evaluation Board User Manual More details on the SiTime recommendations on the oscillator’s output probing can be found in AN10028. Measuring Jitter The analog buffer isolates the device from the significant loading, which is important for best jitter measurement result. The R2 can be populated as 0 Ω resistor for best result.
  • Page 6 AMP_POWER Turret for probe clip Pad5 Pad10 V-_BUFFER V+_BUFFER Pad6 Pad11 Buffer Power Connector Pad12 Pad7 10.0 10.0 Pad8 Pad13 V-_BUFFER Pad9 Pad14 Figure A1. SiT6096EBB EVB Electrical schematics SiT6096EBB User Manual | Rev 2.0 Page 6 of 9 www.sitime.com...
  • Page 7 Connectors part number connector products DUT power WM10299-ND WM2002-ND WM1114TR-ND Pin 1 access 2057-PH1RA-02-UA-ND WM2011-ND WM2756CT-ND Buffer power WM10298-ND 900-0022013037-ND WM1114TR-ND WM5534-ND 23-0732512430-ND SiT6096EBB User Manual | Rev 2.0 Page 7 of 9 www.sitime.com...
  • Page 8 SiT6096EBB Evaluation Board User Manual Buffered output SMA connector Direct output Power RC test point filter Post for scope GND clip AC/DC coupling Figure A2. SiT6096EBB EVB SiT6096EBB User Manual | Rev 2.0 Page 8 of 9 www.sitime.com...
  • Page 9 © SiTime Corporation, January 2025. The information contained herein is subject to change at any time without notice. SiTime assumes no responsibility or liabi lity for any loss, damage or defect of a Product which is caused in whole or in part by (i) use of any circuitry other than circuitry embodied in a SiTime product, (ii) misuse or abuse including static discharge, neglect or accident, (iii) unauthorized modification or repairs which have been soldered or altered during assembly and are not capable of being tested by SiTime under its normal test conditions, or (iv) improper installation, storage, handling, warehousing or transportation, or (v) being subjected to unusual physical, thermal, or electrical stress.
