SiT6095EB Evaluation Board User Manual
Contents
1 Introduction ............................................................................................................................................. 1
2 I/O Descriptions ....................................................................................................................................... 2
3 EVB Usage Descriptions ........................................................................................................................... 2
3.1 EVB Configurations........................................................................................................................ 2
3.2 Waveform Capturing Using Active Probe ..................................................................................... 3
3.3 Measuring Jitter and Phase Noise ................................................................................................. 4
3.4 Current Measurement .................................................................................................................. 4
Appendix A .................................................................................................................................................... 5
1

Introduction

The SiT6095EB evaluation board (EVB) is designed for use with SiTime's XO in the 4-pin, 2.0 x 1.6 mm
packages and LVCMOS output type.
The SiT6095EB supports the following products:
Base Part Number
SiT1602
SiT8008
SiT8009
SiT8918
SiT8919
SiT8920
SiT8921
SiT8924
SiT8925
SiT8944
SiT8945
SiT9025
SiT9005
SiT9045
SiT1618
SiT5008
SiT6095EBB User Manual | Rev 3.01
Type
XO
XO
XO
Automotive & High Temp XO
Automotive & High Temp XO
Automotive & High Temp XO
Automotive & High Temp XO
Automotive & High Temp XO
Automotive & High Temp XO
Endura Automotive &
High Temp XO
Endura Automotive &
High Temp XO
Automotive SSXO
SSXO
Endura SSXO
XO
TCXO
Page 1 of 8
Output frequency
3.57 MHz - 77.76 MHz
1 MHz - 110 MHz
115 MHz - 137 MHz
1 MHz - 110 MHz
115 MHz - 137 MHz
1 MHz - 110 MHz
115 MHz - 137 MHz
1 MHz - 110 MHz
115 MHz - 137 MHz
1 MHz - 110 MHz
115 MHz - 137 MHz
1 MHz - 150 MHz
1 MHz - 141 MHz
1 MHz - 150 MHz
7.3728 MHz - 48 MHz
10 MHz - 60 MHz
Package
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
2.0 x 1.6 QFN
www.sitime.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SiT6095EB and is the answer not in the manual?

Questions and answers

Related Manuals for SiTime SiT6095EB

Summary of Contents for SiTime SiT6095EB

  • Page 1: Table Of Contents

    3.4 Current Measurement ........................4 Appendix A ..............................5 Introduction The SiT6095EB evaluation board (EVB) is designed for use with SiTime’s XO in the 4-pin, 2.0 x 1.6 mm packages and LVCMOS output type. The SiT6095EB supports the following products:...

  • Page 2: O Descriptions

    EVB Usage Descriptions EVB Configurations SiT6095EB can be configured to support three configuration modes including XO/TCXO with output enable (OE), XO in Standby (ST), Spread Disabled (SD), Voltage Control (VC) or Digital Control (DC). Oscillator output can be accessed in several ways listed in Table 2. Table 2 describes components configuration to support all output configurations.

  • Page 3: Waveform Capturing Using Active Probe

    For waveform measurement, it's recommended to remove resistor R7. Please refer to Figure A2 for test point locations on the SiT6095EB. If the soldering probe is used, it is recommended to use C7 capacitor pads or solder it over it if necessary (Figure SiT6095EBB User Manual | Rev 3.01...

  • Page 4: Measuring Jitter And Phase Noise

    Figure 1: Recommended points for soldering probe head More details on the SiTime recommendations on the oscillator’s output probing can be found in AN10028. Measuring Jitter and Phase Noise For Jitter measurements or phase noise measurements with evaluation boards, SiTime recommends using SMA support Configuration to connect the device output directly to external equipment, such as Time Interval Analyzer (TIA) or high-bandwidth real-time oscilloscope.
  • Page 5 SiT6095EB Evaluation Board User Manual Appendix A 10uH 10uF Sense 0.1uF 0.01uF 0.1uF PIN1 J1 SMA edge mount PIN1 Pin1 NL R7 0.1uF SiTime_4pin PIN1 SMA edge mount Figure A1: SiT6095EB electrical schematics SiT6095EBB User Manual | Rev 3.01 Page 5 of 8...
  • Page 6 SiT6095EB Evaluation Board User Manual Table A1: Bill of Materials (BOM) Reference Description SMD component size Value Designators Capacitors 0603 10uF Capacitors 0603 C3, C5, C6 Capacitors 0603 0.1uF Capacitor 0402 0.01uF Capacitor 0402 bidirectional 0603 protection diode Inductance 0805...
  • Page 7 SiT6095EB Evaluation Board User Manual Probe test points Signal VDD sense Figure A2: SiT6095EB layout SiT6095EBB User Manual | Rev 3.01 Page 7 of 8 www.sitime.com...
  • Page 8 © SiTime Corporation, January 2024. The information contained herein is subject to change at any time without notice. SiTime assumes no responsibility or liabi lity for any loss, damage or defect of a Product which is caused in whole or in part by (i) use of any circuitry other than circuitry embodied in a SiTime product, (ii) misuse or abuse including static discharge, neglect or accident, (iii) unauthorized modification or repairs which have been soldered or altered during assembly and are not capable of being tested by SiTime under its normal test conditions, or (iv) improper installation, storage, handling, warehousing or transportation, or (v) being subjected to unusual physical, thermal, or electrical stress.
