Stainless Steel Surface-Mount Enclosure
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information which is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
General Information
The Model 238-001RT6 Stainless Steel Surface-Mount Enclosure is designed to house GAI-Tronics
RT6-type flush-panel telephones, which measure 11.87 H × 8.25 W inches. The following components
are supplied with the Model 238-001RT6 Enclosure:
Qty Description
1 Telephone jack with double-sided adhesive pad
C
1 label
AUTION
1 Access hole gasket
4 Rubber washers
Installation
Safety Guidelines
When installing GAI-Tronics' telephone equipment, please adhere to the following guidelines to ensure
the safety of all personnel:
•
NEVER install telephone wiring during a lightning storm.
•
NEVER install telephone jacks in wet locations unless the jack is specifically designed for wet
locations.
•
NEVER touch uninsulated telephone wires or terminals unless the telephone line has been
disconnected at the network interface.
•
USE CAUTION when installing or modifying telephone lines.
