Model 733-006 Single-Party Outdoor
Non-metallic Amplifier Enclosure
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics. GAI-
Tronics retains all intellectual property and other rights in or to the information contained herein, and
such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
General Information
The Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure is a component of the 700
Series Page/Party System. It is constructed of glass-reinforced polyester and is extremely weatherproof
and corrosion-resistant. This enclosure is equipped with terminal strips for connecting system cable.
®
The Page/Party
series amplifiers mate directly with this enclosure.
Installation
CAUTION
Do not install this equipment in hazardous areas or areas other than those
indicated on the approval listing in the "Specifications" section of this manual. Such installation
may cause a safety hazard and consequent injury or property damage.
WARNING
Do not disconnect equipment while energized.
Insure proper grounding to protective earthing.
When installing an add-on station, consult the appropriate system layout diagrams. These figures, when
used in conjunction with the station installation information and cable layout guide, should provide all
the information necessary to install additional Page/Party stations.
Enclosure Placement
All GAI-Tronics Page/Party
required for each installation. GAI-Tronics multi-conductor cable, designed especially for this
application, is recommended. For the number, size, and color-coding of conductors refer to the
appropriate system connection diagrams.
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
V
ISIT WWW
G A I - T R O N I C S ®
A H U B B E L L C O M P A N Y
®
units are wired in parallel. Good system layout design minimizes the cable
610-777-1374
800-492-1212
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
Fax: 610-796-5954
Pub. 42004-372B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hubbell GAI-TRONICS 733-006
Summary of Contents for Hubbell GAI-TRONICS 733-006
- Page 1 Pub. 42004-372B G A I - T R O N I C S ® A H U B B E L L C O M P A N Y Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure Confidentiality Notice This manual is provided solely as an operational, installation, and maintenance guide and contains sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
- Page 2 Pub. 42004-372B 2 of 7 Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure Page: System layout and power cable length are very important when installing Page/Party equipment. Although it varies for different systems, the general guideline is that the total power cable length should not exceed 1 mile (5280 feet) for 120 V ac systems.
- Page 3 Pub. 42004-372B 3 of 7 Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure Page: Figure 1. Model 733-006 Enclosure Mounting Details f:\standard ioms - current release\42004 instr. manuals\42004-372b.doc 11/10...
- Page 4 Pub. 42004-372B 4 of 7 Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure Page: Wiring Attach the conduit to the enclosure. Feed the wiring through the conduit and bring it into the enclosure. See Figure 2. Follow the wire colors carefully because the colors correspond to GAI-Tronics cable. The wires must be spade-lugged and connected carefully and completely to the terminal block.
- Page 5 Pub. 42004-372B 5 of 7 Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure Page: Figure 2. Wiring Diagram f:\standard ioms - current release\42004 instr. manuals\42004-372b.doc 11/10...
- Page 6 Pub. 42004-372B 6 of 7 Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure Page: Maintenance Regular inspection and a good preventive maintenance program will increase the reliability of your GAI-Tronics station. The GAI-Tronics Field Service Department can formulate a service contract suited to your facility’s specific need for preventive maintenance.
- Page 7 Pub. 42004-372B 7 of 7 Model 733-006 Single-Party Outdoor Non-metallic Amplifier Enclosure Page: Specifications Construction/finish ........ Glass-reinforced polyester, J-hook latch, hinged door with gasket Mounting............. Wall, column, or pole (mounting kit required for pole mount), four 7/16-inch mounting holes Connections ................Internal screw-type barrier terminal blocks Dimensions ............
- Page 8 Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document.
