- Page 1 ™ ® Installer's Guide A Step-by-Step Guide for Installing a Complete Lutron GRAFIK 5000/6000 ® Lighting Control System...
- Page 3 Please be assured that all the information presented is pertinent to your GRAFIK 5000 System as well, except for the following points: GRAFIK 5000 has Link A only with a maximum of 32 Wallstations; GRAFIK 6000 has Links A, B and C with a total maximum of 96 Wallstations.
- Page 4 Overview System Features The GRAFIK 6000 Lighting Control System provides centralized preset lighting control for commercial facilities and large residences. The system Total centralized control consists of touch-button Wallstations and handheld wireless remote PC user interface controls located throughout a building, plus a central control panel and Windows ®...
- Page 5 Wire System ..............10-14 STEP 9: Set Normal/Emergency Switch........19 STEP 5: Set Address DIP Switches ........15-16 STEP 6: Install Controls and Walljacks ........17 Reference Sheets Page User-Supplied PC Specifications Hardware and Software Requirements ......20 Table of Contents for GRAFIK 5000/6000 Lighting Control System...
- Page 6 Standard US wallbox, 4 gang, 2 3/4 in. deep minimum, 3-1/2 in. deep OMX-DACPI recommended Lutron No. 241-519: 3-1/2 in. (89mm) deep, (1 per gang, 4 required) Consult Lutron All other Controls For More Information... See instructions packaged with each control. Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 7 OMX-7B DW, OMX-4SLB-DW, and OMX-2B-DW Mounting OMX-7B-DW, OMX-4SLB-DW, and OMX-2B-DW Mounting (with wallbox) (without wallbox) Lutron No. Lutron P/N 241-399 241-399 Door Trim yoke yoke 90 mm 3-1/2” 32 mm 1-1/4” Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 8 ARE 7/8" (23mm) DIA. AND 1 1/8" warranty. (29mm) DIA. 38 mm 140 mm 38 mm (1 1/2”) (5 1/2”) (1 1/2”) For More Information... See GP 3,4 Installation Guide provided with the panel . Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 9 Note: GP-8 through 24 must have its top cover punched for Feed and Load Circuit wiring. For More Information... See GP Installation Guide provided with the panel Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 10 25 mm (1”) 13 mm (1/2”). conduit knockouts MXINP-ENC RS232 input enters here 51 mm (2”) Wallstation links enter here Dimmer panel link enters here User interface link Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 11 Caution! This equipment is air-cooled. Vents must not be blocked or you will void the warranty. Warning! CE marked panels with 10A circuit breakers are intended for industrial or commercial installations. Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 12 Caution! Only use the four holes indicated when surface mounting. Other holes in the back of panel are No clearance required above, below, or to each side. used for mounting the subplate. Weight: 45lbs (20kg) with electronics. Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 13 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 MXIMP-ENC CONTROL CONTROL DIMMER PANEL USER CONTROL LINK #_____ LINK #_____ LINK INTERFACE LINK #_____ MODEL NUMBER DEDICATED FEED 120VAC, 15A/20A GR6MXINP GR6MXINP-220/240 220-240VAC, 10A Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 14 (LT1 not necessary for stageboard-already built in). Data A OK Power Data B OK Link Link 24VFW 1 2 3 4 Common Sense 1 2 3 4 Drain/Shield Link A Terminals Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 15 Use the wire connector required by local code (those shown are connections in the wallbox. #12 AWG (2.5mm ) is necessary due to voltage drop on the wire. common in the USA). Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 16 • Max 32 controls/link. NTOMX-4B NTOMX-4B GR6-HHP • Max 96 controls/system. • LT-1 supplied in GRAFIK 6000 processor panel. OMX-AV OMX-CIR OMX-7B-DW OMX-2B-DW LT-1 LT-1 Wallstation Link A Wallstation Link B Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 17 Warning! CE marked panels are appliances. A distribution panel must provide a main circuit breaker that does not exceed the rating of the panel. Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 18 User Interface Link Wiring (Low Voltage Wiring) STATUS LEDs 1 PER LINK TO DIMMER TO USER NOT USED WALLSTATION WALLSTATION WALLSTATION PANEL LINK INTERFACE/ LINK A LINK B LINK C COMPUTER LINK Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 19 DIP Switches and recording them above. Note: This diagram shows a common Wallstation back. Some newer products may have a different layout. See product instructions for detailed drawings. Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 20 Scenes 1 - 4 and OFF Link A Address 5 UUDUUX LV29 Entry Hall Multi 7B - Architrave 7 Button Scenes 1 - 4 and OFF Link A Address 29 UUDDDX Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 21 Schedule. Correct any problems before proceeding. F. Wire and check all loads connected to system prior to factory commissioning. Warning! DO NOT remove bypass jumpers at this time. Bypass Jumpers Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 22 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 GRAFIK 6000 Main Board DIMMER PANEL USER INTERFACE CONTROL CONTROL CONTROL LINK LINK #_____ LINK #_____ LINK #_____ Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 23 Unassigned Neon / CC Incandescent Non-Dim Incandescent Non-Dim Fluorescent Lutron Hi-lume FDB Ballast Fluorescent Lutron Hi-lume FDB Ballast Fluorescent Lutron Tu-Wire Ballast Fluorescent Lutron Tu-Wire Ballast Move left Move right Step by Step Instructions for GRAFIK 5000/6000 Lighting Control System...
- Page 24 IBM is a registered trademark of International Business Machines Corporation. Windows is a registered trademark of Microsoft Corporation . Close-Up is a registered trademark of Norton-Lambert Corporation. Pentium is a registered trademark of Intel Corporation. Reference Sheet for GRAFIK 5000/6000 Lighting Control System...
- Page 28 Fax: ++65-220-4333 GRAFIK 5000 Hi-Power, Eco-10, LIAISON, Designer, Tu-Wire, and Architrave International ++49-30-97-10-4591 are trademarks of Lutron Electronics Co., Inc. © 2001 Lutron Electronics Co., Inc. ® Safety standards listed above apply to one or more products in the GRAFIK Eye product line. Consult factory for specific information.
