rosseto EZ-SERV EZL015 Instructions

EZ-SERV® TABLE-TOP DISPENSER WITH WOOD TRAY
Your EZ-SERV® Standing Dispenser comes with the 6-Wing 1 Tbsp Portion Wheel. This
portion wheel is perfect for dispensing items such as medium grind cookies, cereals &
granolas, trail mixes and coffee beans!
SETTING UP YOUR PRODUCT
1. Carefully remove all parts from packaging and poly bags:
2. Make sure you have all parts above before discarding packaging.
3. Place table stand on a flat surface facing you.
4. Find the ridges on the underside of the wooden tray – these mark the back of the tray. Place the wooden tray on the base
of the table stand, with the smoother side of the tray facing you.
5.
Fill containers with desired dry product and seal with the lid. (You may also choose to do this after Step 7.)
Hold the container above the stand with the handle facing you. Carefully lower the container down to the metal opening,
6.
tilted at an angle that allows the handle to clear through first.
Note: The back of the container has a small key that aligns with bracket notch to prevent movement from side to side.
7.
Once the handle is cleared through the metal opening, you may tilt the container carefully back to a full upright
position. Then, gently set the container down directly on the stand.
8.
Repeat Steps 5 thru 8 for the remaining containers.
9.
Attach label holder (d) to bracket as shown in FIGURE A.
10. Dispense as you please!
FIGURE A
1. Hold Label Holder horizontally beneath the bracket., above the steel handle.
2. Slide the label holder forward into the slot alloted. There are 2 small wings on the back
portion that will glide over the metal until you can lock it into position.
1
NEED ASSISTANCE?
•
1 Table Stand
•
1 Wooden Tray
• Depending on your model, 1-5 Containers each one with:
a. Lid
b. 6-Wing 1 Tbsp Portion Wheel
c. Container
d. Label Holder
e. Handle
2 3
ROSSETO
3. Hold the bottom portion of the label holder
and pull gently until it clicks into place.
4. Insert the desired label.
NOTE:
Recommended label size is 60 x 35 mm / 2.35" x 1.4"
Please contact our customer support at (847)763-1215 and we'll be
happy to assist with any assembly questions, comments or concerns.
3600 W. Pratt Avenue. Lincolnwood, IL 60712
®
a
LID
FOR 1.3-GAL: ITEM # EZL015
FOR 2.0-GAL: ITEM # EZL017
FOR 3.5-GAL: ITEM # EZL018
b
6-WING 1 TBSP PORTION WHEEL
ITEM # EZP004
c
CONTAINER
FOR 1.3-GAL: ITEM # EZC014
FOR 2-GAL: ITEM # EZC013
FOR 3.5-GAL: ITEM # EZC020
Visit our website at: www.rosseto.com
LABEL HOLDER
d
ITEM # EZM036
HANDLE
e
ITEM # EZH012
