Summary of Contents for DTS DIVE 12 N
- Page 2 Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S . D.T.S.
-
Page 3: Table Of Contents
1- SYMBOLS ................................4 2- GENERAL WARNING ............................5 3- GENERAL WARRANTY CONDITIONS ........................5 4- TECHNICAL FEATURES DIVE 12 N 24 Vdc ......................5 5- TECHNICAL FEATURES AKHELIOS 12 N 24 Vdc ....................6 DIMENSIONS DIVE 12 N ............................8 5- ACCESSORIES DIVE 12 N ............................ -
Page 4: 1- Symbols
1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL INDICATES ELECTRICSHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL INDICATES THE MINIMUM DISTANCE FROM THE ILLUMINATED OBJECTS THIS SYMBOL MEANS “DO NOT STARE AT THE OPERATING LIGHT... -
Page 5: 2- General Warning
The warranty covers defects in materials and workmanship. The warranty is not appliable where a defect is caused by misuse or unauthorised repair of the product. Any functional or/and physical modification of the product is not allowed. 4- TECHNICAL FEATURES DIVE 12 N 24 Vdc Product codes: 03.LPB100E99FC25 DIVE 12 N FC MF 24VDC IP68 03.LPB100E99FC10... -
Page 6: 5- Technical Features Akhelios 12 N 24 Vdc
Operating temperature + 1° / + 45°C Storage temperature -40° / + 85°C Physical IP68 Housing: Bronze / Stainless steel 316 Weight: 5.6 Kg Beware Underwater installation only allowed Never make the joints of the cables in water Certifications 5- TECHNICAL FEATURES AKHELIOS 12 N 24 Vdc Product codes: 03.LPS100E99FC25 AKHELIOS 12 N FC MF 24VDC IP68... - Page 7 Power supply Outputs for Products Code Name Voltage Drivenet every release 03.LA.184.V2 Drivenet 832 24 Vdc 1400 Power consumption 120W max Connections End-stripped 8-pole cable Operating temperature + 1° / + 45°C Storage temperature -40° / + 85°C Physical IP68 Housing: Bronze / Stainless steel 316 Weight: 6.2 Kg Beware...
-
Page 8: Dimensions Dive 12 N
DIMENSIONS DIVE 12 N 5- ACCESSORIES DIVE 12 N Optional (on request) ● 8-pole underwater cable (code 0509C159 ) ● HUB – IP56 Screw terminals 1 IN / 3 OUT (code 03.LA.131.IP56 ) ● HUB – IP20 Screw terminals 1 IN / 3 OUT (code 03.LA.131 ) P a g . -
Page 9: Dimensions Akhelios 12 N
DIMENSIONS AKHELIOS 12 N 5- ACCESSORIES AKHELIOS 12 N Optional (on request) ● 8-pole underwater cable (code 0509C159) ● HUB – IP56 Screw terminals 1 IN / 3 OUT (code 03.LA.131.IP56 ) ● HUB – IP20 Screw terminals 1 IN / 3 OUT (code 03.LA.131 ) ●... -
Page 10: 6- Important Safety Information
Do not use any cleaning towels that are abrasive. Use only microfiber towels. If unsure about the suitability of a product for cleaning bronze, contact DTS. Maintenance period can vary depending on water quality and environment conditions. -
Page 11: Maintenance
If any parts are broken or missing, contact DTS to determine the availability of replacements. Replace any screw only by 316 stainless steel screws. To replace cable or gaskets, contact DTS. -
Page 12: 7- Connections Dive 12 N
7- CONNECTIONS DIVE 12 N DIVE 12 N is provided with an end-stripped 8-pole cable The maximum distance between DRIVENET PSU and DIVE 12 N 24 Vdc unit should not exceed 40 meter P a g . 12 | 16... -
Page 13: Connections Akhelios 12 N
CONNECTIONS AKHELIOS 12 N AKHELIOS 12 N is provided with an end-stripped 8-pole cable The maximum distance between DRIVENET PSU and AKHELIOS 12 N 24Vdc unit should not exceed 40 meters. P a g . 13 | 16... -
Page 14: 8- Connection Diagrams
8- CONNECTION DIAGRAMS DIVE 12 N 24Vdc The maximum distance between DRIVENET PSU and DIVE 12 N 24Vdc unit should not exceed 40 meters. The maximum current for all output channels of the drivenet psu must be set to 1400 mA in the display menu “LED CURRENTS”... -
Page 15: Akhelios 12 N 24Vdc
AKHELIOS 12 N 24Vdc The maximum distance between DRIVENET PSU and AKHELIOS 12 N 24Vdc unit should not exceed 40 meters. The maximum current for all output channels of the drivenet psu must be set to 1400 mA in the display menu “LED CURRENTS”... - Page 16 P a g . 16 | 16...
