Touchstone SIDELINE DELUXE Owner's Manual

50”/60” electric fireplace heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SIDELINE DELUXE
ELECTRIC FIREPLACE HEATER
Model # : 86273, 86275
86276, 86277, 86278, 86279
OWNER'S MANUAL
50"/60"
Sideline Deluxe™
Electric Fireplace
AC 110-120V 60Hz 1500W
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
WARNING
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIDELINE DELUXE and is the answer not in the manual?

Questions and answers

Related Manuals for Touchstone SIDELINE DELUXE

Summary of Contents for Touchstone SIDELINE DELUXE

  • Page 1 SIDELINE DELUXE ELECTRIC FIREPLACE HEATER Model # : 86273, 86275 86276, 86277, 86278, 86279 OWNER’S MANUAL 50”/60” Sideline Deluxe™ Electric Fireplace AC 110-120V 60Hz 1500W Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury.
