- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all Hydrocarbon PR Refrigerator Models 809-217A Rev. C. 04/21/2025 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: beverage-air.com...
-
Page 2: Table Of Contents
Beverage-Air! You have made a quality investment that with proper maintenance will give you many years of reliable service! Important Information •... -
Page 3: Safety
R290 equipment. • Clean a dirty condenser with a sharp object. • Use ONLY Beverage-Air factory service parts. Use of • Store gasoline, kerosene or any other flammable non OEM parts can be dangerous because of the design material near the cabinet. - Page 4 User Manual for PR Refrigerators Beverage-Air SAFETY CAUTION: If it is necessary to move the Refrigerator after removal from the skid, CAUTION remove all doors and carefully push the unit at a point of no more than 36” from the bottom to avoid damage.
-
Page 5: Important Information
User Manual for PR Refrigerators Beverage-Air IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes bars and restaurants. If installed in a residence some commercial service companies may not be able to service it on site. -
Page 6: Product Information
Charge (g) / Charge w x d x h (Inches) Door Solid Door Amps Plug (NEMA) (oz) PR1HC-1AS 26 1/2 x 34 3/4 x 84 1/8 1 Full Solid PR1HC-1AHS 26 1/2 x 34 3/4 x 84 1/8 2 Half... -
Page 7: Clearance And Placement
User Manual for PR Refrigerators Beverage-Air CLEARANCE AND PLACEMENT 12" 12" AT 12" AT MINIMUM CLEARANCE 0" 0" AT 0" AT REAR REAR MINIMUM REAR CLEARANCE 0" LEFT/RIGHT SIDE MINIMUM CLEARANCE 0" AT 0" AT BOTTOM BOTTOM 0" AT SIDES 0"... -
Page 8: Unpacking And Set Up
User Manual for PR Refrigerators Beverage-Air UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. -
Page 9: Shelf Installation
9. Do NOT overload the shelves. The unit is designed to need to be squeezed slightly during installation. use all shelves that are supplied in an equally spaced manner. Contact Beverage-Air customer service if 4. Install all remaining clips. fewer shelves or a different configuration to ensure shelf overloading will not occur. -
Page 10: Electrical
4 to 6 mA. To avoid this • Cabinet MUST NOT SHARE A RECEPTACLE with issue in a location that requires GFCI circuit protection, Beverage-Air recommends using either an Eaton, SGF20, another piece of equipment or HUBBELL Model Number GFRST83W 20A Heavy Duty •... -
Page 11: Door Reversal Instructions
User Manual for PR Refrigerators Beverage-Air DOOR REVERSAL INSTRUCTIONS 1. Remove hinge cover. 2. Remove door from the unit including the hinge mounting brackets 3. Remove white hole covers from the side of the door opening you would like the hinges to be located (do not throw away). -
Page 12: Using The Unit - Danfoss Controller
User Manual for PR Refrigerators Beverage-Air User Manual for MMR Refrigerators Beverage-Air USING THE UNIT - DANFOSS CONTROLLER USING THE UNIT - DANFOSS CONTROLLER Operation is simple, just keep it connected to the correct The Refrigerator will automatically defrost as needed, power supply and the refrigerator will maintain the there is no set time for defrost. -
Page 13: Sequence Of Operations Refrigerator
User Manual for PR Refrigerators Beverage-Air 2 34 5 6 6 2 5 5 54 8 6 6 ... - Page 14 User Manual for UCR Refrigerators Beverage-Air User Manual for PR Refrigerators Beverage-Air DANFOSS CONTROLLER DEFROST (ESC) Electronic Controller SELECT (OK) DOWN Control Panel Display Note: Defrost is manual, LED indicator is inoperative. Defrost LED Alarm LED On fixed: Defrost active...
- Page 15 01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for PR Refrigerators Beverage-Air ! " ! # $ % ! & '( # ÿ Rev.
- Page 16 User Manual for PR Refrigerators Beverage-Air () * + , ÿ . / ÿ 0 1 0 2 3ÿ 4 5 6 1 7 8 9 : ; ÿ < 9 34 8 ÿ 0 2 4 ÿ 9 ; ÿ = 2 : > 2 4 8 8 ÿ ? @A @ÿ / : 1 C 4 2 ÿ : / ÿ < D 4 ÿ = 0 2 0 34 < 4 2 ÿ < 0 E 1 4 F G ÿ < D 4 ÿ 0 1 0 2 3ÿ 9 8 ÿ ; : < ÿ 8 9 > ; 0 1 4 C H Beverage-Air Rev.
-
Page 17: Using The Unit - Eliwell Controller
2 2 3 6 2 3 User Manual for PR Refrigerators Beverage-Air +,- ./ÿ 123ÿ +.- 1ÿ 4 ÿ 35 - 635 5 ÿ 78.1985 5 39 ! " ! # $ % ! & '( # ÿ... -
Page 18: Sequence Of Operations Refrigerator
Refrigerator with Eliwell Controller Refrigerator with Eliwell Controller Beverage-Air Beverage-Air User Manual for PR Refrigerators Beverage-Air SEQUENCE OF OPERATIONS REFRIGERATOR The refrigerator operates based on the air temperature measured by the probe located at the return air. CONTROLLER CONTROLLER COMPONENT... - Page 19 01 2 3 ÿ 56 786 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for PR Refrigerators Beverage-Air ! " ! # $ % ! & '( # ÿ Rev.
- Page 20 01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for PR Refrigerators Beverage-Air ÿ ! " ! # $ % ! & '( # Beverage-Air Rev.
-
Page 21: Cleaning And Maintenance
User Manual for PR Refrigerators Beverage-Air CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Routine maintenance Daily wipe down Quarterly cleaning Daily inspection, check Annually that hinges are tight to Weekly interior the cabinet. Daily Exterior Cleaning It is much easier to clean on a regular basis than to have to remove stains once they have built up. -
Page 22: Condenser Cleaning
User Manual for PR Refrigerators Beverage-Air CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient operation. 1. Unplug unit from power supply. Rotating fan blade can cause CAUTION personal injury. Unplug unit from power supply before beginning to clean... -
Page 23: Methods For Cleaning Stainless Steel
User Manual for PR Refrigerators Beverage-Air METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. Smears and fingerprints O’Cedar Cream Polish, Stainless... -
Page 24: Help
User Manual for PR Refrigerators Beverage-Air HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. -
Page 25: For The Service Tech - R290
User Manual for PR Refrigerators Beverage-Air FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. It is a Evacuation: It is critical that a refrigeration system be reminder and checklist for the service tech. -
Page 26: For The Service Tech - Wiring Diagrams
User Manual for PR Refrigerators Beverage-Air FOR THE SERVICE TECH - WIRING DIAGRAM 115V ONE SYSTEM REFRIGERATOR BLACK WHITE 115VAC 60 HZ EVAP FAN RELAY CONTROL CIRCUIT COMPRESSOR DETAIL CONDENSER FAN START RELAY S.C. COMP R.C. COMP RELAY HIGH PRESSURE... -
Page 27: Limited Warranty
If service is deemed non- freight for the return of the failed compressor. warranty, Beverage-Air reserves the right to bill the end user for service. * Units shipped after 07/01/2024. Previous warranty applies to units shipped prior. -
Page 28: Limited Warranty (Continued)
GIVEN IN LIEU OF ALL OTHER WARRANTIES, apply. Notice: Specifications are subject to change EXPRESS, IMPLIED, OR STATUTORY, INCLUDING without notice. Contact Beverage-Air for specific model THE IMPLIED WARRANTIES OF MERCHANTABILITY agency approval. All prices are ex-works Brookville, AND FITNESS FOR A PARTICULAR PURPOSE, PA. -
Page 29: Replacement Parts
User Manual for PR Refrigerators Beverage-Air REPLACEMENT PARTS PR1HC-1AS 05315650 SHELL END TOP (2) 44B31-324D-01 TOP GRILLE ASSY (1) 50A36-220D-05 INSTRUMENT PANEL (1) 502-513D-31 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (4) 50022601 SHELF SUPPORT CLIPS (12) 50597706 SHELF (3) Rev. 04/25... - Page 30 User Manual for PR Refrigerators Beverage-Air DOOR ASSEMBLY (PART # 40B47-075D-01) 50917901 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50597111 LOCK (1) LEG KIT (PART # 00C26-028A) ------------------------- 6" STEEL LEGS - NOT SOLD SEPARATELY (4) Beverage-Air Rev.
- Page 31 User Manual for PR Refrigerators Beverage-Air PR1HC-1AHS 05315650 SHELL END TOP (2) 44B31-324D-01 TOP GRILLE ASSY (1) 50A36-220D-05 INSTRUMENT PANEL (1) 502-513D-31 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (4) 50022601 SHELF SUPPORT CLIPS (12) 50597706 SHELF (3) Rev. 04/25 Beverage-Air...
- Page 32 User Manual for PR Refrigerators Beverage-Air TOP DOOR ASSEMBLY (PART # 40B48-350D-01) 50917902 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50597111 LOCK (1) BOTTOM DOOR ASSEMBLY (PART # 40B48-351D-01 )
- Page 33 User Manual for PR Refrigerators Beverage-Air PR1HC-1BG 05315650 SHELL END TOP (2) 44B31-324D-01 TOP GRILLE ASSY (1) 50A36-220D-05 INSTRUMENT PANEL (1) 502-513D-30 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (4) 50022601 SHELF SUPPORT CLIPS (12) 50597706 SHELF (3) Rev. 04/25 Beverage-Air...
- Page 34 User Manual for PR Refrigerators Beverage-Air DOOR ASSEMBLY (PART # 10688302) 50876402 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50598102 LOCK (1) LEG KIT (PART # 00C26-028A) ------------------------- 6" STEEL LEGS - NOT SOLD SEPARATELY (4) Beverage-Air Rev.
- Page 35 User Manual for PR Refrigerators Beverage-Air PR1HC-1BHG 05315650 SHELL END TOP (2) 44B31-324D-01 TOP GRILLE ASSY (1) 50A36-220D-05 INSTRUMENT PANEL (1) 502-513D-30 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (4) 50022601 SHELF SUPPORT CLIPS (12) 50597706 SHELF (3) Rev. 04/25 Beverage-Air...
- Page 36 User Manual for PR Refrigerators Beverage-Air TOP DOOR ASSEMBLY (PART # 10689103) 50876403 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50598102 LOCK (1) BOTTOM DOOR ASSEMBLY (PART # 10689102)
- Page 37 User Manual for PR Refrigerators Beverage-Air PR2HC-1AS 05315650 SHELL END TOP (2) 44B31-327D-01 TOP GRILLE ASSY (1) 50A36-223D-05 INSTRUMENT PANEL (1) 502-513D-31 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (8) 50022601 SHELF SUPPORT CLIPS (24) 50597806 SHELF (6) Rev. 04/25 Beverage-Air...
- Page 38 User Manual for PR Refrigerators Beverage-Air RIGHT DOOR ASSEMBLY (PART # 40B47-075D-01) 50917901 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50597111 LOCK (1) LEFT DOOR ASSEMBLY (PART # 40B47-075D-01)
- Page 39 User Manual for PR Refrigerators Beverage-Air PR2HC-1AHS 05315650 SHELL END TOP (2) 44B31-327D-01 TOP GRILLE ASSY (1) 50A36-223D-05 INSTRUMENT PANEL (1) 502-513D-31 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (8) 50022601 SHELF SUPPORT CLIPS (24) 50597806 SHELF (6) Rev. 04/25 Beverage-Air...
- Page 40 User Manual for PR Refrigerators Beverage-Air TOP RIGHT DOOR ASSEMBLY (PART # 40B48-350D-01 ) 50917902 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50597111 LOCK (1) TOP LEFT DOOR ASSEMBLY (PART # 40B48-351D-02)
- Page 41 User Manual for PR Refrigerators Beverage-Air PR2HC-1BG 05315650 SHELL END TOP (2) 44B31-327D-01 TOP GRILLE ASSY (1) 50A36-223D-05 INSTRUMENT PANEL (1) 502-513D-30 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (8) 50022601 SHELF SUPPORT CLIPS (24) 50597806 SHELF (6) Rev. 04/25 Beverage-Air...
- Page 42 User Manual for PR Refrigerators Beverage-Air RIGHT DOOR ASSEMBLY (PART # 10688302) 50876402 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50598202 DOUBLE LOCK (1) LEFT DOOR ASSEMBLY (PART # 10688301)
- Page 43 User Manual for PR Refrigerators Beverage-Air PR2HC-1BHG 05315650 SHELL END TOP (2) 44B31-327D-01 TOP GRILLE ASSY (1) 50A36-223D-05 INSTRUMENT PANEL (1) 502-513D-30 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (8) 50022601 SHELF SUPPORT CLIPS (24) 50597806 SHELF (6) Rev. 04/25 Beverage-Air...
- Page 44 User Manual for PR Refrigerators Beverage-Air TOP RIGHT DOOR ASSEMBLY (PART # 10689103) 50876403 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50598202 DOUBLE LOCK (1) TOP LEFT DOOR ASSEMBLY (PART # 10689101)
- Page 45 User Manual for PR Refrigerators Beverage-Air PR3HC-1AS SHELL END TOP (2) 44B31-328D-01 TOP GRILLE ASSY (1) 50A36-226D-05 INSTRUMENT PANEL (1) 502-513D-31 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (12) 50022601 SHELF SUPPORT CLIPS (36) 50597906 CENTER SHELF (3) 50597806 LEFT AND RIGHT SHELF (6) Rev.
- Page 46 User Manual for PR Refrigerators Beverage-Air RIGHT DOOR ASSEMBLY (PART # 40B47-075D-01 ) 50917901 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50597111 LOCK (1) MIDDLE DOOR ASSEMBLY (PART # 40B47-075D-01 )
- Page 47 User Manual for PR Refrigerators Beverage-Air PR3HC-1AHS SHELL END TOP (2) 44B31-328D-01 TOP GRILLE ASSY (1) 50A36-226D-05 INSTRUMENT PANEL (1) 502-513D-31 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (12) 50022601 SHELF SUPPORT CLIPS (36) 50597906 CENTER SHELF (3) 50597806 LEFT AND RIGHT SHELF (6) Rev.
- Page 48 User Manual for PR Refrigerators Beverage-Air TOP RIGHT DOOR ASSEMBLY (PART # 40B48-350D-01) 50917902 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50597111 LOCK (1) TOP MIDDLE DOOR ASSEMBLY (PART # 40B48-350D-01)
- Page 49 User Manual for PR Refrigerators Beverage-Air PR3HC-1BG SHELL END TOP (2) 44B31-328D-01 TOP GRILLE ASSY (1) 50A36-226D-05 INSTRUMENT PANEL (1) 502-513D-30 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (12) 50022601 SHELF SUPPORT CLIPS (36) 50597906 CENTER SHELF (3) 50597806 LEFT AND RIGHT SHELF (6) Rev.
- Page 50 User Manual for PR Refrigerators Beverage-Air RIGHT DOOR ASSEMBLY (PART # 10688302) 50876402 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50598102 LOCK (1) MIDDLE DOOR ASSEMBLY (PART # 10688302)
- Page 51 User Manual for PR Refrigerators Beverage-Air PR3HC-1BHG SHELL END TOP (2) 44B31-328D-01 TOP GRILLE ASSY (1) 50A36-226D-05 INSTRUMENT PANEL (1) 502-513D-30 DANFOSS CONTROLLER (1) 59D35-120D-19 PILASTER (12) 50022601 SHELF SUPPORT CLIPS (36) 50597906 CENTER SHELF (3) 50597806 LEFT AND RIGHT SHELF (6) Rev.
- Page 52 User Manual for PR Refrigerators Beverage-Air TOP RIGHT DOOR ASSEMBLY (PART # 10689103) 50876403 DOOR GASKET (1) 00C34-034D-01 RETAIL HINGE KIT - LIFTOFF (1) ------------------------- DOOR HANDLE - NOT SOLD SEPARATELY (1) 50598102 LOCK (1) TOP MIDDLE DOOR ASSEMBLY (PART # 10689103)
- Page 53 User Manual for PR Refrigerators Beverage-Air REFRIGERATION SYSTEM ALL MODELS (SOME MODELS HAVE 2 SYSTEMS REFRIGERATION SYSTEM COMPONENTS (PART NUMBER -------------------- EVAP FAN (1) - PART NOT SOLD SEPARATELY -------------------- EVAP COIL (1) - PART NOT SOLD SEPARATELY -------------------- JUNCTION BOX (1) PART NOT SOLD SEPARATELY...
-
Page 54: Warranty Registration
User Manual for PR Refrigerators Beverage-Air Warranty Registration Register your product online at beverage-air.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product Business Name: ____________________________________________________...
