- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all Hydrocarbon CT Cross Temp™ Freezer / Refrigerator Models 809-154A 6/23/2020 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: beverage-air.com...
-
Page 2: Table Of Contents
If you meets the high standards set by Beverage-Air! You have have any questions, Please call our Technical Service made a quality investment that with proper maintenance Department at (800) 684-1195. -
Page 3: Safety
R290 equipment. • Clean a dirty condenser with a sharp object. • Use ONLY Beverage-Air factory service parts. Use of • Store gasoline, kerosene or any other flammable non OEM parts can be dangerous because of the design material near the cabinet. -
Page 4: Safety
User Manual for CT Freezer / Refrigerator Beverage-Air SAFETY CAUTION: If it is necessary to move the Refrigerator after removal from the skid, remove CAUTION all doors and carefully push the unit at a point of no more than 36” from the bottom to avoid damage. -
Page 5: Important Information
User Manual for CT Freezer / Refrigerator Beverage-Air IMPORTANT INFORMATION This unit is intended to be used in a commercial The manufacturer has designed and produced this application. That includes bars and restaurants. machine with the finest in materials. The manufacturer... -
Page 6: Product Information
User Manual for CT Freezer / Refrigerator Beverage-Air PRODUCT INFORMATION Cabinet Dimensions Half or Glass or Full Load Power Cord Refrigerant Type / Model w x d x h (Inches) Full Door Solid Door Amps Plug (NEMA) Charge (g) 5-15P... -
Page 7: Clearance And Placement
User Manual for CT Freezer / Refrigerator Beverage-Air CLEARANCE AND PLACEMENT 12" AT 0" AT BACK 6" AT BOTTOM 0" AT SIDES CT12-12HC-1HC Spacing Placement Consider the following when selecting a location for your Refrigerator: CT12-12HC-1HS Clearance Clearance: • 12 in. at the top •... -
Page 8: Unpacking And Set Up
User Manual for CT Freezer / Refrigerator Beverage-Air UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. - Page 9 User Manual for CT Freezer / Refrigerator Beverage-Air VAPORIZER PAN INSTALLATION Tools Needed Impact Gun with a A Philips head Philips head bit screwdriver Parts Included VAPORIZER ASSY 1D DT, BOTTOM Rev. 06/20 Beverage-Air...
- Page 10 User Manual for CT Freezer / Refrigerator Beverage-Air MOUNTING SCREWS From the back of the cabinet, nd the (4x) Philips head screws on the bottom. Using a tool with a Philips head tip, back the screws out about a ¼”.
- Page 11 User Manual for CT Freezer / Refrigerator Beverage-Air SECURING THE PAN ASSEMBLY Using the slots on the pan bracket, slide the assembly onto the screws then tighten the screws. Once the pan is secured, make sure both hoses are inside the pan NOTE: The hoses are often shipped with extra length and will need trimmed.
- Page 12 User Manual for CT Freezer / Refrigerator Beverage-Air ENERGIZING THE VAPORIZER Locate the receptacle at the bottom of the back channel Plug the vaporizer cord into the receptacle. If the cord is too long, use a zip tie to keep the cord from hanging on the ground.
-
Page 13: Shelf Installation
4. Install all remaining clips. manner. Contact Beverage-Air customer service if fewer shelves or a different configuration to ensure 5. Install shelves onto clips with the product retention shelf overloading will not occur. -
Page 14: Electrical
User Manual for CT Freezer / Refrigerator Beverage-Air ELECTRICAL This is a cord-connected unit, and must be connected to the machine to confirm the voltage and per the dataplate its own dedicated power supply. Check the dataplate on use the correct fuses or HACR circuit breakers. -
Page 15: Using The Unit
User Manual for CT Freezer / Refrigerator Beverage-Air USING THE UNIT Operation is simple, just keep it connected to the correct When switching from refrigerator to freezer or freezer power supply and the Cross Temp™ freezer/refrigerator to refrigerator, remove all product before making the will maintain the internal temperature it has been set change. -
Page 16: Sequence Of Operations Cross Temp
User Manual for CT Freezer / Refrigerator Beverage-Air SEQUENCE OF OPERATIONS CROSS TEMP The cooler operates based on the air temperature measured by the probe located at the return air. COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION COMPRESSOR Compressor turns on... - Page 17 User Manual for CT Freezer / Refrigerator Beverage-Air Electronic Controller DEFROST (ESC) SELECT (OK) DOWN Control Panel Display Note: Defrost is manual, LED indicator is inoperative. Defrost LED Alarm LED On fixed: Defrost active On fixed: ALARM Present Off: Defrost is off...
- Page 18 User Manual for CT Freezer / Refrigerator Beverage-Air Control Panel Connections Changing the Set Point Beverage-Air Rev. 06/20...
- Page 19 User Manual for CT Freezer / Refrigerator Beverage-Air Electronic Controller Alarms Alarm Trigger Automatic Outputs Comments Code Clearance "Hi" Air temperature is higher than User Bl ink "Hi" with the highest temperature; If High temperature "ALA->Hat• for "ALA->Htd" configured configured: cut in alarm relay, beep the buzzer alarm "Lo"...
-
Page 20: Cleaning And Maintenance
User Manual for CT Freezer / Refrigerator Beverage-Air CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Routine maintenance Daily wipe down Quarterly cleaning Daily inspection, check Annually that hinges are tight to Weekly interior the cabinet. Daily Exterior Cleaning It is much easier to clean on a regular basis than to have 3. -
Page 21: Condenser Cleaning
User Manual for CT Freezer / Refrigerator Beverage-Air CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient operation. 1. Unplug unit from power supply. Rotating fan blade can cause CAUTION personal injury. Unplug unit from power supply before beginning to clean... -
Page 22: Methods For Cleaning Stainless Steel
User Manual for CT Freezer / Refrigerator Beverage-Air METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. Smears and fingerprints O’Cedar Cream Polish, Stainless... -
Page 23: Help
User Manual for CT Freezer / Refrigerator Beverage-Air HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. -
Page 24: For The Service Tech - R290
User Manual for CT Freezer / Refrigerator Beverage-Air FOR THE SERVICE TECH - R290 inform anyone in the area when propane is present in Refrigeration service should only be attempted by a trained trade professional certified to work on R290 the air. -
Page 25: For The Service Tech - Wiring Diagram For Single System
User Manual for CT Freezer / Refrigerator Beverage-Air FOR THE SERVICE TECH - WIRING DIAGRAM FOR SINGLE SYSTEM 115VAC 60 HZ COMPRESSOR DETAIL COMP HIGH PRESSURE CONDENSER FAN LIMIT SWITCH FACE HEATER DOOR HEATER DEFROST HEATER HEATER SAFETY THERMAL SWITCH... -
Page 26: For The Service Tech - Wiring Diagram For Ct12-12Hc-1Hc
User Manual for CT Freezer / Refrigerator Beverage-Air FOR THE SERVICE TECH - WIRING DIAGRAM FOR CT12-12HC-1HC 115VAC 60 HZ COMPRESSOR DETAIL DANFOSS CONTROLLER DETAIL S3 S4 DI COMP HIGH PRESSURE CONDENSER FAN LIMIT SWITCH FACE HEATER DIGITAL INPUT CIRCUIT... -
Page 27: Limited Warranty
(87) months from the date of defective. shipment from Beverage-Air, provided upon receipt of the The labor warranty shall be for self-contained units compressor, manufacturer examination shows the sealed only and for standard straight time, which is defined as compressor to be defective. -
Page 28: Limited Warranty (Continued)
With the exception of Blast Chillers product is designed for LIMITATION OF LIABILITY: maintaining temperature and not bringing food to a desired Beverage-Air Corporation or their affiliates shall not be temperature therefore cannot be held responsible for this liable for any indirect, incidental, special or consequential function under warranty. - Page 29 User Manual for CT Freezer / Refrigerator Beverage-Air Warranty Registration Register your product online at beverage-air.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product Business Name: ____________________________________________________...
