USER'S GUIDE
Thermal Printer
MP-A40 SERIES
Read this USER'S GUIDE carefully before using the printer.
Keep this USER'S GUIDE in a place where it can be accessed
quickly.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-A40 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SII MP-A40 Series

Summary of Contents for SII MP-A40 Series

  • Page 1 USER'S GUIDE Thermal Printer MP-A40 SERIES Read this USER'S GUIDE carefully before using the printer. Keep this USER'S GUIDE in a place where it can be accessed quickly.
  • Page 2 Copyright 2016-2024 by Seiko Instruments Inc. All rights reserved. The information contained herein is the property of SII and shall not be reproduced in whole or in part without prior written approval of SII. SII reserves the right to make changes in the specifications and materials contained herein without notice and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical, arithmetic, and listing errors.
  • Page 3 This product may be used in following all EU and EFTA countries: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Netherlands EFTA Iceland, Norway, Switzerland, Liechtenstein Product:...
  • Page 4 Restrictions: Operations in 5150-5250 MHz band is for indoor use only. This product is for use only with nominal voltage in each country. Product: AC adapter PW-D0940-W2 Directive: Electromagnetic Compatibility Regulations 2016 Electrical Equipment (Safety) Regulations 2016 The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 Standards BS EN 55032 Class B BS EN ICE 61000-3-2...

  • Page 5: Table Of Contents

    Keep this manual in a safe place and available for future use whenever necessary See "MP-A40 SERIES THERMAL PRINTER TECHNICAL REFERENCE" for more detailed function and specifications on the printer. This manual consists of the following sections.

  • Page 6: Safety Precautions

    2. SAFETY PRECAUTIONS In this SAFETY PRECAUTIONS, the following symbols are used to ensure safe and proper use of products and prevent from damaging devices. WARNING Failure to follow the instructions marked with this symbol could result in severe personal injury or death. CAUTION Failure to follow the instructions marked with this symbol could result in minor personal injury or property damage.
  • Page 7 OPERATING PRECAUTIONS The "products" shall collectively mean the printer, the battery pack, the AC adapter, the AC cable, the car charger, and the battery charger. WARNING Never attempt the followings. Failure to follow the instructions leads to fire, electric shock, or accident. DO NOT disassemble or reconstruct the products.
  • Page 8 DO NOT expose the battery pack in a fire or heat it. DO NOT leave the battery pack under high temperature conditions such as in scorching heat, inside a car, or near a fire. It may cause leakage, overheating, rupture, or fire. DO NOT apply strong impact to the battery pack with a hammer or a nail, and DO NOT crush it.

  • Page 9: For Wireless Communication

    Procedures to take when in trouble Follow the instructions in the following cases. Failure to follow the instructions may lead to fire, electric shock, or accident. Turn off the printer, and unplug the AC plug from an outlet in any of the following cases. (In case of using the car charger, unplug the cigar plug from a car accessory socket.) And then, remove the battery pack.
  • Page 10 Observe the following instructions. Failure to follow the instructions may lead fire, electric shock, or accident. Turn off the products and unplug the AC plug from an outlet when not in use for a long time or before maintenance. And remove the battery pack from the printer or battery charger. DO NOT use or store the products in the following locations: Locations exposed to direct sunlight or high temperature such as in a car.

  • Page 11: Operating Precautions

    Charge battery pack (32°F to 104°F) (Non condensing) See "MP-A40 SERIES THERMAL PRINTER TECHNICAL REFERENCE" for the certifiable humidity range at each temperature. DO NOT install the products near devices that generate strong magnetism such as a copy machine ◆...
  • Page 12 Even if the AC adapter is connected with the printer during printing or communication using the ◆ battery pack as the power source, the power supply from the battery pack will continue until printing or communication is completed. If the printer suspends printing because the battery remaining capacity becomes low, connect the AC adapter and resume printing or communication.

  • Page 13: Precautions For Maintenance

    After using the car charger, be sure to unplug the cigar plug from a car accessory socket. ◆ DO NOT print out during vehicle driving. The ejected thermal paper may hinder the driving of the ◆ vehicle. DO NOT drop or insert any foreign objects such as clips, pins, and screws in the internal parts or ◆...

  • Page 14: Precautions On Discarding

    Precautions for storing Turn off the power when not in use. ◆ In addition, when the printer is not used for a long time, ・Unplug the AC plug from an outlet. ・Remove the battery pack from the printer. If not, it will cause overdischarge, and the battery pack will not be usable even after it is charged.

  • Page 15: Preparation

    4. PREPARATION Make sure that the printer and its accessories are contained. Keep the package and packing materials for future transportation or long-term storage.
  • Page 16 The available accessories are shown below. See "20. SPECIFICATIONS" and "21. ACCESSORIES AND CONSUMABLE PARTS", and be sure to purchase our specified products listed on these references.

  • Page 17: Identifying Model Type

    5. IDENTIFYING MODEL TYPE The printer model is identified as follows: MP-A40-x06JKxx Series Name Interface B : Bluetooth + USB W : Wireless LAN + USB Version Country/Region* U : USA, Canada E : EU, EFTA, UK, Turkey J : Japan *: The model with Wireless LAN only.

  • Page 18: Each Part Of Printer

    6. EACH PART OF PRINTER...
  • Page 19 1 POWER Switch 10 Paper outlet The POWER Switch turns the power on or off. Thermal paper is ejected from here. Two paper The POWER LED lights when turning on the cutters are installed: one is on the printer side, power.

  • Page 20: Led Indication Of Printer

    7. LED INDICATION OF PRINTER  LED Indication of Printer The 3 LEDs of the printer show the printer states. • ERROR LED and POWER LED Table 7-1 Printer States • WIRELESS LED Table 7-2 Bluetooth / Wireless LAN States Indication Table 7-1 Printer States ERROR LED...
  • Page 21 Table 7-2 Bluetooth / Wireless LAN States Indication WIRELESS LED Wireless Communication States Lighting Color Pattern Wireless off Connecting Blue Unconnected Blue Blink-2 Initializing wireless communication Blue Blink-4 In pairing mode* Blue Blink-3 *: Only for the model with Bluetooth and when its Inquiry Response in the Function Settings is set to Pairing Mode. Table 7-3 LED Blink Pattern States Pattern...
  • Page 22  Error and Recovery Procedure When an error occurs, the printer stops printing operation. However, the data receiving is enabled. The table below shows errors and their recovery procedures. Table 7-1 Error and Recovery Procedure Error Detail Recovery Procedure Priority The printer suspends The printer automatically resumes charging charging because the...

  • Page 23: Power Connection

    8. POWER CONNECTION There are 2 ways to supply power to the printer; from the battery pack or the AC adapter. While supplying power from the AC adapter, the printer can print without the battery pack. The AC cable is required for using the AC adapter. The car charger is only for charging.
  • Page 24 (1) Ensure that the power of the printer is off. (2) Insert the tab "a" of the battery pack into the groove "A" of the printer. Figure 8-2 Installing Battery Pack (2) (3) Press the battery pack in the direction of the arrow in Figure 8-3 until the tab "b" of the battery pack locks into the groove "B"...

  • Page 25: Removing The Battery Pack

    Removing the Battery Pack (1) Turn off the printer. (2) As shown in Figure 8-4, pressing the lever "c" of the battery pack in the direction of the arrow 1, remove it by pulling up in the direction of the arrow 2. Figure 8-4 Removing Battery Pack HINT •...
  • Page 26  Connecting AC Adapter to Printer (1) Turn off the printer. (2) Connect the AC cable to the AC adapter. (3) Connect the DC plug of the AC adapter to the power connector of the printer. (4) Connect the AC plug of the AC cable to an outlet. Then, the LED of the AC adapter lights up green. Figure 8-5 Connecting AC Adapter to Printer NOTE ◆...

  • Page 27: Loading Thermal Paper

    9. LOADING THERMAL PAPER The printer uses the thermal paper roll (hereinafter referred to as "thermal paper"). Use the thermal paper with printable surface rolled outwards. Four types of the thermal paper width can be used in the printer. For setting the paper width, see "13.
  • Page 28 (2) Load the thermal paper into the paper holder with its printing surface facing to the thermal head. If the setting direction is wrong, the printer cannot print. Printing surface Figure 9-2 Thermal Paper Setting Direction NOTE ◆ The printer has 2 paper cutters on the paper outlet: one is on the printer side, and the other is on the paper cover side.
  • Page 29 (5) When using the marked paper, press the FEED Switch once to feed the paper to the home position. In this case, the mark mode setting is needed. See "2.1.8 Mark (Paper) Sensor Specifications" in "MP-A40 SERIES THERMAL PRINTER TECHNICAL REFERENCE" for details of the mark mode setting, paper position or specifications.
  • Page 30  Thermal Paper Shape Always use the specified thermal paper. See "21. ACCESSORIES AND CONSUMABLE PARTS" for details. NOTE ◆ Use the thermal paper whose maximum diameter is φ58 mm or less. ◆ Use the thermal paper whose maximum width is equal or less than +0.5 mm including winding deviation.

  • Page 31: Test Print

    10. TEST PRINT The printer can perform a test print. In the test print, the firmware version, setting values of function settings, etc. are printed.  Test Print Procedure : Model with Bluetooth (1) Load the thermal paper in the printer as instructed in "9. LOADING THERMAL PAPER". Ensure that no error occurs, and then turn off the printer.
  • Page 32 (3) A message of mode selection is printed as shown in Figure 10-3 when the test print has completed. To return to the print-ready states, select "0 : Normal Mode". (Press the POWER Switch without pressing the FEED Switch.) To select other modes, press the FEED Switch for the number of times corresponding to the selected mode number, and then press the POWER Switch.
  • Page 33  Test Print Procedure: Model with Wireless LAN (1) Load the thermal paper in the printer as instructed in "9. THERMAL PAPER SETTING". Ensure that no error occurs, and then turn off the printer. (2) Hold the FEED Switch down and press the POWER Switch, then release the POWER Switch. Release the FEED Switch when the test print has been started.
  • Page 34 (3) A message of mode selection is printed as shown in Figure 10-5 when the test print has completed. To print Wireless LAN information, select "4 : Print WLAN Information". (Press the FEED Switch 4 times, and then press the POWER Switch.) The printer starts preparation for printing Wireless LAN information.
  • Page 35 After getting Wireless LAN information, Wireless LAN information is printed as an example shown in Figure 10-7. * WLAN Communication * Mode: Simple AP Radio: 802.11b/g/n Country: Channel: Auto SSID: SII-Printer Security: None DHCP Server: Enable MAC Address: XX:XX:XX:XX:XX:XX IP Address: 192.168.0.1 Subnet Mask: 255.255.255.0 Gateway Address: 0.0.0.0...
  • Page 36 (5) After the Wireless LAN information printing, the mode selection message is printed as shown in Figure 10-5. To return to the print-ready states, select "0 : Normal Mode". (Press the POWER Switch without pressing the FEED Switch.) To select other modes, press the FEED Switch for the number of times corresponding to the selected mode number, and then press the POWER Switch.

  • Page 37: Function Settings

    "SII Printer Setting Utility" included in “SII Software Package for Windows” ･For iOS and Android: App "SII Printer Utility" provided by App Store or Google Play  Procedure for Setting Functions Using Switches To set the functions using the switches, set the printer in the Setting Mode.
  • Page 38 (4) A message for selecting MS to be set is printed as shown in Figure 11-2 when the printer enters the Setting Mode. Press the FEED Switch the number of times corresponding to the selected MS number, and then press the POWER Switch. [MS Selection] 0 : Exit 1 : MS1...
  • Page 39 (6) A message for selecting the setting value of the selected function is printed as an example shown in Figure 11-4. Press the FEED Switch the number of times corresponding to the selected setting value number, and then press the POWER Switch. [Command System] 0 : Return to function selection 1 : ESC/POS...

  • Page 40: Connecting To Host Device

    12. CONNECTING TO HOST DEVICE The printer supports USB communication and Bluetooth communication or Wireless LAN communication. Select the model with Bluetooth or model with Wireless LAN depending on the communication method to use. • Model with Bluetooth (MP-A40-Bxxxxxx) : Bluetooth + USB •...

  • Page 41: Usb Communication

     USB Communication (1) Ensure that the power of the printer is off. (2) Connect the USB interface cable to the USB interface connector of the printer. (3) Turn on the printer, and send data from the host device to the printer. (4) Verify that the data is printed correctly.

  • Page 42: Bluetooth Communication

     Bluetooth Communication (1) When the USB interface cable is connected to the printer, disconnect it from the printer. (2) Turn on the printer and pair it with the host device. In the factory shipment state, the printer enters pairing mode for about 60 seconds by pushing the power switch for 7 seconds or more.
  • Page 43 In the factory shipment state, the function settings are as follows: Mode : Simple AP (simple access point) Communication Standard : IEEE802.11b/g/n (2.4GHz frequency range) SSID : SII-Printer Security : None DHCP Server : Enable Printer IP address : 192.168.0.1 (3) View the page "http://192.168.0.1"...

  • Page 44: Paper Width Setting

    13. PAPER WIDTH SETTING The printer can use thermal paper of 105 mm, 100 mm, and 80 mm in width by installing the partition plate and partition plate attachments included with the printer. The partition plate attachment (hereinafter referred to as attachment) has 2 types. Partition Plate Partition Plate Partition Plate...
  • Page 45  Installing Partition Plate This section describes how to install the partition plate and attachment for 80 mm paper width. (1) Turn off the printer. (2) Remove the battery pack from the printer. When the AC adapter is connected, unplug the AC plug of the AC cable from an outlet.
  • Page 46 • Ensure the tab "g" is fixed in the groove "G" (7) When the paper width is set by the partition plate, set the paper width in General Setting 3 (MS3) of the Function Settings. See "4.2 FUNCTION SETTINGS (MS)" in "MP-A40 SERIES THERMAL PRINTER TECHNICAL REFERENCE" for details.
  • Page 47  Removing Partition Plate Follow the below procedure to remove the partition plate from the printer. (1) Pull up the part "h" of the partition plate pressing in the direction of the arrow as shown in the figure below. Figure 13-7 Partition Plate Removal NOTE ◆...

  • Page 48: Installing Belt Clip / Shoulder Strap

    14. INSTALLING BELT CLIP / SHOULDER STRAP The belt clip and the shoulder strap convenient for carrying the printer can be attached to the printer. The belt clip is included with the printer. The shoulder strap is an optional accessory. See "21. ACCESSORIES AND CONSUMABLE PARTS", and be sure to purchase our specified products listed on the reference.
  • Page 49 (4) Rotate the belt clip 90 degrees. Figure 14-2 Belt Clip Installation (2) (5) Install the battery pack in the printer. (6) Hook the part "k" of the belt clip in Figure 14-3 to your belt. Figure 14-3 Belt Clip Installation (3) NOTE ◆...
  • Page 50  Installing Shoulder Strap (1) Pass the tip of shoulder strap through the installation hole of the printer as shown in Figure 14-4. Loosen the shoulder strap at the adjuster part. Figure 14-4 Shoulder Strap Installation (1) (2) Pass the tip of folded shoulder strap through the ring as shown in Figure 14-5. Figure 14-5 Shoulder Strap Installation (2)
  • Page 51 (3) As shown in Figure 14-6, pass the tip of shoulder strap through the adjuster hole on farther side from the printer. Figure 14-6 Shoulder Strap Installation (3) (4) As shown in Figure 14-7, pass the tip of shoulder strap through the adjuster hole on closer side from the printer.
  • Page 52 (5) As shown in Figure 14-8, install the other shoulder strap by the same procedure described (1) to (4). Tighten the looseness of adjuster part and adjust the length of the shoulder strap. Figure 14-8 Shoulder Strap Installation (5) NOTE ◆...

  • Page 53: Charging Battery Pack

    15. CHARGING BATTERY PACK The battery pack can be charged using the printer or battery charger. From the Printer Charged from an AC power supply using the AC adapter. Charged from an accessory socket of a car using the car charger. From the Battery Charger Charged from an AC power supply using the AC adapter.

  • Page 54: Normal Charging

    Normal Charging Before connecting the AC adapter, install the battery pack in the printer. (1) Ensure that the printer power is off. (2) Install the battery pack in the printer. (3) Connect the AC cable to the AC adapter. (4) Plug the DC plug of the AC adapter to the power connector of the printer. (5) Plug the AC plug of the AC cable to an outlet.
  • Page 55 Long Life Charging After connecting the AC adapter, install the battery pack in the printer. When the battery pack has already been installed, remove it from the printer. (1) Ensure that the printer power is off. (2) Connect the AC cable to the AC adapter. (3) Plug the DC plug of the AC adapter to the power connector of the printer.
  • Page 56 HINT • The printer can print or receive data while charging from the printer and AC adapter. During printing, the POWER LED indicates the battery remaining capacity continuously and the printer pauses charging. After printing is completed, the printer resumes charging, and the light of the POWER LED changes to orange.

  • Page 57: Charging From Car Charger

    16. CHARGING FROM CAR CHARGER The battery pack can be charged by connecting a car accessory socket and the printer using the car charger. The car charger is only for charging. Even if the car charger is connected to the printer, the printer cannot print without the battery pack.
  • Page 58  Each Part of Car Charger Figure 16-1 Each Part of Car Charger (CC-A12-A1) 1 DC Plug The DC plug connects to the power connecter. 2 Cigar Plug The cigar plug connects to a car accessory socket. 3 LED The LED indicates the activate state. The LED lights on green when the car engine is being run or accessory power is being provided.
  • Page 59 Normal Charging Before connecting the car charger, install the battery pack in the printer. Ensure that the car engine is running or accessory power is providing. (1) Ensure that the printer power is off. (2) Install the battery pack in the printer. (3) Connect the DC plug of the car charger to the power connector of the printer.
  • Page 60 Long Life Charging After connecting the car charger, install the battery pack in the printer. When the battery pack has already been installed, remove it from the printer. Ensure that the car engine is running or accessory power is providing. (1) Ensure that the printer power is off.
  • Page 61 HINT • The printer can print or receive data while charging from the printer and car charger. But note that the power for operating the printer is supplied from the battery. During printing, the POWER LED indicates the battery remaining capacity continuously and the printer pauses charging.

  • Page 62: Charging From Battery Charger

    17. CHARGING FROM BATTERY CHARGER The battery pack can be charged using the battery charger. To use the battery charger, the AC adapter and the AC cable are required. The battery pack, the AC adapter, the AC cable, and the battery charger are optional accessories. See "20.
  • Page 63  LED Indication of Battery Charger Table 17-1 Battery Charger States Battery Pack States Lighting Color Pattern Not installed Green Charging completed Green Charging Orange Charging battery temperature error Blink-2 Battery installation error Blink-3 Battery error Blink-4 Hardware error Table 17-2 Blink Pattern States Pattern 0.2s...
  • Page 64  Connecting Battery Charger and AC adapter This section describes how to connect the battery charger PWC-A071-A1 and the AC adapter. When the battery pack has already been installed, remove it from the battery charger. (1) Connect the AC cable to the AC adapter. (2) Plug the DC plug of AC adapter to the power connector of the battery charger.
  • Page 65  Charging Battery Pack from Battery Charger This section describes how to charge the battery pack from the battery charger PWC-A071-A1. The battery pack is installed to the battery charger in the direction as shown in Figure 17-4. The battery pack cannot be inserted in the wrong direction. Figure 17-4 Battery Pack Direction (1) Insert the tab "a"...
  • Page 66 (3) Make sure that the battery pack is installed to the battery charger correctly. • Ensure the tab "a" of the battery pack is inserted under the groove "A" of the battery charger. • Ensure the tab "b" of the battery pack is locked in the groove "B" of the battery charger. (4) The LED of the battery charger changes to orange, and then charging starts.

  • Page 67: Error Handling Procedure

     Error Handling Procedure Table 17-3 Error Handling Procedure Phenomenon Possible Cause Corrective Action The battery charger doesn't connect Securely connect the AC adapter to the power supply. and the AC cable. The AC adapter is failed or AC Replace the AC adapter or AC LED doesn't light up cable is broken.

  • Page 68: Mounting To Wall

     Mounting to Wall The battery charger can be mounted to a wall using the bottom holes shown in Figure 17-8. • Recommended screw: pan head screw 3 mm (head shape: φ5.5 mm, head size: 2 mm) Mounting Size 222 ±1 37 ±1 PWC-A074-A1 PWC-A071-A1...

  • Page 69: Printer Maintenance

    18. PRINTER MAINTENANCE The thermal head of the printer does not require user maintenance. When paper powder accumulates, cleaning the thermal head can maintain the print quality for an extended period of time.  Cleaning Thermal Head / Platen (1) Turn off the printer. (2) Remove the battery pack from the printer.

  • Page 70: Troubleshooting

    19. TROUBLESHOOTING Check the following points before requesting for repair:  The power does not turn on • Is the specified battery pack or AC adapter being used? • Is the battery pack sufficiently charged? • Is the battery pack installed correctly? •...

  • Page 71: Specifications

    IP54 *1: The number is for 1-byte character, and when character spacing is 0 dots. *2: See "MP-A40 SERIES THERMAL PRINTER TECHNICAL REFERENCE" for the certifiable humidity range at each temperature. *3: This number is test result based on SII procedures, not a guaranteed value.

  • Page 72: Battery Pack Specifications

     Battery Pack Specifications (Specified Accessories) Item Specifications Model BP-A0720-A1 Battery Lithium ion Rated voltage DC7.4 V Rated capacity 1950 mAh Operating temperature -20°C to 50°C (-4°F to 122°F) (printing) 0°C to 40°C (32°F to 104°F) (charging) Mass Approx. 119 g *: MP-A40-B06JK2 does not support this battery pack.

  • Page 73: Interface Specifications

     Car Charger Specifications (Specified Accessories) Item Specifications Model CC-A12-A1 Input voltage DC12.0 V, DC24.0 V Rated output DC12.0 V, 1.5 A Operating temperature 0°C to 40°C (32°F to 104°F) Dimensions (W × D × H) 107 mm × 38 mm × 20.4 mm* Mass Approx.
  • Page 74 AC Adapter Car Charger AC Cable Charger Japan CB-JP04-18A-E CC-A12-A1 CB-US04-18A-E Canada BP-A0720-A1 PWC-A071-A1 PW-D0940-W2 BP-A0720-B1 PWC-A074-A1 EFTA CB-CE01-18B-E Turkey CB-UK01-20A-E *: Ask your SII sales representative when you want to operate the products in countries/regions other than those listed above.

  • Page 75: Accessories And Consumable Parts

    Use the thermal paper whose maximum width is equal or less than the each paper width + 0.5 mm including winding deviation. *3: See "MP-A40 SERIES THERMAL PRINTER TECHNICAL REFERENCE" for details of the position and specifications of the mark and the size of the label sheet.

  • Page 76: Ms Settings List

    22. MS SETTINGS LIST : Default value General Setting 1 Value Function Interface Selection USB/Wireless (Interface) Mark Mode Selection Disable Enable (Mark Mode) 000B : ESC/POS 011B : HTML Command System Selection 1-3 to 5 (Command System) 100B : CPCL Other than those above: Prohibition Data Discard Selection When an Error Occurs Enable...
  • Page 77 General Setting 3 Value Function 011000B : 80 mm / 576 dots 101100B : 100 mm / 736 dots 110001B : 105 mm / 776 dots Paper Width Selection 3-1 to 6 (Paper Width) 111000B : 112 mm / 832 dots Other than those above : Prohibition (Setting value = (number of dots - 384) / 8 ) Reserved...
  • Page 78 Auto Power Off Time Setting Value Function Set in seconds Auto Power Off Time Setting (Total of higher 8 bits and lower 8 bits : (Auto Power Off Time) 7 to 8 0 to 65535 seconds, 0 : Disable) MS7 : Lower 8 bits Once Auto Deactivation Selection by AC MS8 : Higher 8 bits (MS2-8) is enabled : Disable...
  • Page 79 Command Setting Value Function JIS Code 13-1 Kanji Code System (Kanji Code) Shift-JIS Code 180° Reverse Function Selection Disable 13-2 Enable (Reverse Function) Reserved Fixed Fixed Reserved Fixed Reserved 13-3 to 8 Fixed Reserved Fixed Reserved Reserved Fixed International Character Setting Value Function 00000000B : USA...
  • Page 80 Character Code Table Setting Value Function 00000000B : USA, Standard Europe (Code Page 437) 00000001B : Katakana 00000010B : Multilingual (Code Page 850) 00000011B : Portuguese (Code Page 860) 00000100B : Canadian-French (Code Page 863) 00000101B : Nordic (Code Page 865) 00001101B : Turkish (Code Page 857) 00001110B : Greek (Code Page 737) 00010000B : Latin (Code Page 1252)
  • Page 81 Setting of Bluetooth Communication Value Function iOS Auto Connection Enable Disable (Auto Connection) Fixed Reserved Selected Searching Mode Pairing Mode Always (Inquiry Response) Selected Profile iAP2 (Profile) Fixed Reserved...
  • Page 82 7/F, Ying Tung Industrial Building, 802 Lai Chi Kok Road, Kowloon, Hong Kong Telephone:+852-2494-5111 Facsimile:+852-2424-0901 Seiko UK Ltd. (Authorized Representative in the United Kingdom) SC House, Vanwall Road, Maidenhead, Berkshire, SL6 4UW Download page:https://www.sii.co.jp/sps/eg/download/index.html (Specifications are subject to change without notice.)

This manual is also suitable for:

Mp-a40-b06jk1Mp-a40-b06jk2Mp-a40-w06jk1
