SII Color Painter W-64s Specifications

Better Color Density & Details At High Speeds
While other printers lose color density in dark areas and details as they reach high speeds, the ColorPainter W
prints accurate color densities - even at high speeds on dark images. The combination of high-viscosity inks and
advanced printheads produce razor sharp, crisp images in all print modes - retaining details and color density.
Multiple High-Speed Print Modes
Industry's Best Backlit Film Prints
Print at super high speeds with full color density, High density inks with higher pigment loading mean
or slow your printer down to achieve super high better, richer colors when you print backlit or frontlit
resolution. Only a ColorPainter W printer offers this films for light boxes. The ColorPainter W printers can
flexibility and the reliability to print high volumes print rich dark glossy blacks on standard backlit films,
when you really need it. You can also increase or making any menu or airport graphic stand out.
decrease levels of Smart Pass 3 Technology to fine
tune your printer for your exact application and image
requirements.
Print Mode Speed Drop Resolution Passes
Sizes
191 sfph
Production 3 540x360 4
17.8 m ph
2
128 sfph 128 sfph
Normal 2 540x540 6
Normal 2 540x540 6
11.9 m ph
11.9 m 2 2 ph
77 sfph
High Quality 1 720x720 8
7.2 m 2 ph
Maximum 51 sfph
1 900x900 10
Quality 4.7 m 2 ph
Speeds above are for ColorPainter W64s. ColorPainter W-54s would be slightly slower.
super fast print speeds,
with full color density
HAPs-Free & Low-Solvent Printers
Specifications W-64s W-54s
Print Heads
Industrial drop-on-demand piezo-electric
IP5-182
Number of Print Heads 4 (for 4 color configuration), 6 (for 6 color configuration)
IP5-153
Print Modes 900x900 dpi, 720x720 dpi, 540x540 dpi, 540x360 dpi
IP5-260
Print Speeds 26 - 191 sfph 22 - 182 sfph
IP5-262
2.4 - 17.8 m 2 ph 2.1 - 16.8 m 2 ph
IP5-263
Number of Nozzles 6 Colors: 254 nozzles x 6, 4 Colors: 254 nozzles x 4
IP5-265
Maximum Media Width 64" (1,626 mm) 54" (1,372 mm)
IP5-264
Maximum Print Width 63.6" (1,616 mm) 53.6" (1,362 mm)
IP-261
Recommended Media Weight
below 53 lbs/24kg
Maximum Media Diameter 7" (180 mm)
Maximum Media Length 164' (50 m)
GX Ink: Value-priced low-solvent
Paper Feed Method
Roll/Cut Media
ink with excellent color, glossiness,
Head Height 2 levels: .08"(2.1 mm) or .1" (2.6 mm) adhesion, dry-time, and long-term
outdoor durability.
Margin Size 1/5" (5 mm) when using roll without edge guard
Neon Ink: 2 UV Fluorescent inks that
Ink Types GX Low Solvent High-Viscosity Ink
glow under blacklight. Only compatible
IX Low Odor, HAPs-Free High-Viscosity Ink
with GX Inks.
Neon Inks For GX Only (Neon Yellow, Neon Pink)
Colors 4 Colors or 6 Colors
IX Ink: Low-odor, HAPs-Free
ink with excellent color,
Ink Capacity 500 milliliters per color
glossiness, adhesion, dry-time
Media Vinyl, banner, backlit films, textiles
and medium-term outdoor durability.
and other media designed for solvent printers
Built-in Heater 3-way independently controlled heater (front/ print/rear)
59°F (15°C) - 133°F (55°C)
A special-edition SIIT Onyx RIPCenter RIP is
Modes on Optional Take-up included. Most industry RIPs also support the
Tension, Loose, Inside, Outside
System ColorPainter W-64s & W-54s printers. Consult
with your authorized Reseller to identify the
Interface USB 2.0
best RIP for your needs.
Power Consumption 1350 W (in operation)
Power Voltage 110 VAC ± 10%
Operating Environment 59-86°F (15-30°C)
Seiko Instruments USA offers comprehesive
30-70% RH (no condensation)
support for all Seiko I Infotech products through
Storage Environment 5-35°C (41-95°F)
our factory-trained authorized resellers.
10-80% RH (no condensation)
By Phone:
External Dimensions 112" x 33" x 50" 102" x 33" x 50"
Real-time support is available Mondays
(W x D x H) (2,830 x 830 x 1,255 mm) (2,576 x 830 x 1,255 mm)
to Fridays (8:00am-5:00pm Pacific Time),
Weight
502 lbs (228 kg) 451 lbs (205 kg) excluding holidays. Tel: 760-781-5200 Option 3
Accessories Waste Ink Bottle, USB 2.0 cable, Wiper Sponge,
By E-Mail:
S/W RIP, CD w/User Manual & CP Manager SW
ColorPainterSupport@seikoinstruments.com.
Specifications are subject to change without notice. Please contact your local authorized SIIT product reseller.
Seiko Instruments USA, Inc.
Infotech Division
2067 Wineridge Place, Suite C
Escondido, CA 92029
1-800-264-1272
www.seiko-i.com
colorpainterinfo@seikoinstruments.com
ColorPainter is a trademark of Seiko I Infotech Inc. All other trademarks are the property of their respective owners.
F L E X I B L E R E L I A B L E H I G H - P E R F O R M A N C E W I D E - F O R M AT P R I N T E R S
O P T I O N A L A C C E S S O R I E S
Blower/Dryer Unit (54" & 64")
Take-Up Unit (64")
Take-Up Unit (54")
Cutter Unit (64")
Cutter Unit (54")
Exhaust Attachment
6 Color Upgrade Kit
2" Flange
I N K
R I P
S U P P O R T
HAPs-Free & Low-Solvent Printers
