SECTION 7: APPENDIX ......................................... 23 Warranty ........................................ 23 Bolt Torque ......................................24 PART BREAKDOWN LIST ........................................25 TMG-TMB72/90 Main Part Part List ..............................25 Rotor Assemble Part List ..................................33 Transmission Assemble part list ................................. 34 Hydraulic system Part list ..................................35 www.tmgindustrial.com...
IMPORTANT SAFETY INFORMATION Safety always Thoroughly read and understand the instructions given in this manual before operation. Refer to the “Safety Decal”, read all instructions noted on them. Do not allow anyone to operate this equipment who has not fully read and comprehended this manual and who has not been properly trained in the safe operation of the equipment.
Your Flail Mower comes equipped with all safety labels in place. They were designed to help you safely operate your implement. Read and follow their directions. Keep all safety labels clean and legible. Replace all damaged or missing labels. To order new labels go to your nearest TMG dealer www.tmgindustrial.com 4 / 36...
Page 5
Some new equipment installed during repair requires safety labels to be affixed to the replaced component as specified by TMG. When ordering new components make sure the correct safety labels are included in the request. Refer to this section for proper label placement. To install new labels: Clean the area the label is to be placed.
INTRODUCTION TMG welcomes you to the growing family of new product owners. This implement has been designed with care and built by skilled workers using quality materials. Proper assembly, maintenance, and safe operating practices will help you get years of satisfactory use from the machine.
Important: A special point of information related to its preceding topic. The intention is that this information should be read and noted before continuing. Owner Assistance The Warranty Registration card should be filled out by the dealer at the time of purchase. This information is necessary to provide you with quality customer service.
Remove the packing, check goods without defect and miss. Brush Mulcher without push bar Item Description Qty. Main body of the brush mulcher Push Bar Bracket TMG-TMB72 Push Bar Bracket Part No. Ref. No. Part Description Qty. FRM180.33 Bracket GB/T 5783 Bolt M12*45 GB/T 97.1...
Page 9
Push Bar Side Plate Part No. Ref. No. Part Description Qty. FRM225.13 Plate Push Bar Teeth Plate TMG-TMB72 Push Bar Teeth Plate Part No. Ref. No. Part Description Qty. FRM225.34 Teeth plate TMG-TMB90 Push Bar Teeth Plate Part No. Ref. No.
Packing List The detailed packing list of the mower and accessory as the following table. Item Description Qty. Package Form Brush Mulcher without push bar Steel Package Push Bar Bubble film Push Bar Side Plate Bubble film Push Bar Teeth Plate Bubble film PTO shaft None...
Page 11
Step2: Strike the Left pin shaft via the orange pin. Unit left side have enough space for push bar Left Side Right Side www.tmgindustrial.com 11 / 36 TOLL FREE: 1-877-761-2819...
Page 12
Step3: Installing push bar Left Side Plate in the space Step4: Strike Right side pin shaft via the orange pin, until Left pin pass through the left side plate. Right side have enough space for right Side Plate on the mean time. www.tmgindustrial.com 12 / 36 TOLL FREE: 1-877-761-2819...
Page 13
Step5: Strike Left side pin shaft via the orange pin, until Right pin pass through the left side plate. Step6: Lock the pin on both sides. Step7: Assembly the Bracket www.tmgindustrial.com 13 / 36 TOLL FREE: 1-877-761-2819...
Page 14
Step8: Assembly the Push Bar Teeth Plate Link the push bar to the cylinders www.tmgindustrial.com 14 / 36 TOLL FREE: 1-877-761-2819...
Tractor Hook-Up Be certain that tractor draw bar will not interfere. Move draw bar ahead or remove if required. Draw bar should also be checked for clearance when unit is being raised for the first time. Align lower link arms of tractor to hitch clevises on mower. Insert lower hitch pins into lower ball swivels and attach link pins.
SECTION 2: OPERATING INSTRUCTIONS Must add oil before first use. THE GEARBOX AND TRANSMISSION ARE SHIPPED WITHOUT OIL. ADD OIL BEFORE FIRST USE! Gear Oil SAE90 700ml Use T type socket wrench 17mm; Remover 6 pcs Bolt 10*30 on the orange cover. Open the orange cover, find the gearbox Add gear oil before first use.
Transporting NOTE: Always disengage PTO before raising mower to transport position. When raising the mower to transport position, be sure that driveline does not contact tractor or mower. Adjust and set the tractor’s 3-point hitch lift height so that the driveline does not contact mower deck in the fully raised position. Be sure to reduce tractor ground speed when turning, leaving enough clearance so that the mower does not contact obstacles such as buildings, trees or fences.
Hydraulic Push Bar Operation For smaller trees The push bar leans small trees over so that when they engage the mulching rotor, they do not fall on the carrier. For larger trees Retract the hydraulic top link or hydraulic cylinders of loader arms to rotate the mulcher back far enough so that all the tools contact the tree and begin to cut through it.
The hitch can also be adjusted from side to side by turning the adjustment handle. Turn handle until you have achieved your desired location. CAUTION Engage parking brake, shut off tractor, remove key and disengage PTO before making any height adjustments! Belt Tension CAUTION Belt drive system under spring tension;...
SECTION 4: MAINTENANCE AND LUBRICATION Maintenance Proper servicing and adjustment is the key to the long life of any farm implement. With careful and systematic inspection, you can avoid costly maintenance, time and repair. CAUTION For safety reasons, each maintenance operation must be performed with tractor PTO disengaged, mower lowered completely to ground and tractor engine shut off with ignition key removed.
Add oil until it flows from side plug hole. Do not overfill! IMPORTANT: Mower should be level when checking oil in gearbox! SECTION 5: SPECIFICATIONS & CAPACITIES TMG-TMB72 Model TMG-TMB90 70“...
This warranty does not apply to any part or product which in TMG’s judgment shall have been misused or damaged by accident or lack of normal maintenance or care, or which has been repaired or altered in a way which adversely affects its performance or reliability, or which has been used for a purpose for which the product not designed.
Claims under this warranty must be made to the dealer which originally sold the product and all warranty adjustments must be made through such dealer. TMG reserves the right to make changes in materials or design of the product at any time without notices.
Page 30
TMG-TMB72/90 Main Part Part List Part No. Ref. No. Part Description TMB72 TMB90 GB/T 12730-2018 V belt XPB1540 FRM225.10 Big Pulley JB/T 7934 Power lock 45*80 JB/T 7940.1 Grease nipple M10*1 M10X1-6X4 Connection FRM225.24 Grease tube 01 M6X1-6X4 Connection FRM225.41 Grease tube 02 FRM180.6...
Page 31
PUM180.10 Plate for bearing JB/T 7934 Power lock 60*90 FRM225.11 Small pulley GB/T 6182 Locking nut FRM225.32 Bushing FRM225.31 Chain 8mm FRM180.16 FRM225.16 FRM225.48 Plate for Gearbox FRM225.36 Cover for Gearbox GB/T 5783 Bolt M6*12 GB/T 93.1 Spring washer 6 GB/T 70.1 Plain washer 10 GB/T 6182...
Page 32
FRM225A.15 Skid 01 FRM225A.53 Hand weldment GB/T 62.1 Butterfly nut GB/T 5783 Bolt M12*70 FRM225A.19 Belt cover weldment FRM225A.40 Plate FRM225.30 LOGO plate weldment FRM225.23 Belt cover plate 02 FRM225A.42 Skid 02 FRM225A.50 Cover assemble GB/T 5783 Bolt M8*40 FRM225.26 Back cover weldment JB/T 7940.1 Grease nipple M6*1...
