PROFUCT MANUAL
Snow Plow Pusher
8.5 FT, U/V Angle Blade
MODEL: TMG-SP08
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your requests
WWW.TMGINDUSTRIAL.COM
Toll Free:1-877-761-2819
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TMG TMG-SP08
Summary of Contents for TMG TMG-SP08
- Page 1 PROFUCT MANUAL Snow Plow Pusher 8.5 FT, U/V Angle Blade MODEL: TMG-SP08 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...
-
Page 2: Table Of Contents
CONTENTS Safety operation warning ........................03 1. safety instructions Preparations before operation......................04 In operation............................05 After operation.............................06 2. Machine introduce Product parts name and function......................Product specifications......................... 3. Assembly work instruction Check after unpacking..........................10 Assembly of bracket and shovel.........................12 Installation of shovel cylinder........................13 Installation of bracket component ......................14 Installation of bracket assembly and bracket....................15 Installation of rubber components and three-point suspension..............16... - Page 3 Warning instructions for safe operation Meaning of warning labels NOTICE! Read the instruction manual carefully before using the machine. Failure to follow this warning may cause injury. WARNING ! Keep away from the cutting area of the running machine. If this warning is not followed, a personal injury accident may occur WARNING ! Keep a safe distance while driving the machine.
-
Page 4: Preparations Before Operation
1.Precautions for safe operation Read the operating instructions of the machine carefully, and be familiar with the performance and how to operate all the control devices! Understand all the safety labels on the equipment, and keep the labels clean. Please do not paint or move any safety labels casually. -
Page 5: In Operation
Before operation DANGER ! ★ Make sure that the snow shovel and the car (other) connecting frame have been connected. ★ Operate in a safe area. ★ Ensure that the snow shovel is installed firmly. ★ Ensure that all hydraulic joints and hydraulic devices are firmly connected. ★... -
Page 6: After Operation
After operation NOTICE ! ★ After the machine is used, the shovel body and joints should be cleaned with a high-pressure water gun. ★ Grease the exposed cylinder rod ★ Thoroughly remove all dirt, dirt and grease on the clean surface. ★... -
Page 7: Machine Introduce
2.Machine introduce Products part names and functions Right main shovel Protect the rubber assembly components Left main shovel assembly Hydraulic component Bracket assembly Bracket assembly WWW.TMGINDUSTRIAL.COM P07/27 Toll Free:1-877-761-2819... -
Page 8: Product Specifications
Products Specifications WWW.TMGINDUSTRIAL.COM P08/27 Toll Free:1-877-761-2819... - Page 9 Model No. TMG-SP08 Max Working Pressure 3050PSI Max Working Flow 8.0GPM Working Width 8.5ft(102”) Working Voltage DC 12V U blade up to 140 degree V blade up to 215 degree Blade Angle 22 degrees left or right Hydraulic Hose Diameter 1/4”(I.D)/1/2”(O.D)
-
Page 10: Assembly Work Instruction
3.Assembly work instruction 1. After unpacking, check the following components All numbers are not part numbers in the drawings. For correct part numbers, see explosive diagram WWW.TMGINDUSTRIAL.COM P10/27 Toll Free:1-877-761-2819... - Page 11 REF# SPECIFICATION REF# SPECIFICATION Left main shovel assembly Flat Washers Ø22 Right main shovel assembly Hex Bolts M20x120 Protection eraser Hex Bolts M20x110 Rubber splint Flat Washers Ø20 Rubber splint two Cylinder pin King pin shaft welded parts Cylinder head gasket 2 Shovel cylinder 50x32x255 Flat Washers Ø18 Hexagon lock nuts with...
-
Page 12: Assembly Of Bracket And Shovel
2. Assembly of bracket and shovel Installation steps: align the right main shovel(3), bracket(1), and left main shovel (4) in sequence and align them with the king pin shaft welded parts (A6), then adjust the hole position at the end of the king pin shaft to be perpendicular to the bracket, Then use M8*70 bolts (A7) to insert and fasten. -
Page 13: Installation Of Shovel Cylinder
3. Installation of shovel cylinder Installation steps: After installing the bracket, install the shovel cylinder(F11 according to the cylinder position in the above figure, and fix it with the cylinder pin(F12) and the split pin. Note: The oil port of the oil cylinder is facing upwards, and the position of the cotter pin of the oil cylinder pin is facing downwards. -
Page 14: Installation Of Bracket Component
4. Installation of bracket component Installation steps: 1. Align the mounting holes on the B1 and B2 pieces according to the style of the above figure, and then fix them with a pin with a flat washer and a lock nut. Note: Do not reverse the direction of the lower bracket assembly. -
Page 15: Installation Of Bracket Assembly And Bracket
5. Installation of bracket assembly and bracket Installation steps: 1. First align the Lower bracket welded parts (B1) with the hole on the Bracket Assembly (1) according to the style of the above figure, and then fix the cylindrical pin (B11) with the spring- type straight pin (B12) . -
Page 16: Installation Of Rubber Components And Three-Point Suspension
Part name and specification REF No Specification B1-B2 Bracket assembly Adjust the rod assembly Plain washer Ø20 Lock nut M20 Cylinder pin Spring-type straight pin 8×40 Hexagon head bolts M20×120 Plain washer Ø22 Lifting cylinder 40x22x160 Cylinder gasket Cylinder pin shaft (L=121) Plain washer Ø18 Lock nut M18 6. -
Page 17: Cylinder And Oil Pipe Connection
Installation steps: 1. Assemble the eraser in the order of the style above. 2. Install the three-point suspension according to the above figure with M16*50 bolts (G6) and flat washers (G4) and nuts (G5) to tighten, and finally fit the lock pin (G8) to insert the suspension connecting pin (G3) and the upper suspension pin (G2). - Page 18 oil pump). Importance: All bolts are locked in place without shaking. WARNING: Once the assembly bolts are not fastened in place, there will be abnormal noises when the machine is working. Inspection: Check whether each bolt is loose. Part name and specification REF No Specification Hydraulic manifold...
-
Page 19: Electrical Circuit Connection
8. Electrical circuit connection SOLENOID VALVE SWITCH CORTOL POWER INLET The solenoid valve head harness is fastened to the solenoid valve by inserting the phillips screws on the solenoid valve One end of the switch harness is connected to the conversion head of a section of the solenoid valve harness, and the other end is connected to the power supply. -
Page 20: Lubricating Grease
9. Lubricating grease WARNING Lubricate the bearing before each use, Otherwise, the service life of the machine will be affected Grease Nipple Grease Nipple Grease Nipple Grease Nipple WWW.TMGINDUSTRIAL.COM P20/27 Toll Free:1-877-761-2819... -
Page 21: Explosion Diagram And Product Parts
4.Explosion diagram and Product Parts 1.Explosive diagram of major components PART# DESCRIPTION PART# DESCRIPTION Bracket assembly Shovel as-left main Bracket assembly Shovel as-right main Rubber as-protection Hydraulic components 2.Explosive diagram of Bracket Assembly WWW.TMGINDUSTRIAL.COM P21/27 Toll Free:1-877-761-2819... - Page 22 PART# DESCRIPTION PART# DESCRIPTION Bracket weldment R pin Leg weldment Main pin shaft weldment Pipe plug Hexagon head bolts M8x70 Raker pin Lock nut M8 3.Explosive diagram of Bracket Assembly PART# DESCRIPTION PART# DESCRIPTION Lower bracket wedment Hexagon head bolts M20x110 Fear bracket weldment Adjusting plate Tie rod assembly...
- Page 23 4.Explosive diagram of As-protection PART# DESCRIPTION PART# DESCRIPTION Rubber splint II Plain washer Ø10 Rubber splint Full-thread hexagon bolts M10x30 Rubber sheet Lock nut M10 5.Explosive diagram of Shovel as-left main WWW.TMGINDUSTRIAL.COM P23/27 Toll Free:1-877-761-2819...
- Page 24 PART# DESCRIPTION PART# DESCRIPTION Left main shovel plate weldment Spring pin shaft weldment Grease nipple Spring Left rubber pressing plate Plain washer Ø14 weldment Rubber sheet Full-thread hexagon bolts M14x65 Front cover plate Lock nut M14 Cup head square neck bolts Full-thread hexagon bolts M12x60 M12x70 Plain washer Ø12...
- Page 25 7.Explosive diagram of Hydraulic Components PART# DESCRIPTION PART# DESCRIPTION Hydraulic cylinder 40X22X160 Cylinder pin Hydraulic manifold Split pin 5x40 Cylinder gasket Transition joints Cylinder pin shaft M18 x121 Combined sealing gaskets Hydraulic hose 1/2”x650mm with Plain washer Ø18 BSP G1/4 fitting Hydraulic hose 1/2”x600mm with Lock nut M18 BSP G1/4 fitting...
- Page 26 8.Explosive diagram of Three-point suspension PART# DESCRIPTION PART# DESCRIPTION Three point suspension welding Lock nut M16 Upper suspension pin Full-thread hexagon bolts M16x50 Suspension connecting pin Full-thread hexagon bolts M16x85 Plain washer Ø16 Lock pin WWW.TMGINDUSTRIAL.COM P26/27 Toll Free:1-877-761-2819...
- Page 27 9.Explosive diagram of Electrical circuit Specification Material Seven-pin plug for tractor Engineering plastics Single hole button box Engineering plastics Green button A38-11 self-locking Engineering plastics Button label box Engineering plastics Hydraulic solenoid valve coil plug Engineering plastics 12AWG small fuse holder Engineering plastics RVC2*1 Copper...
