Summary of Contents for Adrenaline DRAKONS MOTION DRK-106-2001
- Page 1 DRAKONS MOTION DRK-106-2001 Operation & Service Manual Version 4 .2 * Read this manual before use 2024-03-20...
-
Page 2: Table Of Contents
Table of Content Contents: Table of Contents General Remark Chapter 01 - Preface Chapter 02 - Game Features Chapter 03 – Unit Features Chapter 04 – Unit Installation Chapter 05 – Operator Menu Chapter 06 - Parts Chapter 07 – Diagrams & Schematics 59 Chapter 08 –... -
Page 3: General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your arcade product, we invite you to contact your local distributor or reach us at techsupport@aagmes.com or by calling our support line +1 (450) 824-1671 Adrenaline Amusements Team Adrenaline Amusements 2273 Antonio-Héroux Street Terrebonne, QC Canada... -
Page 4: Chapter 01 - Preface
● Do not block cooling vents. Precaution for Game Operation Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games. Operators should be aware that certain health and physical conditions may make people susceptible to injury when playing video games. - Page 5 If a power cord is damaged, it must be replaced by the equivalent power cord available from your distributor. Adrenaline Amusement Inc. assumes no liability for any damages or injuries incurred while setting up or servicing the cabinet. Only qualified service personnel should perform installation or service procedures.
-
Page 6: Environmental Conditions
Environmental Conditions Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating temperatures of 59° - 86°F (15° - 30°C). Electrical Power This game cabinet is shipped configured as either 120V or 220V and is not user switchable. Do not attempt to change the voltage switches on the power supplies to change the required voltage. -
Page 7: Chapter 02 - Game Features
Chapter 02 - Game Features Soar on a gigantic dragon, shoot enemies, and conquer new realms in this thrilling, high-flying RIDE. How to Play • Take Your Seat: Find your spot and grab hold of the turret directly in front of you. Take note of your assigned color (either blue or green). •... -
Page 8: Chapter 03 - Unit Features
Chapter 03 - Unit Features Cabinet facts & Dimensions for 2 players Hardware Features Depth Widht Height ● 2 Players Game 107" [2708 mm] 83,1" [2111 mm] 124" [3145 mm] ● Game control for each player ● 106 inches LED Screen Dept in Inch. -
Page 9: Chapter 04 - Unit Installation
Chapter 04 - Unit installation 2024-07-31... -
Page 10: Hardware Kit
Hardware kit Part Description Part Number Button Head Screw, Hex Drive, Black, 1/4-20x 1" BS-HRO-BS-1/4-20x1 Steel Header's Support, Drakons Header DRK-01-0100 Plastic Screen Corner For Drakon DRK-07-0061 Button Head Screw, Hex Drive, Round Head, Black Steel, M8 x 35MM BS-HH-BS-M8X35MM Button Head Screw, Hex Drive, Round Head, Black Steel, M8 x 45MM BS-HH-BS-M8X45MM Rounded Head Particle Board Screws, Quadrex, Black, #8 x 3/4''... - Page 11 How to assemble your DRAKONS - Motion 1) Start by removing the base cover. Unscrew the 5 black screws and lift the cover up, keep the screws for step 18. 2024-07-31...
- Page 12 2) Remove the Left and Right plywood brackets of Screen by unscrewing 4x M6 Allen Key Bolts and 4x M6 Philips Bolt and discard. 2024-07-31...
- Page 13 3) Straighten the Top Screen to its vertical position and maintain it in place. 2024-07-31...
- Page 14 4) Remove the Top Rear Door on the back of the screen. Untighten the 4 top screws of the rear panels. 2024-07-31...
- Page 15 5) Access the 2x M8 x 12mm screws already in place from inside the cabinet and tighten. TO INSTALL THE SCREWS, START AT THE POINT WHERE THE PANEL WAS REMOVED. YOU'LL THEN SEE THE LOCATION OF THE SCREWS! 2024-07-31...
- Page 16 6) Pull the top of the rear panels and remove the back doors of the screen cabinet in order to access the 2x M8 x 12mm screws under the top side of the screen. 2024-07-31...
- Page 17 7) Access the 2x M8 x 12mm screws already in place from inside the cabinet and tighten. 2024-07-31...
- Page 18 8) Screw back the Rear panels and the covers. 2024-07-31...
- Page 19 9) Before installing the screws, connect the Cables & Install the Right Led Assembly by tightening the 6x M8 x 35mm. 2024-07-31...
- Page 20 10) Before installing the screws, connect the Cables & Install the Left Led Assembly by tightening the 6x M8 x 35mm. 2024-07-31...
- Page 21 11) Install 4x Screen corner with 8x screws. 2024-07-31...
- Page 22 12) Install DRAKON HEADERS. Use 2x DRK-01-0100 WITH 8x BS-HRO-BS-1/4-20x1 2024-07-31...
- Page 23 13) Connect LED headers 2024-07-31...
- Page 24 14) Place the seat module in front of the screen. Make sure the distance between the screen module and the motion module is at least 24.5In (648mm) to ensure the installation of the Wire Cover Bridge. 2024-07-31...
- Page 25 15) Pass the wires through the protector and Install the wire cover bridge between BS-HRO-BS-1/4-20x1 the screen and the motion module. Starting by the Screen side Protector AAG-07-0010 2024-07-31...
- Page 26 16) Connect the cables and the air tube from the seat module to the screen module. -USB Cable -12V Power Cable -24V Power Cable -AIR Tube -Drain Valve cable 2024-07-31...
- Page 27 17) Secure the Wire Cover Bridge on both side with the motion module. BS-HRO-BS-1/4-20x1 2024-07-31...
- Page 28 18) Install the wire cover using five 10-24 3/4 screws and the base cover using the screws from step 1. 2024-07-31...
- Page 29 Plug-in 1) Plug the arcade into the power source, United States/Canada (120V) It’s important to connect the air compressor to a separate power intel without being on the same 15 Amp breaker. 2024-07-31...
- Page 30 Plug-in 1) Plug the arcade into the power source, International (220V). It’s important to connect the air compressor to a separate power intel without being on the same 15 Amp breaker. 2024-07-31...
- Page 31 Secured 2) When you are pleased by the arrangement of the machines, secure them by fixing all the leveling mounts of the arcade. 2024-07-31...
-
Page 32: Chapter 05 - Operator Menu
Chapter 05 – Operator Menu Operator Menu Access the Operator Menu by pressing the white operator menu button behind the coin door. 2024-07-31... - Page 33 Settings Operator Menu Values What It Does Adjusts the in-game audio volume. “0” will mute the Game Audio Volume 0-20 game. Adjusts the volume of the voice attract loop. Attract Audio Volume 0-20 “0” Will mute Language English/Français Switches the game and the menu’s language Resets the Inserted credits to 0 if more than 40 credits Clear Credits are entered.
- Page 34 Payments Operator Menu Values What It Does Swipes per Game 01-20 Set Price per Play Credit Sharing on/off Apply Credit on player #1 or #2 Changes the credit type: *Credit = Coins Payment Type Credit or Card *Card = Card Reader This will change the in-game text accordingly Resets the Inserted credits to 0 if...
- Page 35 Statistic For day-to-day Life cycle statistics of statistic, can be reset the game, cannot be by pushing the reset when pushing RESET STATS ICONS! RESET STATS ICONS! 2024-07-31...
-
Page 36: Network Option
Network option The left menu The left menu is a quick status overview of the state of the cabinet. This is the version number of the game software BUILD The unique ID of your machine DEVICE ID Pneumatic control board FIRMWARE SELECT THE DESIRED WIFI NETWORK! - Page 37 Diagnostic LINE AIR PRESSURE Adjust line pressure 50 PSI. +/- 5 PSI CENTER LINE SPRING PRESSURE Adjust spring pressure DISTANCE 1 Preset distance for installation DISTANCE 2 Preset distance for installation GYRO Calibrate Gyro FULL MOTION TEST Do not use VALVE STATUS Used to test valve manually VALVE TEST...
-
Page 38: Input Test
Input test THE SQUARE WILL TURN GREEN IF THE VALIDATION OF THE EQUIPMENT'S OPERATION IS POSITIVE. IF THE SQUARE REMAINS BLACK, CONTACT TECHNICAL SUPPORT TO DETERMINE THE SOURCE OF THE PROBLEM. 2024-07-31... -
Page 39: Sound Calibration
Sound Calibration PRESS THE ALL THE INDIVIDUAL ICONS TO CONFIRM THAT ALL COMPONENTS OF THE ACOUSTIC SYSTEM ARE FUNCTIONING CORRECTLY. 2024-07-31... -
Page 40: Valve Status
Valve Status *N.B. If you see a red indicator in the table, it is important to note that you have a fault. It is therefore important to contact technical support. EXAMPLE 2024-07-31... -
Page 41: Valve Test
Valve test *In this menu, if you need to modify the valve pressure, it is important to use the mouse to make the modification in order to select on D or I. 2024-07-31... -
Page 42: Chapter 06 - Parts
Chapter 06 - Parts Motion cabinet Part Description Part # Floor Melamine, Seat Cabinet, Drakon DRK-02-0010-01 Rear Right-Side Melamine, Seat Cabinet, Drakon DRK-02-0010-02 Rear Left Side Melamine, Seat Cabinet, Drakon DRK-02-0010-03 Front Right-Side Melamine, Seat Cabinet, Drakon DRK-02-0010-04 Front Left Side Melamine, Seat Cabinet, Drakon DRK-02-0010-05 Back Hinge Slot Melamine, Seat Cabinet, Drakon DRK-02-0010-06... - Page 43 Screen cabinet Part Description Part # Screen Cabinet Plywood Floor, Drakon DRK-02-0003-1 Left Side Screen Melamine Cabinet, Drakon DRK-02-0003-2 Right Side Screen Melamine Cabinet, Drakon DRK-02-0003-3 Melamine Top Screen Cabinet, Drakon DRK-02-0003-4 Back Screen for Screen Melamine Cabinet, Drakon DRK-02-0003-5 Melamine Screen Cabinet Front Panel Bottom Screen, Drakon DRK-02-0003-6 Cover Across Support Screen Melamine Cabinet, Drakon...
-
Page 44: Seat Assembly
Part Description Part # Seat assembly Rounded Head Screw, Phillips, Black M4-0.7X6MM MS-PRO-BS-M4-0.7X6MM Back Seat Led Cover NFSM-07-0017 Back Upper Arrow LED Shim NFSM-02-0006-01 Back Middle Arrow LED Shim NFSM-02-0006-02 Back Bottom Arrow LED Shim NFSM-02-0006-03 Seat Sticker Cover NFSM-09-0002 Top Seat Base NFSM-02-0002-01 Bottom Seat Base... -
Page 45: Plastic Parts
Plastic parts Part Description Part # Plastic Sheet Dash, Seat Cabinet, Drakon DRK-07-0010 Turrets Holder Plastic, Seat Cabinet, Drakon DRK-07-0042 Shim 3/4 Black PVC for Acrylic Sign DRK-07-0115 Acrylic Sign 0.220 Drakons Realm Keepers DRK-07-0114 Plastic Turrets Wire Cover, Seat Cabinet, Drakon DRK-07-0001 2024-07-31... - Page 46 Metal parts motion Part Description Part # Bottom Gun Holder Plate Right, Seat Cabinet, Drakon DRK-01-0036 Bottom Gun Holder Plate Left, Seat Cabinet, Drakon DRK-01-0035 Center Gun Bracket Left, Seat Cabinet, Drakon DRK-01-0037 Center Gun Bracket Right, Seat Cabinet, Drakon DRK-01-0038 Card Reader Plate, Seat Cabinet, Drakon DRK-01-0056...
- Page 47 Metal parts screen Part Description Part # Bridge Assy, Screen Cabinet, Drakon 106'' DRK-01-0200 Base Cover Front, Screen Cabinet, Drakon DRK-01-0007 Wire Cover Bracket NFSM-01-0004 Wire Cover Back Screen Cabinet, Drakon DRK-01-0083 Top & Bottom Screen Frame, Screen Cabinet, Drakon DRK-01-0042 Sides Screen Frame, Screen Cabinet, Drakon DRK-01-0044...
- Page 48 Headers parts Part Description Part # PVC FOAM SECOND SHIM 1 DRK-07-0009 PVC Foam First Shim, Drakons Header DRK-07-0002 PVC Foam Slogan Poster, Drakons Header DRK-07-0003 PVC Foam Letter's Fram, Drakons Header DRK-07-0004 PETG 1/8 DRAKONS LOGO LETTERS DRK-07-0005 ACRYLIC 0.218 DRAKONS DECORATION DRK-07-0006 LED STRIP PCB-14-0052-R1...
- Page 49 Electronics Screen Location Part Description Part # Pc Box for Drakon, With Asrock B660M and SSD ADR-11-1222-DRK Switching Power Supply, 24V, 320W, Low Profile AAG-13-0036 Switching Power Supply 12V, 500W AAG-13-0016 Board Support Snap Lock, 1/2'' AAG-05-0057 Power Bar, 5 Outlets INV-05-1242 Drakons Side Screen RGB Strip Starter AAG-14-0046...
- Page 50 Electronics Motion Location Part Description Part # Programmed Pneumatic Controller Board, Need for Speed AAG-04-0026-PROG-NFSM Motion RGB Led Controller Board Assembly 12V AAG-04-0026-PROG-NFSM Drakon Fuse Board AAG-04-0077 7.1 Audio Amplifier Board, Need for Speed AAG-04-0066 Board For Accelerometer and Gyroscope 3 Axes AAG-04-0038 7-Port USB, 3.0 Hub,Type A Female USB AAG-11-0011...
-
Page 51: Pneumatic System
Pneumatic system Part Description Part Number Accordion Seal, 0.65'' x 4'' With Steel AAG-05-0049 Center Bottom Plate, Need for Speed Motion DRK-01-0011 Upper Frame Weld, Drakon DRK-01-0020 Big Air Spring, Model : 2B6956, Need For Speed Motion AAG-05-0045 Small Air Spring, Model: 2B2200, Need for Speed Motion AAG-05-0044 2.0 Gallon Air Tank AAG-05-0041... -
Page 52: Mechanical Parts
Mechanical Parts Part Description Part # General Duty Rubber Caster, 2-1/2'' INV-F25083 Leg Leveler 1/2"-13 x 4" Thread, 2-3/8" Base Diameter INV-62805K-39 Grill 120mm ADR-GRILLE-120MM Cam Lock for Panel Thickness up to 23mm ADR-14-2010 6’’ Speaker Grill for Woofer AAG-13-0035 Black Steel Grill Clamp for Woofer AAG-01-0011 2024-07-31... -
Page 53: Sound System
Sound system Part Description Part # Round Black Speaker, 8 Ohm, 3.3'' AAG-13-0025 GSR 8SW-4 8’’ Poly Cone Subwoofer 4 Ohm ADR-292-480 Audio Bass Shaker 50 Watts AAG-13-0027 7.1 Audio Amplifier Board, Need for Speed AAG-04-0066 2024-07-31... -
Page 54: Electronic Boards
Electronic boards Part Description Part # Back seat Arrow, NFS AAG-14-0022 Back Seat RGB Strip Start, NFS AAG-14-0021 Side Seat RGB Strip, NFS AAG-14-0018 Front Seat RGB Strip, NFS AAG-14-0019 Back Seat RGB Strip End AAG-14-0020 Programmed Pneumatic Controller Board, Need for Speed Motion AAG-04-0026-PROG-NFS Board For Accelerometer and Gyroscope 3 Axes AAG-04-0038... - Page 55 Computer parts (ADR-11-1022-DRK) Part Description Part Number Metal Pc Box Casing For NFS AAG-01-0010 Power Supply 600W, (Or 500W) For PC Box AAG-11-0001 Motherboard Asrock, B660M, S1700,12TH AAG-11-0026 Crucial RAM, DDR4, 3200, 8GB, DIMM AAG-11-0025 Sapphire Video card, Radeon, RX6600, 8 GB, GDDR6 AAG-11-0023 Restore Usb Key Drakons, ASROCK B660M ADR-11-2014-DRK...
- Page 56 Miscellaneous electronics part Part Description Part Number Power Bar 5 positions INV-05-1242 Switching Power Supply 12V, 320W AAG-13-0029 Switching Power Supply 24V, 320W AAG-13-0028 Kit for Fan 138CFM With Harness, 120mm ADR-FAN-120MM-02-KIT Miniature Round Pushbutton, White Center ADR-49-0577-01 Meter, 12V, 7 Digit with Bracket ADR-42-08012-072 7-Port USB, 3.0 Hub, Type A Female USB AAG-11-0011...
- Page 57 Turret. ( DRK-06-0002) Part Description Part Number Plastic Turret Body For Drakons DRK-07-0085 Plastic Turret Ornament Center Ring For Drakons DRK-07-0021 Plastic Turret Ornament Front Ring For Drakons DRK-07-0022 Plastic Turret Ornament Rear Ring For Drakons DRK-07-0029 Plastic Turret Ornament Left Side Cover For Drakons DRK-07-0030 Plastic Turret Ornament Right Side Cover For Drakons DRK-07-0031...
- Page 58 Turret Mechanism Assembly Parts. (DRK-06-0002) Part Description Part Number Controller With Grips (No PCBs), Drakons AAG-13-0033 Board For Turret Controller Programmed AAG-04-0074-PROG Drakons Turret RGB Ring AAG-14-0050 HDPE Turret Led Shim DRK-07-0044 LED's Base DRK-01-0072 Drakons Turret RGB U-Shape AAG-14-0051 Right Side Solenoid's Holder DRK-07-0112 Left Side Solenoid's Holder...
- Page 59 Door Part Description Part Number Round Corner Blank Door Only ADR- 42-3145-100C15 2024-07-31...
-
Page 60: Chapter 07 - Diagrams & Schematics
Chapter 07 – Diagrams & Schematics 2024-07-31... - Page 61 2024-07-31...
- Page 62 2024-07-31...
- Page 63 2024-07-31...
- Page 64 2024-07-31...
- Page 65 2024-07-31...
- Page 66 2024-07-31...
- Page 67 2024-07-31...
- Page 68 2024-07-31...
- Page 69 2024-07-31...
- Page 70 2024-07-31...
- Page 71 2024-07-31...
-
Page 72: Chapter 08 - Software Recovery
Chapter 08 – Software Recovery If your unit software needs to be restored, please follow those instructions. -Connect a USB keyboard to the motherboard. -Connect the provided USB Recovery flash disk is in a Black USB port. -Power on the unit and press F11 on the keyboard to display the boot menu. -Choose the UEFI: USB device ~16GB The process takes 25-30 minutes, and the unit will reboot back in the game at the end. -
Page 73: Chapter 09 - Card Reader
Chapter 09 – Card Reader CARD READER POSITION & CONNECTION 1) Remove panel & install the card reader on the central panel between the turret. 2024-07-31... - Page 74 2) Connect the wires to the appropriate places. 12v #1 CONNECTION DIAGRAM Coin in #2 Ground #9 2024-07-31...
-
Page 75: Chapter 10 - Troubleshooting
Chapter 10 – Troubleshooting * NOTE: When requesting a warranty replacement, you will be asked to give the unit’s serial number from the back of the unit. Video Troubleshooting There might have loose or faulty connections between the monitor and the computer. Make sure the HDMI cable is connected properly in the computer’s video card and in the monitor connector. - Page 76 If the sound still not playing in all the speakers, please do the following procedure: 1. Right click on the sound icon in the task bar and select “Open Sound settings.” 2024-07-31...
- Page 77 2. Click on the “Sound Control Panel”. 2024-07-31...
- Page 78 3. Select “Speakers USB Sound Device” and click on “Configure”. 2024-07-31...
- Page 79 4. Select “7.1 Surround ” and click on “Next”. 2024-07-31...
- Page 80 5. Click on “Finish” 2024-07-31...
- Page 81 Computer not powering at boot. If your computer is not powering on by itself at boot, you’ll need to verify the Bios Setting. -Power off the computer. -Plug a USB keyboard and a USB mouse. -Press the power button on the computer. -Press and hold F2 on the keyboard until you see the Bios screen.
- Page 82 -Press on F6 or using a mouse click on advanced. 2024-07-31...
- Page 83 -Then click on Chipset Configuration. 2024-07-31...
- Page 84 -Go to the bottom of that page, click/select the line Restore AC Power Loss, click on the drop box where it displays (Power Off) and select Power On. 2024-07-31...
- Page 85 -On your keyboard press on and then click on YES to confirm and save the settings. Or go to the Exit tab, click save and Exit. 2024-07-31...
-
Page 86: Limited Warranty Policies
Improper servicing or abuse will VOID existing warranties. All warranty request needs to be validated with our technical support department. After the 1-year warranty, Adrenaline Amusements offers repairs & sales services options. Please contact the technical support department for information.
