Heat Takedown
NFS-43-1001
Operation & Service Manual
Version 1.0.1
* Read this manual before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NFS Heat Takedown NFS-43-1001 and is the answer not in the manual?

Questions and answers

Related Manuals for Adrenaline NFS Heat Takedown NFS-43-1001

Summary of Contents for Adrenaline NFS Heat Takedown NFS-43-1001

  • Page 1 Heat Takedown NFS-43-1001 Operation & Service Manual Version 1.0.1 * Read this manual before use...

  • Page 2: General Remark

    If you encounter any difficulties or if you need support on how to update and/ or install your Hot Wheels King of the Road product, we invite you to contact your local distributor or reach us techsupport@aagmes.com or by calling our support line +1-450-824-1671 Adrenaline Amusements Team Adrenaline Amusements 2273 Antonio-Héroux street Terrebonne, QC...

  • Page 3: Table Of Contents

    NFS Heat Takedown V1.0.1 Table of Contents Contents General Remark ....................2 Table of Contents ....................3 Chapter 01 - Preface ................... 4 Chapter 02 - Game Features ................6 Chapter 03 – Unit Features ................. 7 Chapter 04 – Unit Installation ................9 Chapter 05 –...

  • Page 4: Chapter 01 - Preface

    • Do not block cooling vents. Precaution for Game Operation Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games. Operators should be aware that certain health and physical conditions may make people susceptible to injury when playing video games.
  • Page 5 If a power cord is damaged, it must be replaced by the equivalent power cord available from your distributor. Adrenaline Amusement Inc. assumes no liability for any damages or injuries incurred while setting up or servicing the cabinet. Only qualified service personnel should perform installation or service procedures.

  • Page 6: Chapter 02 - Game Features

    NFS Heat Takedown V1.0.1 Chapter 02 – Game Features Chapter 02 - Game Features Are you fast enough to scape the cops? Do you have the skills to take the wheels and drift? Push the Nitrous and takedown your enemies on the streets and become the king of Palm City. How to Play •...

  • Page 7: Chapter 03 - Unit Features

    NFS Heat Takedown V1.0.1 Chapter 03 – Unit Features Chapter 03 – Unit Features Hardware Features • 1 to 4 Players Game • Steering wheels & accelerator pedals for each player • 43 inches LCD Screen Cabinet Facts – 1 player version Cabinet Dimensions Depth = 65.87”...
  • Page 8 NFS Heat Takedown V1.0.1 Chapter 03 – Unit Features Cabinet Facts – 4 players assembly Cabinet Dimensions Depth = 65.87” [1673.1mm] Width = 161.27” [4.096.3mm] P a g e...

  • Page 9: Chapter 04 - Unit Installation

    NFS Heat Takedown V1.0.1 Chapter 04 – Unit Installation Chapter 04 – Unit Installation How to assemble your NFS Heat Takedown Remove the four screw who hold the two steel bars inside and take them out.. Install back the steel bars as show on the picture. Move the seat module towards the large cabinet Connect all three cables coming from the seat to the cabinet.
  • Page 10 NFS Heat Takedown V1.0.1 Chapter 04 – Unit Installation In order to secure the seat to the cabinet, Push the seat until the steel bars are completely inserted. Using the ¼-20 screws, secure the seat in each side. Push the screen up and secure it by installing the two 1/4 screws from the inside. 10 | P a g e...
  • Page 11 NFS Heat Takedown V1.0.1 Chapter 04 – Unit Installation How to assemble and connect two or more NFS Heat Takedown 1) Place the machines beside each one. The first arcade to the left will be the player #1. 2) When you are pleased by the arrangement of the machines, secure them by fixing all the leveling mounts of each arcade.
  • Page 12 NFS Heat Takedown V1.0.1 Chapter 04 – Unit Installation Multiplayer network connection 3) connect all the arcades to the network hub. 4) start the arcades, access to the operator menu, and change one by one the Machine ID. (To know how to get access to the operator menu, go to chapter 5.) 12 | P a g e...

  • Page 13: Chapter 05 - Operator Menu

    NFS Heat Takedown V1.0.1 Chapter 05 – Operator Menu Chapter 05 – Operator Menu Operator Menu Access the Operator Menu by pressing the white operator menu button behind the coin door. 13 | P a g e...
  • Page 14 NFS Heat Takedown V1.0.1 Chapter 05 – Operator Menu SETTINGS Operator Menu Values What It Does Adjusts the in-game audio volume. “0” will mute the game. Game Audio Volume 1-20 Adjusts the volume of the voice attract loop. “0” will mute Attract Audio Volume 0-20 Switches the game and the menu’s language...
  • Page 15 NFS Heat Takedown V1.0.1 Chapter 05 – Operator Menu PAYMENT Operator Menu Values What It Does Credit per Game 1-20 Set Price per Play Changes the credit type. “Credits” = Coins and Payment Type Credit / Card “Card” = Card Reader. This will change the in-game text accordingly.
  • Page 16 NFS Heat Takedown V1.0.1 Chapter 05 – Operator Menu Network Connections The left menu The left menu is a quick status overview of the state of the cabinet. BUILD This is the version number of the game software DEVICE ID The unique ID of your machine TYPE This will tell you if this machine is the server or a client...
  • Page 17 NFS Heat Takedown V1.0.1 Chapter 05 – Operator Menu Multiplayer status The upper part of this screen will indicate the status of your cabinets. Red cabinet indicates that this cabinet is not plugged to the rest of the network via the network switch and green indicates that everything is fine.

  • Page 18: Chapter 06 - Parts

    NFS Heat Takedown V1.0.1 Chapter 06 – Parts Chapter 06 - Parts Seat base Part Description Part # Seat Melamine Black Top NFS-02-0002-04 Top Rear Bracket, Seat Cabinet NFS-01-0017 Seat Printed Melamine Back NFS-02-0002-05 Angle Leg Support, 1/2-13 RAC-01-0140 Seat Melamine Black Inside Sides R/L NFS-02-0002-07 Seat Printed Melamine Left Side NFS-02-0002-02...
  • Page 19 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Seat base 19 | P a g e...
  • Page 20 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Part Description Part # Cabinet Melamine Top NFS-02-0010-05 Cabinet Melamine Front Up NFS-02-0010-06 Cabinet Melamine Back Thin Screen NFS-02-0010-31 Cabinet Printed Melamine Right Side NFS-02-0010-09 Cabinet Melamine Front Screen Bottom Mounting NFS-02-0010-23 Cabinet Melamine Speaker Mounting NFS-02-0010-02 Cabinet Melamine Cash Door Side Panel...
  • Page 21 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Seat assembly 21 | P a g e...
  • Page 22 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Part Description Part # Rounded Head Screw, Phillips, Black M4-0.7X6MM MS-PRO-BS-M4-0.7X6MM Back Seat Led Cover, Need for Speed Motion NFSM-07-0017 Back Upper Arrow LED Shim, Need for Speed NFSM-02-0006-01 Back Middle Arrow LED Shim, Need for Speed NFSM-02-0006-02 Back Bottom Arrow LED Shim, Need for Speed NFSM-02-0006-03...
  • Page 23 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Plastic Parts Part Description Part # Top Screen Cover, Need for Speed NFS-07-0021 Diffuser For Police Thermoformed Header NFS-07-0021-DIFF Side Screen Cover R/H, Need for Speed NFS-07-0010 RPM Plastic for Dash, Need for Speed NFS-07-0037 Dash, Need for Speed NFS-07-0005...
  • Page 24 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Metal Parts Part Description Part # Top Rear Plate Center NFS-01-0023 Side Led Bracket NFS-01-0005 Steering Wheel Support NFS-01-0020 Checker Plate Cabinet Floor NFS-01-0026 Camera Bracket NFS-01-0015 Top Rear Plate NFS-01-0022 Rear Panel Cover NFS-01-0027 Bottom Rear Bracket NFS-01-0018...
  • Page 25 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Header Part Description Part Number Display Module, 64x32', RGB LED - 4mm pitch AAG-14-0004-DISPLAY Header’s Frame NFS-07-0044 Programmed Led Matrix Card, Receiving Card AAG-14-0032-PROG Header’s Back Plate NFS-07-0043 Header’s Corner Brace NFS-01-0043 Switching Power Supply 5V, 200W, 110/220V Manual Selection AAG-13-0031 Header’s Shim...
  • Page 26 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Mechanical Parts Part Description Part # General Duty Rubber Caster, 2-1/2'' INV-F25083 Leg Leveler 1/2"-13 x 4" Thread, 2-3/8" Base Diameter INV-62805K-39 Grill 120mm ADR-GRILLE-120MM Cam Lock for Panel Thickness up to 23mm ADR-14-2010 8’’...
  • Page 27 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Electronic boards Part Description Part # Programmed I/O Board Assembly With 4 Analog Input For NFS AAG-04-0076-PROG-NFS 12V RGB LED Controller with Outputs AAG-04-0015-12RL Back seat Arrow, NFS AAG-14-0022 Push-Button RGB Led Ring, NFS AAG-14-0011 Left Side Dash white LEDs, NFS AAG-14-0025...
  • Page 28 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Monitor AND LED Parts Part Description Part # 43'' Monitor for NFS AAG-10-0004 Screen Tempered Protective Glass, Need for Speed NFS-10-0001 Screen's Power Supply Protector NFS-07-0050 HDMI Card for Monitor VG85-13652-10 AAG-04-0069 HDMI Card for Monitor VG85-13652-10 AAG-04-0070 Power-Supply for Monitor VG85-13652-10...
  • Page 29 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Computer parts Part Description Part Number Led Matrix Controller – sending card AAG-14-0039 T901 PC Card Power Cable AAG-03-0185 Metal Pc Box Casing For NFS AAG-01-0010 Power Supply 600W, (Or 500W) For PC Box AAG-11-0001 Motherboard Asrock, B660M, S1700,12TH AAG-11-0026...
  • Page 30 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Miscellaneous electronics parts Part Description Part Number Power Bar 5 positions INV-05-1242 Multi-Stage Filter 10A ADR-817-1321-ND Switching Power Supply 12V, 320W AAG-13-0029 Switching Power Supply 24V, 320W AAG-13-0028 Kit for Fan 138CFM With Harness, 120mm ADR-FAN-120MM-02-KIT Miniature Round Pushbutton, White Center ADR-49-0577-01...
  • Page 31 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Steering wheels Part Description Part Number Steering Wheel with Motor Assembly AAG-13-0002 Center Wheel Sticker, Need for Speed NFS-09-0003 Dual Pedal With Potentiometer On Gas, Need for Speed AAG-13-0023 Steering Mechanism Assembly Parts available from Suzohapp 31 | P a g e...
  • Page 32 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Doors Part Description Part Number Door Assembly with Two Upper Mech Holder, Round Corner, Universal Logo ADR-40-0038-KA Door and Frame Assembly with Blank Upper and Bottom Door, Round Corner ADR-40-0128-00KA Door Assembly with One Upper Mech Holder, Round Corner, Universal Logo, ADR-40-0512-06NMKA NO Bottom Door Round Corner Blank Door Only...
  • Page 33 NFS Heat Takedown V1.0.1 Chapter 06 – Parts Hardware Kit Part Description Part # Button Head Hex Drive Screw, 3/8"-16 Thread, 2-1/2" Long BS-HRO-BS-3/8-16x2-1/2 Round Head, Machine Screw, Phillips/ Quadrex, 1/4-20X3'' MS-PRO-ZS-1/4-20X3 Flat Washer, 1/4'', USS, Zinc FW-Z-1/4-USS Keyboard + Mouse INV-11-1015 33 | P a g e...

  • Page 34: Chapter 07 - Diagrams & Schematics

    NFS Heat Takedown V1.0.1 Chapter 07 – Parts Chapter 07 – Diagrams & Schematics Computer section Figure 8.1 : Computer interconnection diagram 34 | P a g e...
  • Page 35 NFS Heat Takedown V1.0.1 Chapter 07 – Parts Figure 8.2: Computer connections Item Description AC Power Inlet USB port to USB hub USB port to Windows license dongle Ethernet network port HDMI port connected to DVI port (Item 6) DVI port connected to (Item 5) Display port to 43"...
  • Page 36 NFS Heat Takedown V1.0.1 Chapter 07 – Parts 12V/24V Power distribution The following figure shows all the items connected to the fuses board. Harnesses’ part numbers are specified in red. Figure 8.4: 12V/24V power distribution diagram 36 | P a g e...
  • Page 37 NFS Heat Takedown V1.0.1 Chapter 07 – Parts I/O board section The following figure shows all the items connected to the IO board. Figure 8.5: I/O board interconnection diagram 37 | P a g e...
  • Page 38 NFS Heat Takedown V1.0.1 Chapter 07 – Parts Figure 8.6: I/O board connectors locations Pin Definition: J1: Operator Button (AAG-03-0160) Definition OPER. Color BLACK J3: Boost Button (AAG-03-0147) Definition OUTB OPTOB Color BLACK WHITE GREEN *Note: pin 1-2 push-button light, pin 3-4 push-button contact. J4: Brake Pedal switch (AAG-03-0144) Definition OPTOB...
  • Page 39 NFS Heat Takedown V1.0.1 Chapter 07 – Parts J6: Gaz Pedal potentiometer (AAG-03-0145) Definition V.POT S.POT Color WHITE BLACK J9: Steering wheel motor (AAG-03-0146) Definition Color BLACK J11: 24V Supply (AAG-03-0159) Definition Color BLACK J12: 12V Supply (AAG-03-0159) Definition Color BLACK J13: Coin Door (AAG-03-0136) Definition...
  • Page 40 NFS Heat Takedown V1.0.1 Chapter 07 – Parts Coin door wiring connection Figure 8.7: Coin door harness AAG-03-0136 Connection Chart Wire color From Function Green P1-1 12V coin counter Brown P1-2 Coin counter output 2 Orange P1-3 Coin counter output 1 Blue P1-4 P5-P6...
  • Page 41 NFS Heat Takedown V1.0.1 Chapter 07 – Parts Audio section Figure 8.8: Audio connection diagram 41 | P a g e...
  • Page 42 NFS Heat Takedown V1.0.1 Chapter 07 – Parts Figure 8.9: Audio amplifier connector location Pin Definition: J18: 24V Supply (AAG-03-0139) Definition Color BLACK BLACK J23: Shaker, Subwoofer & seat speakers (AAG-03-0137) Definition SHAKER+ SUB+ SEAT L+ SEAT R+ Color Definition SHAKER- SUB- SEAT L-...
  • Page 43 NFS Heat Takedown V1.0.1 Chapter 07 – Parts Dip-switch settings: SW1-1 SW1-2 SW1-3 SW1-4 SW2-1 SW2-2 SW2-3 SW2-4 SW3-1 SW3-2 SW3-3 SW3-4 SW4-1 SW4-2 SW4-3 SW4-4 Led controller section. Figure 8.10: Led controller connection diagram. 43 | P a g e...
  • Page 44 NFS Heat Takedown V1.0.1 Chapter 07 – Parts Figure 8.11: Led controller connector location. Pin description J4: 12V Supply (AAG-03-0158) Definition Color BLACK J9: Police backlight red & blue (AAG-03-0143) Definition OUT1 OUT2 Color BLACK BLACK *Note: pin 1-2 red police, pin 3-4 blue police. J5: Seat RGB strip lower row "CH4"...

  • Page 45: Chapter 08 - Software Recovery

    NFS Heat Takedown V1.0.1 Chapter 08 – Software Recovery Chapter 08 – Software Recovery If your unit software needs to be restored, please follow those instructions. Connect a USB keyboard to the motherboard. Connect the provided USB Recovery flash disk is in a Black USB port. Power on the unit and press F11 on the keyboard to display the boot menu.

  • Page 46: Chapter 09 - Card Reader

    Configure your Operator settings as seen in Chapter 5 - Operator Menu. Embed System If you are using an Embed system, you need to connect your harnesses to Adrenaline Amusements I/O board & harnesses. You should refer to the Embed instructions manual for wiring pin-out.

  • Page 47: Chapter 10 - Troubleshooting

    NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair Chapter 10 – Troubleshooting Troubleshooting * NOTE: When requesting a warranty replacement, you will be asked to give the unit’s serial number from the back of the unit. Video Troubleshooting There might have loose or faulty connections between the monitor and the computer.
  • Page 48 NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair If the sound still not playing in all the speakers, please do the following procedure: 1. Right click on the sound icon in the task bar and select “Open Sound settings.” 2.
  • Page 49 NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair 3. Select “Speakers USB Sound Device” and click on “Configure”. 4. Select “5.1 Surround” and click on “Next”. 49 | P a g e...
  • Page 50 NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair 5. Select “Center”, “Subwoofer”, “Rear pair” and click on “Next”. 6. Select “Front left and right”, “Surround speakers” and click on “Next”. 50 | P a g e...
  • Page 51 NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair 7. Click on “Finish” 51 | P a g e...
  • Page 52 NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair Computer not powering at boot. If your computer is not powering on by itself at boot, you’ll need to verify the Bios Setting. -Power off the computer. -Plug a USB keyboard and a USB mouse. -Press the power button on the computer.
  • Page 53 NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair -Then click on Chipset Configuration. -Go to the bottom of that page, click/select the line Restore AC Power Loss, click on the drop box where it displays “Power Off” and select Power On. 53 | P a g e...
  • Page 54 NFS Heat Takedown V1.0.1 Chapter 10 – Service & repair -On your keyboard press on and then click on OK to confirm and save the settings. Or go to the Exit tab, click save and Exit. 54 | P a g e...

  • Page 55: Limited Warranty Policies

    This unit has a 1-year warranty against defective hardware from date of delivery. Other than abuse or improper servicing, Adrenaline Amusements covers at no charge the replacement parts including standard shipping. We offer an advanced replacement program, and the customers have 30 days from delivery date to return back the defective equipment at their fees or they will be charged automatically for the replacement parts.
