PT Instruções para uso / Manual de Instalación
ES Modo de empleo / Instrucciones de montaje
EN Instructions for use / assembly instructions
DE Gebrauchsanleitung / Montageanleitung
2
3
4
5
Metris 110
31084010
Metris 260
31082010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Metris 110 31084010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hans Grohe Metris 110 31084010

  • Page 1 PT Instruções para uso / Manual de Instalación ES Modo de empleo / Instrucciones de montaje EN Instructions for use / assembly instructions DE Gebrauchsanleitung / Montageanleitung Metris 110 31084010 Metris 260 31082010...
  • Page 2 Português Avisos de segurança Descrição do símbolo Durante a montagem devem ser utilizadas luvas de Não utilizar silicone que contenha ácido acético! protecção, de modo a evitar ferimentos resultantes de entalamentos e de cortes. Afinação (ver página 8) O sistema de duche só pode ser utilizado para fins Ajuste do limitador de água quente. Em de higiene pessoal. combinação com um esquentador, não é Grandes diferenças entre as pressões das águas recomendável o uso de um bloqueio de quente e fria devem ser compensadas. água quente. Avisos de montagem Medidas (ver página 9) • Antes da montagem deve-se controlar o produto rela- tivamente a danos de transporte. Após a montagem Caudal não são aceites quaisquer danos de transporte ou de (ver página 9) superfície.  com EcoSmart ® • As tubagens e a torneira têm que ser montadas,  sem EcoSmart ® enxaguadas e verificadas de acordo com as normas Peças de substituição (ver página em vigor.
  • Page 3 Español Indicaciones de seguridad Descripción de símbolos Durante el montaje deben utilizarse guantes para No utilizar silicona que contiene ácido acético! evitar heridas por aplastamiento o corte. La grifería solo debe ser utilizada para fines de Ajuste (ver página 8) baño, higiene y limpieza corporal. Ajuste del límite de agua caliente. En com- Grandes diferencias de presión en servicio entre binación con calentadores continuos no es agua fría y agua caliente deben equilibrarse. recomendable utilizar un bloqueo de agua Indicaciones para el montaje caliente. Dimensiones (ver página 9) • Antes del montaje se debe examinarse el producto contra daños de transporte. Después de la instala- ción so se reconoce ningún daño de transporte o de Caudal máximo superficie. (ver página 9) • Los conductos y la grifería deben montarse, lavarse y  con EcoSmart ® comprobarse según las normas vigentes.  sin EcoSmart ®...
  • Page 4: Installation Instructions

    English Safety Notes Symbol description Gloves should be worn during installation to prevent Do not use silicone containing acetic acid! crushing and cutting injuries. The shower system may only be used for bathing, Adjustment (see page 8) hygienic and body cleaning purposes. To adjust the hot water limiter. Using a hot The hot and cold supplies must be of equal pres- water limiter in combination with a continu- sures. ous flow water heater is not recommended. Installation Instructions Dimensions (see page 9) • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or surface damage will be honoured. Rate of flow • The pipes and the fixture must be installed, flushed (see page 9) and tested as per the applicable standards.  with EcoSmart ®  without EcoSmart • The plumbing codes applicable in the respective ® countries must be oberserved. Spare parts (see page ) • 31082010: If the instantaneous water heater causes problems or if you wish to increase the water flow, the Operation (see page 12)
  • Page 5: Montage

    Deutsch Sicherheitshinweise Symbolerklärung Bei der Montage müssen zur Vermeidung von Kein essigsäurehaltiges Silikon verwenden! Quetsch- und Schnittverletzungen Handschuhe getragen werden. Justierung (siehe Seite 8) Das Produkt darf nur zu Bade-, Hygiene- und Körper- Einstellen der Warmwasserbegrenzung. In reinigungszwecken eingesetzt werden. Verbindung mit Durchlauferhitzern ist eine Große Druckunterschiede zwischen den Kalt- und Warmwassersperre nicht zu empfehlen. Warmwasseranschlüssen müssen ausgeglichen werden. Maße (siehe Seite 9) Montagehinweise • Vor der Montage muss das Produkt auf Transportschä- Durchflussleistung den untersucht werden. Nach dem Einbau werden (siehe Seite 9) keine Transport- oder Oberflächenschäden anerkannt.  mit EcoSmart ® • Die Leitungen und die Armatur müssen nach den gülti-  ohne EcoSmart ® gen Normen montiert, gespült und geprüft werden. Serviceteile (siehe Seite ) • Die in den Ländern jeweils gültigen Installationsrichtli- nien sind einzuhalten. Bedienung (siehe Seite 12) • 31082010: Bei Problemen mit dem Durchlauferhitzer oder wenn mehr Wasserdurchsatz gewünscht wird, Hansgrohe empfiehlt, morgens oder nach kann der EcoSmart...
  • Page 6 7 Nm 31082010 SW 24 mm SW 10 mm 8 Nm 31084010 SW 24 mm 8 Nm SW 24 mm SW 22 mm...
  • Page 7 SW 22 mm 2 Nm > 2 min...
  • Page 8 Justierung 60 °C 10 °C 0,3 MPa...
  • Page 9 Metris Metris 31082010 31084010 Metris Metris 31082010 31084010 0,50 0,45 EcoSmart ® 0,40 0,35 0,30 0,25 0,20 0,15 0,10 EcoSmart ® 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
  • Page 10 Metris 260 95519000 31082010 96338000 97406000 98193000 (32x2) 97209000 92730000 95140000 98186000 95008000 (30x2) 98750000 EcoSmart ® 97489000 (900 mm) 13185000 98749000 97548000 97774000...
  • Page 11 Metris 110 95519000 31084010 96338000 97406000 98193000 (32x2) 97209000 92730000 95140000 98186000 95008000 (30x2) 98750000 97443000 (450 mm) 98749000 92254000 97548000 97774000 97160000...
  • Page 12 abrir / abierto / open / öffnen fechar / cerrar / close / schließen quente / caliente / hot / warm fria / frío / cold / kalt P-IX DVGW SVGW WRAS 31082010 31084010 Hansgrohe · Auestraße 5 - 9 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
  • Page 13 DE ⁄ Gebrauchsanleitung ⁄ Montageanleitung EN ⁄ Instructions for use ⁄ assembly instructions Focus 31521000 Focus 31523000 Talis 31426000 Talis 31427000 Metris 31422000 Metris 31423000 Novus 71044000 Novus 71043000...
  • Page 14: Bedienung

    Deutsch Sicherheitshinweise Technische Daten Bei der Montage müssen zur Vermeidung von Betriebsdruck: max. 1 MPa Quetsch- und Schnittverletzungen Handschuhe Empfohlener Betriebsdruck: 0,1 - 0,5 MPa getragen werden. Prüfdruck: 1,6 MPa (1 MPa = 10 bar = 147 PSI) Das Produkt darf nur zu Bade-, Hygiene- und Körper- Heißwassertemperatur: max. 70°C reinigungszwecken eingesetzt werden. Empfohlene Heißwassertemperatur: 65°C Große Druckunterschiede zwischen den Kalt- und Thermische Desinfektion: max. 70°C ⁄ 4 min Warmwasseranschlüssen müssen ausgeglichen werden. Das Produkt ist ausschließlich für Trinkwasser konzipiert! Montagehinweise Symbolbeschreibung • Vor der Montage muss das Produkt auf Transportschä- den untersucht werden. Nach dem Einbau werden Kein essigsäurehaltiges Silikon verwenden! keine Transport- oder Oberflächenschäden anerkannt. • Die Leitungen und die Armatur müssen nach den gülti- Justierung (siehe Seite 14) gen Normen montiert, gespült und geprüft werden. • Die in den Ländern jeweils gültigen Installationsrichtli- Einstellen der Warmwasserbegrenzung. In nien sind einzuhalten. Verbindung mit Durchlauferhitzern ist eine • Für Wartungsarbeiten muss unbedingt eine Revisi- Warmwassersperre nicht zu empfehlen.
  • Page 15 Störung Ursache Abhilfe Wenig Wasser – Rückflussverhinderer sitzt fest – Rückflussverhinderer austauschen – Filtereinsatz der Brause – Filtereinsatz zwischen Brause und verschmutzt Schlauch reinigen – Siebdichtung der Brause – Siebdichtung zwischen Brause und verschmutzt Schlauch reinigen Armatur schwergängig – Kartusche defekt, verkalkt – Kartusche austauschen Armatur tropft – Kartusche defekt – Kartusche austauschen Durchlauferhitzer schaltet nicht ein – Rückflussverhinderer sitzt fest – Rückflussverhinderer austauschen Zu niedrige Warmwassertemperatur – Warmwasserbegrenzung falsch – Warmwasserbegrenzung einstellen eingestellt...
  • Page 16: Operation

    English Safety Notes Technical Data Gloves should be worn during installation to prevent Operating pressure: max. 1 MPa crushing and cutting injuries. Recommended operating pressure: 0,1 - 0,5 MPa Test pressure: 1,6 MPa The product may only be used for bathing, hygienic (1 MPa = 10 bar = 147 PSI) and body cleaning purposes. Hot water temperature: max. 70°C The hot and cold supplies must be of equal pres- Recommended hot water temp.: 65°C sures. Thermal disinfection: max. 70°C ⁄ 4 min Installation Instructions The product is exclusively designed for drinking water! • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or Symbol description surface damage will be honoured. • The pipes and the fixture must be installed, flushed Do not use silicone containing acetic acid! and tested as per the applicable standards. • The plumbing codes applicable in the respective Adjustment (see page 14) countries must be observed. • There must be an access door for maintenance. The To adjust the hot water limiter. Using a hot premounted filter insert must be used to ensure a water limiter in combination with a continu-...
  • Page 17 Fault Cause Remedy Insufficient water – check valve hasn't moved back – Exchange check valves – filter insert shower dirty – Clean filter insert between shower and hose – Shower filter seal dirty – Clean filter seal between shower and hose Mixer stiff – Cartridge defective, calcified – Exchange cartridge Mixer dripping – Cartridge defective – Kartusche austauschen Instantaneous heater didn’t work – check valve hasn't moved back – Exchange check valves Hot water temperature too low – Hot water limiter incorrectly set – Set hot water limiter...
  • Page 18 Ø 28 mm min. 55 3 Nm...
  • Page 19 Montage SW 26 mm > 2 min SW 26 mm (2 Nm)
  • Page 20 Focus 31521000 Ø Ø G 3/4 1,25 m Focus 31523000 Ø G 3/4...
  • Page 21 Maße Talis 31426000 Ø G 3/4 Talis 31427000 Ø G 3/4...
  • Page 22 Maße Metris 31422000 Ø G 3/4 Metris 31423000 Ø G 3/4...
  • Page 23 Maße Novus 71044000 Ø G3/4 Novus 71043000 Ø G3/4...
  • Page 24 Durchflussdiagramm Focus 31521000 ⁄ 31523000 Talis 0,50 31426000 ⁄ 31427000 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 6 12 18 24 30 36 42 48 54 Metris 0,50 31422000 ⁄ 31423000 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 6 12 18 24 30 36 42 48 54...
  • Page 25 Durchflussdiagramm Novus 0,50 71043000 ⁄ 71044000 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 6 12 18 24 30 36 42 48 54...
  • Page 26 60 °C 10 °C 0,3 MPa...
  • Page 27 schließen ⁄ close öffnen ⁄ open warm ⁄ hot kalt ⁄ cold schließen ⁄ close öffnen ⁄ open...
  • Page 28 Serviceteile 93336000 Focus Novus 31521000 32892000 Talis Talis 96338000 31426000 96338000 Metris 92158000 31422000 Metris 96338000 28585000 Novus 92155000 Focus 71044000 Focus 97708000 96338000 97995000 98212000 92315000 (41x2) 28331000 Talis 92156000 94246000 92159000 92157000 (48x1,5) 95140000 (M4x20) 96466000 92316000 97738000 Metris 94246000 97163000...
  • Page 29 Serviceteile Focus 31523000 Talis 32892000 31427000 Talis Metris 96338000 31423000 92158000 Novus Metris 71043000 96338000 92155000 Focus 97995000 93336000 96338000 98212000 Novus (41x2) 92156000 96338000 92159000 (48x1,5) 92157000 95140000 (M4x20) 97163000 98667000...
  • Page 30 31521000 ⁄ 31422000 ⁄ 31426000 ⁄ 71044000...
  • Page 31 DE Reinigungsempfehlung ⁄ Garantie ⁄ Kontakt EN Cleaning recommendation ⁄ Warranty ⁄ Contact www.hansgrohe.com/ cleaning-recommendation www.hansgrohe.com/ cleaning-recommendation www.hansgrohe.com/ cleaning-recommendation www.hansgrohe.com/ cleaning-recommendation...
  • Page 32 P-IX DVGW SVGW WRAS KIWAACS 31521XXX 31523XXX 31426XXX 31427XXX 31422XXX 31423XXX 71044XXX 71043XXX Hansgrohe · Auestraße 5 – 9 · D-77761 Schiltach · Telefon +49 (0) 78 36⁄51-1282 · Telefax +49 (0) 7836⁄511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
