Solar Quartz Movements
Classic Functions
RONDA solartech
CALIBER
215
– 11½'''
Product Specifications
Analog quartz movement
Line
Caliber
Size
Version Swiss Made
Battery running time
Standard hand fitting height
Functions
• Solar quartz movement
• Date
• 3 hands
05/2025
solartech
215
11½'''
5 Jewels / gold plated
8 months, fully charged, without
exposure to light
1
Features
• Quick start function: 1 minute sun exposure
• Rechargeable secondary battery
• Power saving mechanism with pulled out stem:
Reduction of consumption approximately 70%. The
battery will remain charged in complete darkness for
more than two years and will start working again
immediately.
1/2
ronda.ch
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ronda solartech 212
Summary of Contents for Ronda solartech 212
- Page 1 Solar Quartz Movements Classic Functions RONDA solartech CALIBER – 11½''' Product Specifications Features Analog quartz movement • Quick start function: 1 minute sun exposure Line solartech • Rechargeable secondary battery Caliber • Power saving mechanism with pulled out stem: Reduction of consumption approximately 70%. The 11½'''...
-
Page 2: Technical Specifications
Solar Quartz Movements Classic Functions RONDA solartech CALIBER – 11½''' Technical Specifications Diameter Total 26.00 mm Case fitting 25.60 mm Movement height 2.89 mm Height over secondary battery 3.09 mm Movement rest 1.18 mm Height over stem 1.42 mm Length of stem travel 0.90 mm... - Page 3 Mod. No. 45418 Frame 45° Tolerance ±20 µm Dégagement dans le cercle d`entourage 9° Scale 5 : 1 Page 1/1 Freistellung im Gehäusering Sous réserve de modifications Opening in casing ring Aenderungen vorbehalten RONDA 212, 213, 214, 215 Modifications reserved 5000.461...
- Page 4 The outer diameter is dependent on the diameter of the customers dial 14.07.2023 jk5228 Issued Cercle d'emboîtage 23.08.2023 jk5228 Modified Released Gehäusering 11½''' Mod. No. 45418 Casing ring Tolerance Scale 5 : 1 Page 1 / 1 Sous réserve de modifications Aenderungen vorbehalten 212, 213, 214, 215 RONDA Modifications reserved 5080.001...
- Page 5 Dial thickness according to hand fitting heights Issued 03.10.2022 aj5216 Cadran Modified 30.08.2024 rk5232 Released Zifferblatt 11½''' Mod. No. 45418 Dial Tolerance ±20 µm Scale 5 : 1 Page 1/1 Sous réserve de modifications Aenderungen vorbehalten RONDA 214, 215 Modifications reserved 5010.856...
- Page 6 Dial thickness according to hand fitting heights Issued 19.04.2023 fl5223 Cadran Modified 30.08.2024 rk5232 Released Zifferblatt 11½''' Mod. No. 45418 Dial Tolerance ±20 µm Scale 5 : 1 Page 1/1 Sous réserve de modifications Aenderungen vorbehalten RONDA 214, 215 Modifications reserved 5010.859...
- Page 7 Scale 20 : 1 Page 1/1 Sous réserve de modifications Aenderungen vorbehalten RONDA Modifications reserved 3316.202 * En cas de données différentes, veuillez contacter le service après-vente * Bei abweichenden Werten, bitte technischen Kundendienst anfragen * In case of different values, please contact the customer service...
- Page 8 Mod. No. 45418 Stem (dimensions / forces) No. d'article Tolerance Artikelnummer (min) Scale Page 1 /1 Part number Sous r serve de modifications 3000.040 12.00 1.90 2.60 0.90 0.90 1.35 Aenderungen vorbehalten 212, 213, 214, 215 RONDA Modifications reserved 5030.055...
- Page 9 Movement holder This movement contains a rechargeable battery that is charged via Setting hands the solar cell. Only batteries specified by RONDA may be used. Under H71X.1A no circumstances may a silver oxide battery or any other conventional watch battery be used.
- Page 10 If it is necessary to replace the battery, it is essential to ensure that only a battery approved by RONDA for this movement is used. The replacement must be carried out by a specialist dealer and the old battery must be disposed of properly.
- Page 11 Mise à l’heure, stop-seconde avec interruption des impulsions moteur Hand setting, stop-second with interruption of motor impulses Batterie Pile Battery Kaliber Wiederaufladbare Batterie Spannung Artikelnummer RONDA Calibre Batterie rechargeable Tension Numero d’article RONDA Caliber Rechargeable Battery Voltage Part number RONDA 212–215 MT 920 1.5 V 3600.035 01/2024...
- Page 12 Werkaufbau Assemblage Assembling 212, 213, 214, 215 4000.102 (2x) 2130.105.G.MO1 4000.233 3612.234.RK 3601.049 4000.102 3603.039 3015.040 4000.141 (2x) 3621.018.RK 4000.240 2020.120.G.MO1 3122.043.CO 3600.035 3136.194.CO 3715.139.RK 4000.266 3147.092.CO 3603.113 3622.069 2030.014.CO 3305.171.CO 3000.155.CO 3017.038 3001.076.Fi Dünnflüssiges Oel Moebius 9014 Fett Moebius, Microgliss D5, Jisma 124 2000.431.SM.G.LC Code: Beispiel 10 / example 10 / exemple 10 Abweichungen / Divergences / Deviations...
-
Page 13: Electrical Checking
Elektr. Messungen Contrôles électriques Electrical checking Kaliber Pos. Einheit Messwerte Kontrolle Bemerkungen Calibre Pos. Unité Valeurs mesurées Contrôle Remarques Caliber Pos. Unit Measured values Check Remarks Stromaufnahme (Kalender nicht im Eingriff) Ohne Batterie, mit externer Speisung 212–215 µA 0,70 –1,35 Consommation de courant (quantième non en prise) Sans pile, avec alimentation externe Current consumption (Date mechanism not in gear)
