Application
» Monitoring of energy consumption in industrial and domestic
installations;
» Ongoing measurement of power consumption and values of
currents and voltages;
» Use of recorded measurements to detect exceedances in vol-
tage levels or power consumption;
» Controlling energy production in photovoltaic installations;
» Metering of heat pumps.
www.fif.com.pl/fox/energy3
ENERGY 3-400
Wi-MEF-3-400
energy consumption monitor
- 1 -
3-phase
Advertisement
Related Manuals for F&F FOX ENERGY 3-400
Summary of Contents for F&F FOX ENERGY 3-400
- Page 1 ENERGY 3-400 Wi-MEF-3-400 3-phase energy consumption monitor www.fif.com.pl/fox/energy3 F&F Filipowski L.P.; Konstantynowska 79/81, 95-200 Pabianice, PL www.fif.com.pl; e-mail: biuro@fif.com.pl Application » Monitoring of energy consumption in industrial and domestic installations; » Ongoing measurement of power consumption and values of currents and voltages; »...
- Page 2 Properties » 3-phase, 2-way, 4-quadrant electricity consumption monitor, perfect for monitoring photovoltaic installations, among other things; » Monitoring of all relevant electrical network parameters; » Recording of average, minimum and maximum values; » Measuring range up to 400 A; » Non-invasive installation using open current transformers for conductors up to 34 mm in diameter;...
- Page 3 Configuration For the initial configuration of the Fox module, it is necessary to download and run the free Fox application available for mobile devices running the system: » Android, version 8.0 or higher; » iOS, version 14 or higher. You can download the app directly from the stores: or via the website: www.fif.com.pl/fox On the above page, you can also find detailed information on...
-
Page 4: Wiring Diagram
Wiring diagram The correct type of measuring transformer must be set in the Fox application (for the Energy 3 module): Module settings → Measuring transformer. - 4 -... - Page 5 Description of terminals Power supply and voltage measurement (top row of terminals) L1 phase L2 phase L3 phase neutral wire Connecting the phase wire to the N terminal may damage the device. The unit is designed for 3-phase, 4-wire mains ope- ration.
- Page 6 Direct connection of a voltage source (especially mains voltage) to the terminals of the transformer may damage the device. By default, the device is designed to connect TOM- 400-03 current transformers with a rated current of 400 A. If other transformers are used, the device setting must also be changed accordingly (Fox app →...
- Page 7 - 7 -...
- Page 8 Mounting of measuring transformers Miniature, open-ended current transformers are supplied with the unit. No interference with the current leads is required to clip them onto the measured leads, but special attention must be paid to the way the lead is passed through the transformer and to the connection of the secondary side of the transformer to the device.
- Page 9 Customisation Once you have connected your new device to the power supply, it is advisable to carry out personalisation, i.e. linking it to your phone and user account. To do this, launch the Fox app, select settings icon , then Add new device command. If you are running the application on your phone for the first time, follow the programme’s instructions to register a user account or log in to an existing account,...
- Page 10 When the search process is complete, the new Fox devices will be displayed. The Energy 3 module will appear in the list as fol- lows: - 10 -...
- Page 11 To add a new device, you must first connect to it (press Con- nect button), and once it has been established (figure below), press Configure button and continue following the application’s instructions. - 11 -...
- Page 12 Telemetry Fox Energy 3 allows energy consumption and monitored ne- twork parameters to be recorded. Data can be accessed directly from the application (Telemetry command visible in the device context menu) or via any web browser. (address https://telemetron.fhome.cloud). Starting data logging requires entering the module set- tings and selecting the Telemetry option.
- Page 13 LED signalling The status of the module can be directly assessed by the STATUS LED located on the front of the device. The grey color actually corresponds to the green LED and the black color to the red LED. Controller in factory mode Connecting to a Wi-Fi network...
-
Page 14: Restore Factory Settings
Energy consumption signalling Three LED lights (L1, L2, L3) on the front of the unit on the ri- ght-hand side are used to indicate the presence of voltage and power consumption. A light on indicates the presence of voltage on a given measuring circuit. A short blink indicates active ener- gy consumption: 1 pulse = 1 Wh. - Page 15 Technical data installation 3-phase, 4-wire power supply 3×230/400 V AC (-25%÷15%) frequency 50÷60 Hz accuracy meter measuring transformers 0.5% transformer parameters primary current 400 A secondary current 30 mA cable diameter ≤34 mm wire length 1,5 m signalling device status, energy consumption meter constant 1000 pulses/kWh power consumption...
-
Page 16: Warranty
Warranty F&F products are covered by a 24-month warranty from the date of purchase. The warranty is only valid with proof of purchase. Contact your dealer or contact us directly. CE declaration F&F Filipowski L.P. declares that the device is in conformity with the essential requirements of Directive 2014/53/EU of the European Parliament and of the Council of 16 April 2014 on the harmonisation of the laws of the Member States relating to the...
