INSTRUCTION MANUAL
LED SOLAR STREET LIGHT WITH SOLAR PANEL
TECHNICAL DATA
MODEL
VT-ST63W
SKU
95532, 98241
SOLAR PANEL
6W
WATTS
LUMENS
800 lm
BEAM ANGLE
120°
LED CHIP TYPE
2835
NUMBER OF LEDs
60
CRI
70
LIFE SPAN
20000 Hours
ON/OFF CYCLE
50000 Times
MAXIMUM
MOUNTING
3 Meter
HEIGHT
OPERATIONAL
-20°C to +60°C
TEMPERATURE
BATTERY
5000 mAh
CAPACITY
LiFePO4
BATTERY TYPE
DC VOLTAGE
DC 3.2V
CHARGING TIME
4-6 Hours
WORKING TIME
12-15 Hours
MATERIAL
PC
DIMENSION
360x187x55mm
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully
before starting the installation and keep this manual handy for future reference. If you have any another query, please contact
our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.
The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by incorrect
installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect
removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24
Hours a day would void the warranty. This product is warranted for manufacturing defects only.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
VT-ST120W
VT-ST180W
95533, 98240,
95534
98417
8W
12W
1000 lm
1200 lm
120°
120°
2835
2835
120
180
70
70
20000 Hours
20000 Hours
50000 Times
50000 Times
4 Meter
5 Meter
-20°C to +60°C
-20°C to +60°C
9000mAh
10000mAh
LiFePO4
LiFePO4
DC 3.2V
DC 3.2V
4-6 Hours
4-6 Hours
12-15 Hours
12-15 Hours
PC
PC
470x190x55mm
600x197x55mm
