V-TAC VT-55ST Instruction Manual

LED STREET LIGHT WITH ADJUSTABLE ANGLE
TECHNICAL DATA
MODEL
SKU
WATTS
LUMENS@WIDE CODE
BEAM ANGLE
DF
CRI
OPERATION
TEMPERATURE
LIFE SPAN
ON/OFF CYCLE
NET WEIGHT (g)
INPUT VOLTAGE
MOUNTING DIAMETER
MOUNTING HEIGHT
MAX. PROJECTED
AREA
BODY TYPE
DIMENSION
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions care-
fully before starting the installation and keep this manual handy for future reference. If you have any another query,
please contact our dealer or local vendor from whom you have purchased the product. They are trained and ready
to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty does not apply to
damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty against damage
to any surface due to incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily
operation. Usage of product for 24 Hours a day would void the warranty. This product is warranted for manufacturing
defects only.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
VT-55ST
23618, 23619
50W
4700 LM
100°
>0.9
≥80
-20°C to +40°C
30,000 Hours
20,000 Times
670
AC: 220-240V, 50/60Hz
60 mm
3-5m
20-30m
2
Aluminium+PC
412x139x92mm
VT-105ST
23620, 23621
100W
9400 LM
100°
>0.9
≥80
-20°C to +40°C
30,000 Hours
20,000 Times
1035
60 mm
5-8 m
30-40m
2
Aluminium+PC
488x183x92mm
