- Page 1 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Be Sure to Read this Manual Before Use Operation Manual ...
-
Page 2: Important Safety Instructions
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Thank you for purchasing LUCKY STREAK from Family Fun Companies. We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. - Page 3 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) No Touching Hazard: This part may be hot or can cause electric shock. Do not touch. Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage.
-
Page 4: Specifications
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 1. SPECIFICATIONS 1) Rated power supply： AC110-120V 50/60Hz 2) Power consumption： Min power consumption：160W Max power consumption：550W 3) Dimensions：W1200×D886×H2406.5（mm） 4) Weight：About 135kg 5) Environment condition:（Indoor）temperature: -10～+40 Humidity : ≤90%；... -
Page 5: Package Contents
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 2. PACKAGE CONTENTS Open the package and make sure all the items are included: • 1 x Body Assembly • Following accessories Part No. Name Spec. -
Page 6: Part Names
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 3. PART NAMES FRONT VIEW REAR VIEW... -
Page 7: Setup And Installation
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 4. SET UP & INSTALLATION This product is an indoor game machine. Do not install outdoors. Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid Place the unit on a dry level surface Ventilation openings in the back of the unit must not be obstructed by objects or by wall. - Page 8 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) NOTICE Make sure the machine is level with the ground and all the adjustable legs should stick to the floor closely. 4.3 Installing the Light Box： Take out the light box and install it on top of the game Fix it with the bolts Guide the cable out through the hole and connect.
- Page 9 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 4.4 Transporting the Game If you need to move the game, adjust the levelers back to an “up” position so the casters touch the ground. Leveler Caster ...
- Page 10 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) WARNING Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet does not sit on the power cord as this could damage the cord and become hazardous. To disconnect the game, grip the plug and pull it from the wall outlet.
-
Page 11: How To Play
5. HOW TO PLAY Lucky Streak is a fun and easy to play game that stays true to the traditional coin flipping game of heads or tails. There are 6 rounds in each play. Build your lucky streak by winning all 6 rounds and... -
Page 12: Switches Control Signal
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 6. GAME OPTIONS & SETTINGS Switches Control Signal 6.1 Refer to the attached I/O chart and the schematic. 6.2 To adjust DIP, please refer to the I/O chart. The initial setting is in CAPITALIZED. 6.3 Main board ：... -
Page 13: Volume Adjustment
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 6.4 Volume Adjustment： Turn the knob on the main board to adjust the game volume as shown:... -
Page 14: Display Error
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 6.5 Adjusting the DIP（Default Setting） Test method： To Test the LED, display 8.7.6.5.4.3.2.1. and 87654321 Press TEST button again and LED displays 1, it shows the LED 1 and LED 2 of 1# in DIP SW state. -
Page 15: Error Codes
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Hold the TEST button and press Reset button, then release Reset button. 6.8 Error Codes: Coin Jam No obverse or reverse signal No coin drop 7. -
Page 16: Maintenance, Inspection
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 7. MAINTENANCE, INSPECTION 7.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Try to run the game before operation each day. 2. -
Page 17: Overall Construction
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8. OVERALL CONSTRUCTION 8-01 Main Assembly 1:... - Page 18 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Part No. 1 Part No. 2 Name Qty. Spec. Note L102-001-000 LS-01-01 Revolution Assy. 461*300*78 L102-005-000 LS-01-02 Lamp box 1170*559*230 L102-635-000 LS-01-03 L_face board Clarity PET 808*576.5*5 L102-624-000 LS-01-04...
- Page 19 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) L102-109-000 LS-01-29 Power holder Electrolytic board 157×210 L102-110-000 LS-01-30 Slit Stainless steel L102-111-000 LS-01-31 Leveler Q235 M16×100 L102-504-000 LS-01-32 Table-board Plywood 587.5*544.5*15 Fluorescence Green PET R_adornment boar L102-605-000 LS-01-33...
-
Page 20: Main Assembly
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-02 Main Assembly 2:... - Page 21 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Part No. Part No. 2 Name Qty. Spec. Note LS-02-01 Score board L102-639-000 Clarity PET 365*74*1.5 LS-02-02 L102-519-000 Lamp board plywood 577.5*300*15 LS-02-03 L102-506-000 Top board plywood 577.5*240*15 L102-802-000...
-
Page 22: Light Box
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-03 Light Box :... - Page 23 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Part No. Part No. 2 Name Qty. Spec. Note LS-03-01 Lamp box board L102-614-000 950.7*115*5 Fiberglas LS-03-02 L102-615-000 Lamp box crust 1170*385*230 LS-03-03 L102-413-000 Lamp holder E27-48 E221399 E27/2U 13V （220V）...
- Page 24 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-04 Rotation Assembly:...
- Page 25 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Part No. Part No. 2 Name Qty. Spec. Note LS-04-01 Top assembly L102-617-000 Fiberglass ＆ Q235 LS-04-02 L102-416-000 Bearing 30302 LS-04-03 L102-618-000 Dustproof cover Black nylonΦ50*6.5 LS-04-04 Top assembly...
- Page 26 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-05 Lamp Board Assembly: Part No. Part No. 2 Name Qty. Spec. note Lamp board L102-815-000 LS-05-01 XYJL-LED06 Lamp box angle iron Electrolytic board LS-05-02 L102-153-000 (upper)
- Page 27 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-06 Launch Assembly:...
- Page 28 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Part No. Part No. 2 Name Qty. Spec. Note LS-06-01 L102-130-000 Coin φ90*4.5 LS-06-02 Filler L102-619-000 Black nylon 298*84 LS-06-03 L102-822-000 Sensor board HW2558.PCB LS-06-04 L102-620-000 Bush...
- Page 29 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-07 Coin Machine Assembly: Part No. Part No. 2 Name Qty. Spec. Note Coin machine Electrolytic board LS-07-01 L102-140-000 bracket 118.5*93*53.3 LS-07-02 L102-424-000 Coin machine TW-600 Coin pipe connect Electrolytic board...
- Page 30 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-08 False coin filler Part No. Part No. 2 Name Qty. Spec. Note LS-08-01 L102-146-000 Press board Stainless steel 18*10*1 LS-08-02 L102-147-000 Block board Stainless steel 65*35*1 Stainless steel LS-08-03...
-
Page 31: Electrical Part
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-09 Electrical part： Coin counter Ticket counter 出币计数 投币计数 Part No. Part No. 2 Name Qty. Spec. Note Electrolytic board LS-09-01 Relay holder L102-149-000 135*60*15*1.5 LS-09-02 L102-426-000... - Page 32 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-10 Wire box Fuse Part No. Part No. 2 Name Spec. Note LS-10-01 Fuse holder L102-432-000 10A/250V R3-11 LS-10-02 L102-433-000 Fuse 10A125V 5A/250Vφ5-20 LS-10-03 L102-434-000 Power SW 10A125V 1/4HP...
-
Page 33: Game Decals
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) 8-11 Game Decals... - Page 34 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 (Ticket V2.0C) Part No. Part No. 2 Name Qty. Spec. Note LS-11-01 L102-701-000 Top menu 960X230（PVC100u） LS-11-02 L102-738-000 Lamp box menu 1160X370（δ3） LS-11-03 L102-739-000 Score group menu 420X95（δ1.5）...
- Page 35 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Lucky Streak (Family Fun ver.) IO Chart 2.2 Update: 5/24/2010 Design: 9/1/2008 Item Content INPUT CONTENT INPUT CONTENT INPUT CONTENT INPUT CONTENT INPUT CONTENT 1#HEADS button...
