NEC NEAX2000 System Manual

Integrated voice server, remote pim

Hide thumbs Also See for NEAX2000:

General description manual (58 pages)

Manual (96 pages)

100

101

102

103

104

105

106

107

108

page of 108

/ 108
Bookmarks

Quick Links

Download this manual

ND-70917(E)

ISSUE 1

Remote PIM System Manual

NOVEMBER, 1999

NEC Corporation

Need help?

Do you have a question about the NEAX2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for NEC NEAX2000

Page 1 ND-70917(E) ISSUE 1 Remote PIM System Manual NOVEMBER, 1999 NEC Corporation...
Page 2 NEC Corporation reserves the right to change the specifications, functions, or features, at any time, without notice. NEC Corporation has prepared this document for use by its employees and customers. The information contained herein is the property of NEC Corporation and shall not be reproduced without prior written approval from NEC Corporation.
Page 3 ND-70917(E) Remote PIM System Manual ISSUE 1 Addendum-001 MARCH, 2000 GENERAL This addendum supplements the “NEAX2000 IVS /NEAX2000/NEAX7400 ICS M100MX Remote PIM System Manual [ND-70917(E)]”. REASON FOR ISSUED The addendum is issued in order to correct errors. PAGE REPLACEMENT INSTRUCTION...
Page 5 ADD No. ADD No. PAGE No. PAGE No. ADDENDUM-001 ADDENDUM-002 ADDENDUM-003 ADDENDUM-004 DATE MARCH,2000 DATE DATE DATE ADDENDUM-005 ADDENDUM-006 ADDENDUM-007 ADDENDUM-008 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX Remote PIM System Manual Addendum Revision Sheet 1/2 ND-70917(E) ISSUE 1...
Page 6 ADD No. ADD No. PAGE No. PAGE No. ADDENDUM-001 ADDENDUM-002 ADDENDUM-003 ADDENDUM-004 DATE MARCH,2000 DATE DATE DATE ADDENDUM-005 ADDENDUM-006 ADDENDUM-007 ADDENDUM-008 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX Remote PIM System Manual Addendum Revision Sheet 2/2 ND-70917(E) ISSUE 1...
Page 7 ISSUE No. ISSUE No. PAGE No. PAGE No. ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE NOVEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX Remote PIM System Manual Revision Sheet 1/2 ND-70917(E)
Page 8 ISSUE No. ISSUE No. PAGE No. PAGE No. ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE NOVEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX Remote PIM System Manual Revision Sheet 2/2 ND-70917(E)
Page 9 TABLE OF CONTENTS INTRODUCTION ............................PURPOSE ............................. OUTLINE OF THIS MANUAL ......................REFERENCE MANUAL ........................CHAPTER 1 GENERAL INFORMATION ..................SYSTEM OUTLINE ..........................PIM CONFIGURATION ........................SYSTEM CONFIGURATION ......................System Configuration for T1 ....................... System Configuration for E1 ....................... REQUIRED EQUIPMENT ........................
Page 10 TABLE OF CONTENTS Optical Cable Connection ......................MP RESET ............................CHAPTER 3 TROUBLESHOOTING ....................CHAPTER 4 CIRCUIT CARD INFORMATION ................HOW TO READ THIS CHAPTER ....................MOUNTING LOCATION OF CIRCUIT CARD ................LIST OF REQUIRED CARD ......................PN-CP15 (FP) ........................... PN-DAIA (DAI) ..........................
Page 11 INTRODUCTION PURPOSE/OUTLINE OF THIS MANUAL INTRODUCTION PURPOSE This manual explains the system outline and installation procedure for providing the Remote PIM to the NEAX 2000IVS /7400ICS M100MX. OUTLINE OF THIS MANUAL This manual consists of four chapters. The contents of CHAPTER 1 through 4 are outlined below. CHAPTER 1 GENERAL INFORMATION This chapter explains the outline of system conﬁguration, required...
Page 12 INTRODUCTION REFERENCE MANUAL REFERENCE MANUAL During installation, refer also to the PBX manuals below: Installation Procedure Manual: describes the installation procedure of the PBX system. Command Manual: describes Customer Administration Terminal (CAT) operation, command function and setting data required for programming the system, and Resident System Program. Ofﬁce Data Programming Manual: contains the Customer Speciﬁcation Sheet and Ofﬁce Data Programming Sheet.
Page 13 CHAPTER 1 GENERAL INFORMATION CHAPTER 1 GENERAL INFORMATION This chapter explains the outline of system conﬁguration, required equipment, system capacity, system conditions, and time slot alloca- tion. SYSTEM OUTLINE ..............PIM CONFIGURATION .............. SYSTEM CONFIGURATION ............. REQUIRED EQUIPMENT ............SYSTEM CAPACITY ..............SYSTEM CONDITIONS .............
Page 14 CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE SYSTEM OUTLINE Remote PIMs can be installed separately at the distance in one building, or between the ofﬁces via the Public Switching Telephone Network (PSTN). The customers in remote site can use the same service features as in main site. Remote PIMs are connected to the main site by T1(1.5 Mbps)/E1 (2 Mbps) digital interface.
Page 15 CHAPTER 1 GENERAL INFORMATION PIM CONFIGURATION PIM CONFIGURATION One PIM can be installed respectively as a remote site. A maximum of 3 remote sites can be provided. The number of remote sites determines the number of PIMs in one system. This table shows the available PIM conﬁguration for the Remote PIM System.
Page 16 CHAPTER 1 GENERAL INFORMATION SYSTEM CONFIGURATION SYSTEM CONFIGURATION System Conﬁguration for T1 This ﬁgure shows the system conﬁguration for T1. System Conﬁguration for T1 Main Site Remote Site Remote PIM 1 23 B Channel DAIA 1 DAIB Line/TRK (FP1) 1 D Channel (FP1) 24 B Channel DAIC 1...
Page 17 CHAPTER 1 GENERAL INFORMATION SYSTEM CONFIGURATION System Conﬁguration for E1 This ﬁgure shows the system conﬁguration for E1. System Conﬁguration for E1 Main Site Remote Site Remote PIM 1 30 B Channel DAID 1 DAIE Line/TRK (FP1) 1 D Channel (FP1) 30 B Channel DAIF 1...
Page 18 CHAPTER 1 GENERAL INFORMATION REQUIRED EQUIPMENT REQUIRED EQUIPMENT This table shows the required equipment for providing the Remote PIM System. Required Equipment EQUIPMENT FUNCTIONAL FUNCTION NAME NAME PN-DAIA T1 Digital Trunk Interface (23B + D, 1.5Mbps) Card for Remote PIM Accommodates 24-channel PCM digital lines, and provides Firmware Processor and BUS interface.
Page 19 CHAPTER 1 GENERAL INFORMATION REQUIRED EQUIPMENT Required Equipment EQUIPMENT FUNCTIONAL FUNCTION NAME NAME PN-CP15 Firmware Processor Card Provides Line/Trunk interface, Memory (RAM 768KB), and inter-module BUS interface. BUS interface functions as a driver/receiver of various signals, adjusts gate delay timing and cable delay timing, monitors I/O BUS and PCM BUS.
Page 20 CHAPTER 1 GENERAL INFORMATION SYSTEM CAPACITY SYSTEM CAPACITY System Capacity for T1 This table shows the system capacity for T1. System Capacity for T1 CAPACITY DESCRIPTION REMARKS MAIN PIM REMOTE PIM DAIA card – DAIB card – DAIC card Line/Trunk Ports –...
Page 21 CHAPTER 1 GENERAL INFORMATION SYSTEM CAPACITY System Capacity for E1 This table shows the system capacity for E1. System Capacity for E1 CAPACITY DESCRIPTION REMARKS MAIN PIM REMOTE PIM DAID card – DAIE card – DAIF card Line/Trunk Ports – Main PIM : 1 DAID on Remote Site...
Page 22 CHAPTER 1 GENERAL INFORMATION SYSTEM CONDITIONS SYSTEM CONDITIONS • Only one PIM conﬁguration is available at remote site. • Remote PIM can be installed at a maximum of 400 m (1312 ft.) distance from main site. Using the Optical Interface card (PN-M10) or line extension equipment (repeater, MUX, etc.), the distance can be extended.
Page 23 CHAPTER 1 GENERAL INFORMATION TIME SLOT ALLOCATION TIME SLOT ALLOCATION Time Slot Allocation for T1 One time slot out of the last 24 time slots provided by DAIA-DAIB connection is used for the con- trol signaling channel. This ﬁgure shows the examples of time slot allocation when mounting 8 port cards to the PIM.
Page 24 CHAPTER 1 GENERAL INFORMATION TIME SLOT ALLOCATION Time Slot Allocation for T1 When using 1 DAIA card, 1 DAIB card and 4 DAIC cards Remote PIM 00-23 24-47 48-63 Highway Channel • 23 time slots for Line/Trunks DAIC 0 DAIC 1 DAIB •...
Page 25 CHAPTER 1 GENERAL INFORMATION TIME SLOT ALLOCATION Time Slot Allocation for E1 One time slot out of the last 32 time slots provided by DAID-DAIE connection is used for the con- trol signaling channel. This ﬁgure shows examples of time slot allocation when mounting 8 port cards to the PIM.
Page 26 THIS PAGE LEFT BLANK INTENTIONALLY. – 16 – 99012-10...
Page 27 CHAPTER 2 INSTALLATION CHAPTER 2 INSTALLATION This chapter explains how to install the Remote PIM hardware. This chapter describes only the installation procedure exclusively re- quired for providing the Remote PIM System. Refer to the Installation Procedure Manual for the regular installation. PRECAUTIONS .................
Page 28 CHAPTER 2 INSTALLATION PRECAUTIONS PRECAUTIONS Static Electricity Guard You must wear a grounded wrist strap to protect circuit cards from static electricity. Static Electricity Guard • WHEN PLUGGING/UNPLUGGING A CIRCUIT CARD FRAME GROUND SCREW WRIST STRAP • WHEN HOLDING A CIRCUIT CARD NEVER TOUCH THE COMPONENTS OR SOLDERED SURFACE WITH BARE HANDS.
Page 29 CHAPTER 2 INSTALLATION PRECAUTIONS Static Electricity Guard • WHEN MAKING A SWITCH SETTING ON A CIRCUIT CARD CIRCUIT CARD WEAR A WRIST STRAP AND PERFORM THE WORK ON A GROUNDED CONDUCTIVE WORK SURFACE. • WHEN CARRYING A CIRCUIT CARD CONDUCTIVE CIRCUIT POLYETHYLENE CARD...
Page 30 CHAPTER 2 INSTALLATION PRECAUTIONS CAUTION You must hold the edge of a circuit card when plugging or unplugging the circuit card. If you touch another area, you may be exposed to hazard voltages. NEVER TOUCH THE COMPO- NENTS OR SOLDERED SUR- FACE WITH BARE HANDS.
Page 31 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE INSTALLATION PROCEDURE Install the Remote PIM System according to the following procedure. Installation Procedure for Main Site This ﬂow chart shows the installation procedure for main site. Installation Procedure for Main Site START Mounting DAIA Card for T1 page 23 Mounting DAID Card for E1 Mounting DAIC Card for T1...
Page 32 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Installation Procedure for Remote Site This ﬂow chart shows the installation procedure for remote site. Installation Procedure for Remote Site START Mounting DAIB Card for T1 page 29 Mounting DAIE Card for E1 Mounting DAIC Card for T1 page 29 Mounting DAIF Card for E1 page 29...
Page 33 CHAPTER 2 INSTALLATION INSTALLATION FOR MAIN SITE INSTALLATION FOR MAIN SITE Mounting DAIA Card for T1 ATTENTION Mounting DAID Card for E1 Contents Static Sensitive Handling (1) Before mounting the DAIA/DAID card, set the MB switch to UP position, Precautions Required and set the other switches to appropriate position.
Page 34 CHAPTER 2 INSTALLATION INSTALLATION FOR MAIN SITE BUS Cable Connection (1) Cable Connection between BUS connector on the BWB and DAIA/DAID Card Connect the DAIA/DAID card to the BUS connector on the BWB by the RMT BUS CA-A, as shown below. In BUS connector on the BWB, BUS1B or BUS0B must be used for this connection.
Page 35 CHAPTER 2 INSTALLATION INSTALLATION FOR MAIN SITE BUS Cable Connection (b) When mounting DAIA/DAID card on PIM2, PIM4 When Main PIM is 5 or 6 PIM conﬁguration, the DAIA/DAID card must be mounted on PIM2 and/or PIM4, and connected as shown below. BUS1B BUS1A RMT BUS CA-A...
Page 36 CHAPTER 2 INSTALLATION INSTALLATION FOR MAIN SITE (2) Cable connection between DAIA/DAID cards If two or three DAIA/DAID cards are mounted on one PIM, connect between the PCM0 connector and PCM1 connector on the DAIA/DAID cards by 17-TW-0.3 CONN CA-A, as shown below.
Page 37 CHAPTER 2 INSTALLATION INSTALLATION FOR MAIN SITE (3) Cable Connection between DAIA/DAID Card and DAIC/DAIF Card Connect between the RBUS connector on the DAIC/DAIF card and the BUS connector on the DAIA/DAID card by 48-TW-0.2 CONN CA, as shown below. Up to two DAIC cards can be mounted per DAIA card.
Page 38 CHAPTER 2 INSTALLATION INSTALLATION FOR MAIN SITE DAIA/DAID between DAIC/DAIF Cable Connection • When mounting 3 DAIA/DAID cards and 3 DAIC/DAIF cards DAIC DAIA DAIC DAIA DAIC DAIA : 17-TW-0.3 CONN CA-A /DAIF /DAID /DAIF /DAID /DAIF /DAID : 48-TW-0.2 CONN CA TBUS PCM1 RBUS...
Page 39 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE INSTALLATION FOR REMOTE SITE Mounting DAIB Card for T1 ATTENTION Mounting DAIE Card for E1 Contents Static Sensitive Handling (1) Before mounting the DAIB/DAIE card, set the MB switch to UP position, Precautions Required and set the other switches to appropriate position.
Page 40 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE BUS Cable Connection Connect between the BUS connector on the DAIB/DAIE card and the RBUS connector on the DAIC/DAIF card by the 48-TW-0.2 CONN CA, as shown below. DAIB/DAIE between DAIC/DAIF Cable Connection •...
Page 41 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE Mounting Line/Trunk Card for T1 (1) Mount line/trunk cards in the LT slots on the Remote PIM. (2) Connect the line cables referring to the following ﬁgure and table. Mounting Location of Line/Trunk Card for T1 AC/DC Remote PIM LTC1...
Page 42 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE Location of Each LEN for T1 • When opposite DAIA card is set to FP No. 1: SLOT No. LT00 LT01 LT02 LT03 LT04 LT05 LT06 LT07 LT08 LT09 LT10 LT11 NOTE 2 •...
Page 43 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE LTC Connector Pin Arrangement for T1 When 8-port card When 4-port card is mounted is mounted (FP2) (FP3) (FP1) (FP2) (FP3) LTC0 (FP1) /400 /600 LEN 200 /400 /600 /601 /401 /601 /401 LT00 /402 /602...
Page 44 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE LTC Connector Pin Arrangement for T1 When 8-port card When 4-port card is mounted is mounted (FP2) (FP3) (FP1) (FP2) (FP3) LTC2 (FP1) /448 /648 LEN 248 /448 /648 /649 /449 /649 /449 LT06 /450 /650...
Page 45 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE Mounting Line/Trunk Card for E1 (1) Mount line/trunk cards in the LT slots on the Remote PIM. (2) Connect the line cables referring to the following ﬁgure and table. Mounting Location of Line/Trunk Card for E1 AC/DC Remote PIM LTC1...
Page 46 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE Location of Each LEN for E1 • When opposite DAID card is set to FP No. 1: SLOT No. LT00 LT01 LT02 LT03 LT04 LT05 LT06 LT07 LT08 LT09 LT10 LT11 NOTE 2 •...
Page 47 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE LTC Connector Pin Arrangement for E1 When 8-port card When 4-port card is mounted is mounted (FP2) (FP3) (FP1) (FP2) (FP3) LTC0 (FP1) /400 /600 LEN 200 /400 /600 /601 /401 /601 /401 LT00 /402 /602...
Page 48 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE LTC Connector Pin Arrangement for E1 When 8-port card When 4-port card is mounted is mounted (FP2) (FP3) (FP1) (FP2) (FP3) LTC2 (FP1) /448 /648 LEN 248 /448 /648 /649 /449 /649 /449 LT06 /450 /650...
Page 49 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE Power Failure Transfer (AUC) The PN-AUC card can be used as the PFT card at remote site. • The ﬁgure shows an outline of a PFT (PN-AUC) connection. • The ﬁgure on next page shows the MDF cross connection for a PFT (PN-AUC). PFT Connection Outline (AUC) Remote PIM TO C.O.
Page 50 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE MDF Cross Connection for PFT (AUC) REMOTE PIM LTC0 PN-4COT Ring C.O.R0 LEN000 (No. 0) C.O. LINE C.O.T0 Ring C.O.R1 LEN001 (No. 1) C.O.T1 C.O. LINE LT00 PN-AUC 4Q-TW-0.3 CONN CA Ring Sta. R0 LEN008 (No.
Page 51 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE MDF Cross Connection for PFT (PN-AUC) LTC0 (J) LTC0 (P) 1 C.O.R0 26 C.O.T0 26 C.O.T0 1 C.O.R0 LEN000 2 C.O.R1 27 C.O.T1 27 C.O.T1 2 C.O.R1 LEN001 LEN008 9 Sta.R0 34 Sta.T0 34 Sta.T0 9 Sta.R0 LEN009 10 Sta.R1 35 Sta.T1...
Page 52 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE Power Failure Transfer (8PFT) The PZ-8PFTB card can be used as the PFT card at remote site. • This ﬁgure shows an outline of a PFT (PZ-8PFTB) connection PFT Connection Outline (8PFT) PZ-8PFTB Remote PIM PN-8LC PN-8COT...
Page 53 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE • Install the PZ-8PFTB card to the PIM according to the following steps. (1) Mount the PZ-8PFTB card into the PFT slot of the PIM. (2) Connect the champ connectors of 25-pair cables to the PFT0 and PFT1 connectors on the PZ-8PFTB card as shown below.
Page 54 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE (3) Connect the 25-pair cables on the MDF. • This ﬁgure shows the PFT connector pin assignment for each PFT circuit number (No. 0-No. 7). PFT Connector Pin Assignment PFT0 PFT1 Sta. R0 26 Sta.
Page 55 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE • This ﬁgure shows the MDF cross connection for the No. 0 circuit on the PFT (PZ-8PFTB), as an example. MDF Cross Connection for PFT (8PFT) TO C.O. LINE Ring Ring TO STATION REMOTE PIM PZ-8PFTB LTC0...
Page 56 CHAPTER 2 INSTALLATION INSTALLATION FOR REMOTE SITE MDF Cross Connection for PFT (8PFT) PFT0 CONNECTOR PFT0 (J) PFT0 (P) Sta. R0 26 Sta. T0 26 Sta. T0 Sta. R0 TO STATION 8LC. R0 27 8LC. T0 27 8LC. T0 8LC. R0 TO PN-8LC C.O.
Page 57 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE CONNECTION BETWEEN MAIN SITE AND REMOTE SITE DAI Connection at Main Site (1) When using the LTC connector on the BWB Connect the cable to a CSU or directly to the Remote PIM via the MDF as shown below. See example of DAI MDF cross connection on next page.
Page 58 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE Example of DAI MDF Cross Connection via LTC Connector (Main Site) PIM 0 LTC3 PN-DAIA/DAID RECEIVE AP09 SEND LTC3 PN-DAIC/DAIF TO CSU /REMOTE PIM RECEIVE AP10 SEND 2 LTC3 CONNECTOR 1 LTC3 CONNECTOR LTC (J) LTC (J)
Page 59 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE (2) When using the CN connector on the DAI Card Connect the cable to a CSU or directly to the Remote PIM via the CN connector on the DAIA/DAIC/DAID/DAIF card as shown below. DAI Cable Connection via CN Connector (Main Site) MAIN PIM DAIA/...
Page 60 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE DAI Connection at Remote Site Connect the cable to a CSU or directly to the Main PIM via the CN connector on the DAIB/DAIC/ DAIE/DAIF card as shown below. DAI Cable Connection via CN Connector (Remote Site) REMOTE PIM DAIB/ DAIC/...
Page 61 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE Optical Cable Connection When you use an optical cable to connect between the Main PIM and Remote PIM, connect the cable each other to the CN1 connector of the M10 cards in both sites. Two DAI cards are con- nected to one M10 card, via MDF through LTC connector on the BWB or CN connector on the DAI card.
Page 62 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE Example of M10 MDF Cross Connection via LTC Connector (Main Site) PIM 0 LTC3 PN-DAIC/DAIF RECEIVE AP09 SEND LTC3 PN-DAIA/DAID RECEIVE AP10 SEND LTC1 PN-M10 RECEIVE No. 1 SEND LT05 RECEIVE No.
Page 63 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE Example of M10 MDF Cross Connection via LTC Connector (Main Site) 1 LTC3 CONNECTOR LTC (J) 2 LTC3 CONNECTOR LTC (J) 3 LTC1 CONNECTOR LTC (J) – 53 – 99047-10...
Page 64 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE Example of M10 MDF Cross Connection via CN Connector (Remote Site) REMOTE PIM PN-DAIC/DAIF RECEIVE AP10 SEND PN-DAIB/DAIE RECEIVE MP12 SEND LTC1 PN-M10 RECEIVE No. 1 SEND LT05 RECEIVE No. 0 SEND SEND TO MAIN PIM PN-M10 CARD...
Page 65 CHAPTER 2 INSTALLATION CONNECTION BETWEEN MAIN SITE AND REMOTE SITE/MP RESET Example of M10 MDF Cross Connection via CN Connector (Remote Site) 1 CN CONNECTOR 2 LTC1 CONNECTOR LTC (J) MP RESET After mounting all DAI cards/M10 cards and connecting between main site and remote site, press SW1 switch on the MP card.
Page 66 THIS PAGE LEFT BLANK INTENTIONALLY. – 56 – 99047-10...
Page 67 CHAPTER 3 TROUBLESHOOTING CHAPTER 3 TROUBLESHOOTING This chapter explains the method for fault diagnosis and troubleshoot- ing when maintenance personnel detect the fault occurrence by lamp indication on DAIA/DAIB/DAIC/DAID/DAIE/DAIF and M10 cards. For other system fault, refer to the Maintenance Manual. –...
Page 68 CHAPTER 3 TROUBLESHOOTING This table shows contents of the fault and the remedial action on each lamp status. Remedial Action on Each Lamp Status CARD NAME LAMP STATUS FAULT CONTENT REMEDIAL ACTION PN-DAIA RUN lamp is not Abnormal operation 1 Reset the MB switch. (DAIA) ﬂashing of DAIA card...
Page 69 CHAPTER 3 TROUBLESHOOTING Remedial Action on Each Lamp Status CARD NAME LAMP STATUS FAULT CONTENT REMEDIAL ACTION PN-DAIB RUN lamp is not Abnormal operation 1 Reset the MB switch. (DAIB) ﬂashing of DAIB card (Down→Up→Down) 2 If the fault can not be cleared, replace the card.
Page 70 CHAPTER 3 TROUBLESHOOTING Remedial Action on Each Lamp Status CARD NAME LAMP STATUS FAULT CONTENT REMEDIAL ACTION PN-DAIC RUN lamp is not Abnormal operation 1 Reset the MB switch. (DAIC) ﬂashing of DAIC card (Down→Up→Down) 2 If the fault can not be cleared, replace the card.
Page 71 CHAPTER 3 TROUBLESHOOTING Remedial Action on Each Lamp Status CARD NAME LAMP STATUS FAULT CONTENT REMEDIAL ACTION PN-DAID RUN lamp is not Abnormal operation 1 Reset the MB switch. (Down → Up → Down) (DAID) ﬂashing of DAID card 2 Check the setting of SW1. 1: FP No.
Page 72 CHAPTER 3 TROUBLESHOOTING Remedial Action on Each Lamp Status CARD NAME LAMP STATUS FAULT CONTENT REMEDIAL ACTION PN-DAIE RUN lamp is not Abnormal operation 1 Reset the MB switch. (DAIE) ﬂashing of DAIE card (Down→Up→Down) 2 If the fault can not be cleared, replace the card.
Page 73 CHAPTER 3 TROUBLESHOOTING Remedial Action on Each Lamp Status CARD NAME LAMP STATUS FAULT CONTENT REMEDIAL ACTION PN-DAIF RUN lamp is not Abnormal operation 1 Reset the MB switch. (Down → Up → Down) (DAIF) ﬂashing of DAIF card 2 If the fault can not be cleared, replace the card.
Page 74 CHAPTER 3 TROUBLESHOOTING Remedial Action on Each Lamp Status CARD NAME LAMP STATUS FAULT CONTENT REMEDIAL ACTION PN-M10 (M10) CK0 lamp is not on Cable connection 1 Check to see if the cable failure between Digi- between Digital Trunk Inter- tal Trunk Interface face and M10 is correctly and No.
Page 75 CHAPTER 4 CIRCUIT CARD INFORMATION CHAPTER 4 CIRCUIT CARD INFORMATION This chapter explains the mounting location, the meaning of lamp in- dications, and the method of switch settings of each circuit card for the Remote PIM. HOW TO READ THIS CHAPTER ..........MOUNTING LOCATION OF CIRCUIT CARD ......
Page 76 CHAPTER 4 CIRCUIT CARD INFORMATION HOW TO READ THIS CHAPTER HOW TO READ THIS CHAPTER This chapter explains each circuit card used in this system about the following items. Explana- tions are given in the alphabetical order of the circuit card names within each circuit card cate- gory (Control, Application Processor, and Line/Trunk).
Page 77 CHAPTER 4 CIRCUIT CARD INFORMATION MOUNTING LOCATION OF CIRCUIT CARD MOUNTING LOCATION OF CIRCUIT CARD This section explains the conditions for mounting circuit cards for the Remote PIM. This ﬁgure shows circuit card mounting slots allocated in the PIM. Mounting Location of Circuit Card AC/DC LTC1 LTC3...
Page 78 CHAPTER 4 CIRCUIT CARD INFORMATION LIST OF REQUIRED CARD LIST OF REQUIRED CARD The table below shows the required cards to be explained in this section. List of Required Card EXTRACTION/ INSERTION WITH LAMP SWITCH POWER ON NAME X: PROVIDED X: PROVIDED REFERENCE X: ALLOWED...
Page 79 PN-CP15 (FP) PN-CP15 (FP) Locations of Lamps, Switches, and Connectors SENSE Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while the circuit card is operating normally. – 69 – 99069-10...
Page 80 PN-CP15 (FP) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE For setting FP No. (Rotary SW) For mounting this card in PIM0 For mounting this card in PIM2 For mounting this card in PIM4 For mounting this card in PIM6 NOTE 1 Not used MB (Toggle SW)
Page 81 PN-DAIA (DAI) PN-DAIA (DAI) Location of Lamps, Switches and Connectors SENSE LINK LOOP PCM1 PCM0 Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. LINK Green Remains lit when a link between this card and a distant ofﬁce is normally connected.
Page 82 PN-DAIA (DAI) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE FP (Firmware Processor) Number setting for the (Rotary SW) DAIA card. By this setting, the system regards the DAIA card and the opposite DAIB card as one Firmware Pro- cessor.
Page 83 PN-DAIA (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Control channel signaling data SW2 (Dip SW) transmission speed: 48kbps Control channel signaling data 1 2 3 4 5 6 7 8 transmission speed: 64kbps DTI frame conﬁguration: 12-Multi Frame DTI frame conﬁguration: 24-Multi Frame Line code: AMI with ZCS...
Page 84 PN-DAIA (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW3 (Dip SW) Set the equalizer according to the cable length between the system 1 2 3 4 and the CSU. CABLE LENGTH 0 - 40m (0-131.2ft.) 40 - 80m (131.2-262.5ft.) 80 - 120m (262.5-394ft.)
Page 85 PN-DAIA (DAI) NOTE 3: When the source clock signal is supplied via the line between the main site and the re- mote site, set the SW1-1 and SW1-2 as the following table. In this case, DAIA cards (DAIA0, DAIA1) must be mounted in PIM0. DAIA0 DAIA1 DAIA2...
Page 86 PN-DAIB (DAI) PN-DAIB (DAI) Location of Lamps, Switches and Connectors SENSE LINK LOOP Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. LINK Green Remains lit when a link between this card and a distant ofﬁce is normally connected.
Page 87 PN-DAIB (DAI) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE Always set to 0 (Rotary SW) Not used MB (Toggle SW) For make-busy For normal operation DOWN NOTE1 Always set to OFF (Piano Key SW) Always set to OFF Always set to OFF Always set to OFF Continued on next page...
Page 88 PN-DAIB (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Control channel signaling data SW2 (Dip SW) transmission speed: 48kbps Control channel signaling data 1 2 3 4 5 6 7 8 transmission speed: 64kbps DTI frame conﬁguration: 12-Multi Frame DTI frame conﬁguration: 24-Multi Frame Line code: AMI with ZCS...
Page 89 PN-DAIB (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW3 (Dip SW) Set the equalizer according to the cable length between the system 1 2 3 4 and the CSU. CABLE LENGTH 0 - 40m (0-131.2ft.) 40 - 80m (131.2-262.5ft.) 80 - 120m (262.5-394ft.)
Page 90 PN-DAIC (DAI) PN-DAIC (DAI) Location of Lamps, Switches and Connectors LINK LOOP TBUS RBUS Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. LINK Green Remains lit when the following connection are normal. •...
Page 91 PN-DAIC (DAI) Switch Settings SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION MB (Toggle SW) For make-busy For normal operation DOWN NOTE Always set to OFF (Piano Key SW) Always set to OFF Always set to OFF Always set to OFF SW2 (Dip SW) Not used DTI frame conﬁguration: 12-Multi...
Page 92 PN-DAIC (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW3 (Dip SW) Set the equalizer according to the cable length between the system and the CSU. 1 2 3 4 CABLE LENGTH 0 - 40m (0-131.2ft.) 40 - 80m (131.2-262.5ft.) 80 - 120m (262.5-394ft.)
Page 93 PN-DAID (DAI) PN-DAID (DAI) Location of Lamps, Switches and Connectors SENSE LINK LOOP PCM1 PCM0 Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. LINK Green Remains lit when a link between this card and a distant ofﬁce is normally connected.
Page 94 PN-DAID (DAI) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE FP (Firmware Processor) Number setting for the (Rotary SW) DAID card. By this setting, the system regards the DAID card and the opposite DAIE card as one Firmware Pro- cessor.
Page 95 PN-DAID (DAI) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW2 (Dip SW) Control channel signaling data transmission speed: 48kbps Control channel signaling data 1 2 3 4 5 6 7 8 transmission speed: 64kbps CRC Synchronization Detection Timer is provided. CRC Synchronization Detection Timer is not provided.
Page 96 PN-DAID (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW2 (Dip SW) Setting of control signal time slot SWITCH NUMBER TIME SLOT NUMBER 1 2 3 4 5 6 7 8 TS 1 TS 2 TS 3 TS 4 TS 5 TS 6 TS 7...
Page 97 PN-DAID (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW3 (Dip SW) Always set to ON Always set to ON 1 2 3 4 Always set to ON Always set to OFF JPS (Jumper pin) Balanced transmission: 120 ohms Right (For twisted-pair cable) TA is grounded on the transmission...
Page 98 PN-DAID (DAI) NOTE 3: When the source clock signal is supplied via the line between the main site and the re- mote site, set the SW1-1 and SW1-2 as the following table. In this case, DAID cards (DAID0, DAID1) must be mounted in PIM0. DAID0 DAID1 DAID2...
Page 99 PN-DAIE (DAI) PN-DAIE (DAI) Location of Lamps, Switches and Connectors SENSE LINK LOOP Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. LINK Green Remains lit when a link between this card and a distant ofﬁce is normally connected.
Page 100 PN-DAIE (DAI) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE Always set to 0 (Rotary SW) Not used MB (Toggle SW) For make-busy For normal operation DOWN NOTE1 Always set to OFF (Piano Key SW) Always set to OFF Always set to OFF Always set to OFF Control channel signaling data...
Page 101 PN-DAIE (DAI) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW2 (Dip SW) Setting of control signal time slot SWITCH NUMBER TIME SLOT NUMBER 1 2 3 4 5 6 7 8 TS 1 TS 2 TS 3 TS 4 TS 5 TS 6 TS 7...
Page 102 PN-DAIE (DAI) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW3 (Dip SW) Always set to ON Always set to ON 1 2 3 4 Always set to ON Always set to OFF JPS (Jumper pin) Balanced transmission: 120 ohms Right (For twisted-pair cable) TA is grounded on the transmission...
Page 103 PN-DAIF (DAI) PN-DAIF (DAI) Location of Lamps, Switches and Connectors LINK LOOP TBUS RBUS Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. LINK Green Remains lit when the following connection are normal. •...
Page 104 PN-DAIF (DAI) Switch Settings SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION MB (Toggle SW) For make-busy For normal operation DOWN NOTE Always set to OFF (Piano Key SW) Line impedance: 75 ohms (For coaxial cable) Line impedance: 120 ohms (For twisted-pair cable) Always set to OFF Always set to OFF...
Page 105 PN-DAIF (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW2 (Dip SW) Control channel signaling data transmission speed: 48kbps 1 2 3 4 5 6 7 8 Control channel signaling data transmission speed: 64kbps CRC Synchronization Detection Timer is provided. CRC Synchronization Detection Timer is not provided.
Page 106 PN-DAIF (DAI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW3 (Dip SW) Always set to ON Always set to ON 1 2 3 4 Always set to ON When mounting this card on remote site. When mounting this card on main site.
Page 107 PN-M10 (M10) PN-M10 (M10) Location of Lamps, Switches and Connectors TALM RALM CN1 TO OPTICAL CABLE Lamp Indications LAMP COLOR FUNCTION NAME Green Remains lit when a Digital Trunk Interface is connected to No. 0 circuit on this card. Green Remains lit when a Digital Trunk Interface is connected to No.
Page 108 PN-M10 (M10) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION JP0, 1 When connected to E1 (2M) Digital (Jumper pin) Trunk Interface. When connected to T1 (1.5M) Digi- DOWN tal Trunk Interface. JP2 (Jumper pin) Line code: B8ZS* is provided (For T1 interface) Right *B8ZS: Bipolar Eight Zero Substitu-...
