ND-70922(E)
ISSUE 1
Open Application Interface (OAI)
System Manual
DECEMBER, 1999
NEC Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEAX 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for NEC NEAX 2000

Summary of Contents for NEC NEAX 2000

  • Page 1 ND-70922(E) ISSUE 1 Open Application Interface (OAI) System Manual DECEMBER, 1999 NEC Corporation...
  • Page 2 NEC Corporation reserves the right to change the specifications, functions, or features, at any time, without notice. NEC Corporation has prepared this document for use by its employees and customers. The information contained herein is the property of NEC Corporation and shall not be reproduced without prior written approval from NEC Corporation.
  • Page 3 ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE DECEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX Open Application Interface (OAI) System Manual Revision Sheet 1/2 ND-70922(E)
  • Page 4 ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE DECEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX Open Application Interface (OAI) System Manual Revision Sheet 2/2 ND-70922(E)

  • Page 5: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ............................PURPOSE ............................. OUTLINE OF THIS MANUAL ......................REFERENCE MANUALS ........................ CHAPTER 1 GENERAL INFORMATION ..................SYSTEM OUTLINE ..........................OAI with RS-232C ........................... OAI with TCP/IP-Ethernet ......................SYSTEM SPECIFICATIONS ......................RS-232C Interface Specification ....................MODEM Specification ........................
  • Page 6 TABLE OF CONTENTS TROUBLESHOOTING FOR OAI WITH TCP/IP-ETHERNET ..........Troubleshooting Information for ETHER Card ................ Troubleshooting Information for PN-AP01 Card ..............Replacement Procedure for PN-AP01/PN-CC01 Card ............CHAPTER 5 CIRCUIT CARD INFORMATION ................HOW TO READ THIS CHAPTER ....................MOUNTING LOCATION OF CIRCUIT CARD ................

  • Page 7: Introduction

    Open Application Interface (OAI) to the NEAX 2000IVS /NEAX 7400ICS M100MX/NEAX 2000 INTEGRATED VOICE SERVER. OUTLINE OF THIS MANUAL This manual consists of 5 chapters and appendix. The contents of chapters 1 through 5 and ap-...

  • Page 8: Reference Manuals

    INTRODUCTION REFERENCE MANUALS REFERENCE MANUALS During installation, refer also to the manuals below: Installation Procedure Manual: describes the installation procedure of the PBX system. Command Manual: describes Customer Administration Terminal (CAT) operation, command function and setting data required for programming the system, and Resident System Program. Office Data Programming Manual: contains the Customer Specification Sheet and Office Data Programming Sheet.

  • Page 9: Chapter 1 General Information

    CHAPTER 1 GENERAL INFORMATION CHAPTER 1 GENERAL INFORMATION This chapter explains the system outline and specifications of OAI system. SYSTEM OUTLINE ..............SYSTEM SPECIFICATIONS ............. – 3 – 9G003-10...

  • Page 10: System Outline

    CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE OAI with RS-232C SYSTEM OUTLINE The PBX is equipped with an interface to provide user applications through an external proces- sor. The interface supports RS-232C (Free Wheel) protocol and TCP/IP protocol. OAI with RS-232C For adding the interface with RS-232C, the AP01 card (OAI Interface Card) is required.
  • Page 11 CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE OAI with RS-232C External Processor Connection for RS-232C Interface (1) External Processor Direct Connection EXTERNAL PROCESSOR AP01 (RS-232C) RS RVS-4(S) CA-A/RS RVS-4(S) CA-C (4 m/13.1 ft.) RS RVS-15(S) CA-A (15 m/49 ft.) page 6 (See next page) (2) External Processor Connection via MODEM EXTERNAL...
  • Page 12 CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE OAI with RS-232C RS RVS-15 CA-A/RS RVS-15S CA-A RS RVS-4 CA-A/RS RVS-4 CA-C RS RVS-4S CA-A/RS RVS-4S CA-C NOTE: If the external processor does not send DTR or RTS signal, cut the signal lead marked by X in the D-Sub connector (external processor side) as shown in the wiring diagram above.
  • Page 13 CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE OAI with RS-232C See APPENDIX DEFINITION OF V.24 SIGNAL LEADS. page 79 RS NORM-4 CA-A/RS NORM-4S CA-A (4 m/13 ft.) 06D-TXC (1) 24-TXC (2) 06B-RXC 17-RXC 06A-TXC (2) 15-TXC (1) 20-DSR 05C-DTR 05B-GND 01-GND 05A-TXD 02-RXD 04B-RXD...

  • Page 14: Oai With Tcp/Ip-Ethernet

    CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE OAI with TCP/IP-Ethernet OAI with TCP/IP-Ethernet The PBX is equipped with an interface to transmit/receive the control signals between the PBX and the Ethernet. The interface supports TCP/IP protocol. For adding the interface with TCP/IP, the ETHER card (CC01) (Ethernet Gateway Controller) is required in addition to the AP01 card.

  • Page 15: System Specifications

    CHAPTER 1 GENERAL INFORMATION SYSTEM SPECIFICATIONS RS-232C Interface Specification/MODEM Specification SYSTEM SPECIFICATIONS RS-232C Interface Specification RS-232C Interface Specification DESCRIPTION SPECIFICATION REMARKS Transmission Speed 150, 300, 600, 1200, 2400, 4800 or 9600 bps Synchronization Asynchronous Transmission Mode Full Duplex Parity No Parity Stop Bit 1-Stop Bit Kind of Code...
  • Page 16 THIS PAGE LEFT BLANK INTENTIONALLY. – 10 – 9G004-10...

  • Page 17: Chapter 2 Installation

    CHAPTER 2 INSTALLATION CHAPTER 2 INSTALLATION This chapter explains the hardware installation procedure to provide OAI interface to the PBX. PRECAUTIONS ................. REQUIRED EQUIPMENT ............INSTALLATION PROCEDURE ..........– 11 – 9G011-10...

  • Page 18: Precautions

    CHAPTER 2 INSTALLATION PRECAUTIONS PRECAUTIONS Static Electricity Guard You must wear a grounded wrist strap to protect circuit cards from static electricity. Static Electricity Guard • WHEN PLUGGING/UNPLUGGING A CIRCUIT CARD FRAME GROUND SCREW WRIST STRAP • WHEN HOLDING A CIRCUIT CARD NEVER TOUCH THE COMPONENTS OR SOLDERED SURFACE WITH BARE HANDS.
  • Page 19 CHAPTER 2 INSTALLATION PRECAUTIONS Static Electricity Guard • WHEN MAKING A SWITCH SETTING ON A CIRCUIT CARD CIRCUIT CARD WEAR A WRIST STRAP AND PERFORM THE WORK ON A GROUNDED CONDUCTIVE WORK SURFACE. • WHEN CARRYING A CIRCUIT CARD CONDUCTIVE CIRCUIT POLYETHYLENE CARD...
  • Page 20 CHAPTER 2 INSTALLATION PRECAUTIONS CAUTION You must hold the edge of a circuit card when plugging or unplugging the circuit card. If you touch another area, you may be exposed to hazard voltages. NEVER TOUCH THE COMPO- NENTS OR SOLDERED SUR- FACE WITH BARE HANDS.

  • Page 21: Required Equipment

    CHAPTER 2 INSTALLATION REQUIRED EQUIPMENT Required Equipment for OAI with RS-232C Interface REQUIRED EQUIPMENT The following tables show the required equipment when the OAI is provided through an external processor with RS-232C interface, or through the Ethernet with TCP/IP. Required Equipment for OAI with RS-232C Interface Required Equipment for OAI with RS-232C Interface EQUIPMENT DESCRIPTION...

  • Page 22: Required Equipment For Oai With Tcp/Ip-Ethernet

    CHAPTER 2 INSTALLATION REQUIRED EQUIPMENT Required Equipment for OAI with TCP/IP-Ethernet Required Equipment for OAI with TCP/IP-Ethernet Required Equipment for OAI with TCP/IP-Ethernet EQUIPMENT DESCRIPTION REMARKS • PN-AP01 OAI Interface Card • PN-CC01 Ethernet Control Card NOTE • 48-TW-0.3 CONN CA BUS Cable between PN-AP01 Cable length: and PN-CC01...

  • Page 23: Installation Procedure

    CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Installation Procedure for OAI with RS-232C/Installation Procedure for OAI with TCP/IP-Ethernet INSTALLATION PROCEDURE Installation Procedure for OAI with RS-232C Install the OAI system with RS-232C interface according to the following procedure. Installation Procedure for OAI with RS-232C Interface START page 18 Mounting PN-AP01 Card...

  • Page 24: Mounting Pn-Ap01 Card

    CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Mounting PN-AP01 Card Mounting PN-AP01 Card (1) Confirm the correct switch settings. See CHAPTER 5. page 65 Before mounting the card, set the MB switch to UP position. ATTENTION Contents Static Sensitive: (2) Mount the PN-AP01 card in one of the following AP slots. Handling Precautions Required PIM 0 : AP00-AP10 slot...

  • Page 25: Mounting Pn-Cc01 Card

    CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Mounting PN-CC01 Card Mounting PN-CC01 Card (1) Confirm the correct switch settings. See CHAPTER 5. page 65 ATTENTION (2) Mount the PN-CC01 card in one of the following AP slots. Contents Static Sensitive: Handling Precautions Required PIM 0 : AP00-AP10 slot PIM 1-7: AP00-AP11 slot –...

  • Page 26: Mounting Pn-Cp15 Card

    CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Mounting PN-CP15 Card Mounting PN-CP15 Card (1) Confirm the correct switch settings. See CHAPTER 5. page 65 Before mounting the card, set the MB switch to UP position. ATTENTION Contents Static Sensitive: (2) Mount one PN-CP15 card in the each FP slot of PIM0, PIM2, PIM4 and Handling Precautions Required PIM6, according to the system configuration.

  • Page 27: Cabling Between Pn-Ap01 Card And External Processor

    CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Cabling between PN-AP01 Card and External Processor Cabling between PN-AP01 Card and External Processor (1) Connect the RS RVS cable or RS NORM cable onto the “RS0” connector on the PN-AP01 card, as shown below. Cable Running of RS RVS Cable/RS NORM Cable PN-AP01 RS RVS-4(S) CA-A/RS RVS-4(S) CA-C...
  • Page 28 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Cabling between PN-AP01 Card and External Processor (2) Connect the RS RVS cable or RS NORM cable as shown below. When connecting an External Processor directly: Connect the External Processor to the PN-AP01 using an RS RVS-4(S) CA-A/RS RVS-4(S) CA-C/RS RVS-15(S) CA-A cable as shown below.

  • Page 29: Cabling Bus Cable And 10 Base-T Cable

    CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Cabling BUS Cable and 10 BASE-T Cable Cabling BUS Cable and 10 BASE-T Cable (1) Connect the 48-TW-0.3 CONN CA (BUS cable) onto the “IP” connector on the PN-CC01 card, as shown below. (2) Connect the 10 BASE-T twisted pair cable (TIA/EIA category 3 or larger) onto the “10 BASE-T”...
  • Page 30 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE Cabling BUS Cable and 10 BASE-T Cable (3) Connect the 48-TW-0.3 CONN CA onto the “IP” connector on the PN-AP01 card, as shown below. (4) Connect the 10 BASE-T twisted pair cable (TIA/EIA category 3 or larger) onto the 10 BASE- T HUB on the Ethernet.

  • Page 31: System Data Programming

    CHAPTER 3 SYSTEM DATA PROGRAMMING CHAPTER 3 SYSTEM DATA PROGRAMMING This chapter explains the programming procedure to provide OAI fea- ture to the PBX. HOW TO READ THIS CHAPTER ..........LIST OF COMMANDS RELATED TO OAI......... AP01 INITIALIZATION .............. OAI COMMUNICATION DATA ASSIGNMENT (TCP/IP) ..OAI COMMUNICATION DATA ASSIGNMENT (RS-232C) ..

  • Page 32: How To Read This Chapter

    CHAPTER 3 SYSTEM DATA PROGRAMMING HOW TO READ THIS CHAPTER AP Initialization/Preparation before Programming HOW TO READ THIS CHAPTER AP Initialization When first programming the OAI system data, initialize the PN-AP01 card using the procedure described in “AP01 Initialization”. Preparation before Programming Before programming, confirm that the system is under the following conditions.

  • Page 33: List Of Commands Related To Oai

    CHAPTER 3 SYSTEM DATA PROGRAMMING LIST OF COMMANDS RELATED TO OAI LIST OF COMMANDS RELATED TO OAI The following table shows the commands related to the OAI with each facility (MSF, TMF etc.). List of Commands Related to OAI RELATED COMMAND ITEM COMMAND 1ST DATA...
  • Page 34 CHAPTER 3 SYSTEM DATA PROGRAMMING LIST OF COMMANDS RELATED TO OAI List of Commands Related to OAI RELATED COMMAND ITEM COMMAND 1ST DATA 2ND DATA MEANING CM10 000-763 EB000-EB127 Digital Announcement Trunk Card CM12 Y=02 Station No. 00-15 Service Restriction Class CM15 Y=59 00-15 CM20 Y=0-3...
  • Page 35 CHAPTER 3 SYSTEM DATA PROGRAMMING LIST OF COMMANDS RELATED TO OAI List of Commands Related to OAI RELATED COMMAND ITEM COMMAND 1ST DATA 2ND DATA MEANING CMD7 Y=0 F1032-F1047 192-255 TMF Operation Code CMD7 Y=0 F1032-F1047 DCX (X=1-3) Digit Number of Digit Code CMD7 Y=3 000-127 RR Timer...
  • Page 36 CHAPTER 3 SYSTEM DATA PROGRAMMING LIST OF COMMANDS RELATED TO OAI List of Commands Related to OAI RELATED COMMAND ITEM COMMAND 1ST DATA 2ND DATA MEANING CM42 01-06 Account Code Max. digit (SCF FID=1, 3, 4, 7) CM49 Y=00 000-127 10/1602-1663 Announcement Service for OAI/ Message Group No.
  • Page 37 CHAPTER 3 SYSTEM DATA PROGRAMMING LIST OF COMMANDS RELATED TO OAI List of Commands Related to OAI RELATED COMMAND ITEM COMMAND 1ST DATA 2ND DATA MEANING CMD5 Y=3 ID code ABBCCDDEE Temporary Class Data CMD7 Y=3 000-127 RR Timer CMD7 Y=5 XXXX Office Number CMD7 Y=B...
  • Page 38 CHAPTER 3 SYSTEM DATA PROGRAMMING LIST OF COMMANDS RELATED TO OAI List of Commands Related to OAI RELATED COMMAND ITEM COMMAND 1ST DATA 2ND DATA MEANING term CM08 subline CM08 SMFN STS (Status) CM08 SMFN when answering a held call CM08 ANI/Caller ID/CPN to OAI Terminal CM08...

  • Page 39: Ap01 Initialization

    CHAPTER 3 SYSTEM DATA PROGRAMMING AP01 INITIALIZATION AP01 INITIALIZATION DESCRIPTION DATA START CM05 Assign an AP number to the AP01 card. • AP Number (04-15) INITIAL 07: AP01 card NOTE: The AP number must match the SENSE switch settings on the AP01 card.

  • Page 40: Oai Communication Data Assignment (Tcp/Ip)

    CHAPTER 3 SYSTEM DATA PROGRAMMING OAI COMMUNICATION DATA ASSIGNMENT (TCP/IP) OAI COMMUNICATION DATA ASSIGNMENT (TCP/IP) DESCRIPTION DATA START CMD7 Assign the IP Address of TCP/IP-Ethernet. • NOTE 1, NOTE 2 00-03: Division No. of IP Address 0-255: Address Data (1-3 digits) AP01 INITIAL NOTE 1: The IP Address must be assigned to the 1st data 00-03 as follows.
  • Page 41 CHAPTER 3 SYSTEM DATA PROGRAMMING OAI COMMUNICATION DATA ASSIGNMENT (TCP/IP) IP Address Assignment Patterns (PN-CC01 Card) INPUT DATA (2ND DATA) PATTERN ASSIGNED DATA When no data 4C.A4.XX.XX (HEX) or all 0 is input 4C.A4: Fixed XX.XX: According to the switch setting of SW1 (D15-D8) and No data No data...

  • Page 42: Oai Communication Data Assignment (Rs-232C)

    CHAPTER 3 SYSTEM DATA PROGRAMMING OAI COMMUNICATION DATA ASSIGNMENT (RS-232C) OAI COMMUNICATION DATA ASSIGNMENT (RS-232C) DESCRIPTION DATA START Assign the attribute data for RS-232C port Y=04 Data Transmission Speed of RS- CMA6 • of the PN-AP01. 232C port AP01 INITIAL 0: 150 bps 1: 300 bps 2: 600 bps...
  • Page 43 CHAPTER 3 SYSTEM DATA PROGRAMMING OAI COMMUNICATION DATA ASSIGNMENT (RS-232C) DESCRIPTION DATA CMA6 • Y=08 Stop Bit AP01 INITIAL 1 : 1-Stop Bit Y=09 Type of Code • 06: JIS (8-bit) Y=10 Flow Control by DCD Signal • 0 : Ineffective 1 : Effective Y=11 RTS Signal Control •...

  • Page 44: Data Assignment For Msf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR MSF DATA ASSIGNMENT FOR MSF term To start up MSF from D by using an OAI function key: DESCRIPTION DATA START CM90 Assign the OAI function key for starting up Y=00 • term MSF to a D My Line No.
  • Page 45 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR MSF term To start up MSF from PB Telephone/D by using an access code: DESCRIPTION DATA START CM12 Assign the Service Restriction Class for Y=02 • starting up MSF to the required stations. X-XXXX: Station No.
  • Page 46 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR MSF DESCRIPTION DATA CMD7 When sending a message through the Digital Announcement Trunk (PN-2DATA) term to PB telephone/D user by using TCF- D facility: When sending a tone to PB telephone/ term user by using TCF-D facility: When not sending a message or tone: –...
  • Page 47 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR MSF DESCRIPTION DATA CM10 Assign a Digital Announcement Trunk card LEN: 000-763 number to the required LEN. EB002-EB127: Digital Announcement Trunk Card No. NOTE 1: The Digital Announcement Trunk For PIM0/1: EB002-EB031 card number must be assigned For PIM2/3: EB032-EB063 to the first LEN (Level 0), the...
  • Page 48 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR MSF DESCRIPTION DATA CM41 Specify the tone sending timer in the OAI • terminal mode, if required. 01-99: 0-396 sec. (4 sec. increments) If no data is set, the default setting is 20-24 sec.

  • Page 49: Data Assignment For Tmf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR TMF DATA ASSIGNMENT FOR TMF DESCRIPTION DATA START Assign the OAI function key for starting up Y=00 CM90 • term TMF to a D My Line No. + + Key No. F1032-F1047: OAI Function Key No.
  • Page 50 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR TMF DESCRIPTION DATA term CMD7 Specify a chime from D when receiving • RR signal of TMF. F1032-F1047: OAI Function Key No. 0-15 00 : Not sent 01 : To send term Specify a chime from D when setting •...

  • Page 51: Data Assignment For Scf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SCF DATA ASSIGNMENT FOR SCF To provide Call Origination with Ringing (FID=3): DESCRIPTION DATA START Assign the Ringing Tone Sending time for CM41 • SCF of OAI. 65: OAI RGT Sending Time 01-99: 4-396 sec.
  • Page 52 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SCF If the Digital Announcement Trunk or Tone is provided, do the following programming: DESCRIPTION DATA START CM10 Assign a Digital Announcement Trunk card LEN: 000-763 number to the required LEN. EB002-EB127: Digital Announcement Trunk Card No.
  • Page 53 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SCF To provide Queue Connection (FID=4): DESCRIPTION DATA START CM17 Assign the UCD group. • X-XXXX: Station No. X-XXXX: Another station No. to be linked Assign the Pilot station and Member sta- Y=1 Distinction of Member station from •...
  • Page 54 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SCF To provide Announcement Call (FID=5): DESCRIPTION DATA START Assign a Digital Announcement Trunk card LEN: 000-763 CM10 number to the required LEN. EB002-EB127: Digital Announcement Trunk Card No. NOTE 1: The Digital Announcement Trunk For PIM0/1: EB002-EB031 card number must be assigned For PIM2/3: EB032-EB063...
  • Page 55 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SCF DESCRIPTION DATA CM49 Assign the function of the Digital An- • Y=00 nouncement Trunk card. 000-001: Built-in DAT on MP card 002-127: Digital Announcement Trunk Card No. assigned by CM10 (EB002-EB127) 10: Announcement Service for OAI 16 XX XX: Message Group No.
  • Page 56 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SCF To provide Conversation Monitoring (FID=6) and Call Conferencing (FID=8): DESCRIPTION DATA START CM41 Assign the Ringing Tone Sending time for • SCF of OAI. 65: OAI RGT Sending Time 01-99: 4-396 sec. (4 sec. increments) If no data is set, the default setting is 12-16 sec.

  • Page 57: Data Assignment For Flf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR FLF DATA ASSIGNMENT FOR FLF DESCRIPTION DATA START CM20 Assign the access code to recognize Au- Y=0-3 • thorization Code for FLF. X-XXXX: Access Code A157 NOTE: The access code should be as- signed to the first one, two or three digits of Authorization Code.
  • Page 58 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR FLF DESCRIPTION DATA CMD7 Assign the recognition of AP database by • RR message. 0 : To provide 1 : Not provided Assign the omission of AP database for in- • formation added to RR message. 0 : Not omitted 1 : To omit Assign the office number.

  • Page 59: Data Assignment For Ktf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR KTF DATA ASSIGNMENT FOR KTF DESCRIPTION DATA START CM90 Assign the OAI function key for starting up Y=00 • term FLF to a D My Line No. + + Key No. F1032-F1047: OAI Function Key No. 0-15 –...

  • Page 60: Data Assignment For Acf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR ACF DATA ASSIGNMENT FOR ACF DESCRIPTION DATA START Specify the processor to check the ID CM08 Codes. 1 : AP (PN-AP01) Specify whether SST is sent after dialing the access code for ID Code Class 0 : No Tone Change or not.
  • Page 61 CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR ACF DESCRIPTION DATA Assign the return result waiting timer for CMD7 • the PBX sent facility. 000-127: 8-508 sec. (4-sec. increments) If no data is set, the default setting is 8 sec. Assign the office number.

  • Page 62: Data Assignment For Ssf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SSF DATA ASSIGNMENT FOR SSF DESCRIPTION DATA START CM08 Assign the Message Wait Indication (VM) for My Line only or My Line and sub-line on 0 : MW for My Line and sub-lines term 1 : MW for My Line only Whether Message Waiting/Message Re-...

  • Page 63: Data Assignment For Smf

    CHAPTER 3 SYSTEM DATA PROGRAMMING DATA ASSIGNMENT FOR SMF DATA ASSIGNMENT FOR SMF DESCRIPTION DATA START CM08 Assign the automatic setting of SMFR for term Sub line. 0 : Available 1 : Not available Specify OAI SMFN STS (status) for Call Transfer from a station.
  • Page 64 THIS PAGE LEFT BLANK INTENTIONALLY. – 58 – 9G056-10...

  • Page 65: Chapter 4 Troubleshooting

    CHAPTER 4 TROUBLESHOOTING CHAPTER 4 TROUBLESHOOTING This chapter explains the troubleshooting information after installing the OAI system. TROUBLESHOOTING FOR OAI WITH RS-232C...... TROUBLESHOOTING FOR OAI WITH TCP/IP-ETHERNET ..............– 59 – 9G059-10...

  • Page 66: Troubleshooting For Oai With Rs-232C

    CHAPTER 4 TROUBLESHOOTING TROUBLESHOOTING FOR OAI WITH RS-232C TROUBLESHOOTING FOR OAI WITH RS-232C This section explains the troubleshooting information for the OAI system with RS-232C. The table below shows the cause of trouble and the remedial action. Troubleshooting Information for OAI with RS-232C TROUBLE CAUSE ACTION...
  • Page 67 CHAPTER 4 TROUBLESHOOTING TROUBLESHOOTING FOR OAI WITH RS-232C Troubleshooting Information for OAI with RS-232-C TROUBLE CAUSE ACTION The system can- • In an external processor (RS- • Assign 0 (RTS Signal ON) as the not communicate 232C) connection via MODEM, 2nd data of CMA6 Y=11.
  • Page 68 CHAPTER 4 TROUBLESHOOTING TROUBLESHOOTING FOR OAI WITH TCP/IP-ETHERNET Troubleshooting Information for ETHER Card TROUBLESHOOTING FOR OAI WITH TCP/IP-ETHERNET This section explains the troubleshooting information for the OAI system with TCP/IP-Ethernet. The following table shows the cause of trouble and the remedial action. When a trouble occurs, do the remedial action.
  • Page 69 CHAPTER 4 TROUBLESHOOTING TROUBLESHOOTING FOR OAI WITH TCP/IP-ETHERNET Troubleshooting Information for PN-AP01 Card Troubleshooting Information for PN-AP01 Card Troubleshooting Information for PN-AP01 Card TROUBLE CAUSE ACTION The PN-AP01 does • The AP data (07) of PN-AP01 • Assign the AP data (07) by not set up.
  • Page 70 CHAPTER 4 TROUBLESHOOTING TROUBLESHOOTING FOR OAI WITH TCP/IP-ETHERNET Replacement Procedure for PN-AP01/PN-CC01 Card Replacement Procedure for PN-AP01/PN-CC01 Card When replacing the PN-AP01 card or the PN-CC01 card under power on, do the following pro- cedure. Procedure for PN-AP01 Card (a) When unplugging: STEP 1: Set the MB switch on the PN-AP01 card to the UP position.

  • Page 71: Circuit Card Information

    CHAPTER 5 CIRUIT CARD INFORMATION CHAPTER 5 CIRCUIT CARD INFORMATION This chapter explains the mounting location, the meaning of lamp in- dications, and the method of switch settings of each circuit card for OAI. HOW TO READ THIS CHAPTER ..........MOUNTING LOCATION OF CIRCUIT CARD ......

  • Page 72: How To Read This Chapter

    CHAPTER 5 CIRCUIT CARD INFORMATION HOW TO READ THIS CHAPTER HOW TO READ THIS CHAPTER This chapter explains each circuit card used in this system about the following items. Explana- tions are given in alphabetical order of the circuit card names within each circuit card category (Control, Application Processor, and Line/Trunk).

  • Page 73: Mounting Location Of Circuit Card

    CHAPTER 5 CIRCUIT CARD INFORMATION MOUNTING LOCATION OF CIRCUIT CARD MOUNTING LOCATION OF CIRCUIT CARD This section explains the conditions for mounting circuit cards for the OAI. This figure below shows circuit card mounting slots allocated in the PIM. Mounting Location of Circuit Card AC/DC LTC1 LTC3...

  • Page 74: List Of Required Circuit Card

    CHAPTER 5 CIRCUIT CARD INFORMATION LIST OF REQUIRED CIRCUIT CARD LIST OF REQUIRED CIRCUIT CARD The table below shows the required circuit cards to be explained in this section. List of Required Card EXTRACTION/ INSERTION WITH LAMP SWITCH POWER ON NAME X: PROVIDED X: PROVIDED...

  • Page 75: Pn-Cp15 (Fp)

    PN-CP15 (FP) PN-CP15 (FP) Locations of Lamps, Switches, and Connectors SENSE Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while the circuit card is operating normally. – 69 – 9G069-10...
  • Page 76 PN-CP15 (FP) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE For setting FP No. (Rotary SW) For mounting this card in PIM0 For mounting this card in PIM2 For mounting this card in PIM4 For mounting this card in PIM6 NOTE1 Not used MB (Toggle SW)

  • Page 77: Pn-Ap01 (Ap01)

    PN-AP01 (AP01) PN-AP01 (AP01) Locations of Lamps, Switches and Connectors SENSE Lamp Indications LAMP NAME COLOR FUNCTION Green Flashes at 120 IPM while this card is operating normally. L0-L3 Green Indication of CTS signal status on RS-232C port. Indication of DCD signal status on RS-232C port. Indication of TXD signal status on RS-232C port.
  • Page 78 PN-AP01 (AP01) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE Set the switch to match the AP Number (04-15) to (Rotary SW) be set by CM05. AP No. 04 05 06 07 08 09 10 11 12 13 14 15 SW No.
  • Page 79 PN-AP01 (AP01) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW0 (Dip SW) Receives RT clock Uses internal clock 1 2 3 4 Receives ST2 clock Uses internal clock Sends ST1 clock Not send ST1 clock Not used For normal operation RIGHT (Memory backup ON) (Jumper pin)

  • Page 80: Pn-Cc01 (Ether)

    PN-CC01 (ETHER) PN-CC01 (ETHER) Location of Lamps, Switches and Connectors LINK 10BASE-T – 74 – 9G074-10...
  • Page 81 PN-CC01 (ETHER) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 60 IPM while this card is operating normally. LINK Green Remains lit when link is established. Green Remains lit when it is transmitting the data. Green Remains lit when it is receiving the data. Green Remains lit only when it is receiving the data with its own IP address.
  • Page 82 PN-CC01 (ETHER) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW1 (Dip SW) 1 (D15) 2 (D14) ON:0 OFF:1 1 2 3 4 5 6 7 8 MAC ADDRESS SWITCH SETTING 3 (D13) 00004CA4 X X X X (HEX) 4 (D12) NOTE2 SW1-1 (D15) ON/OFF...
  • Page 83 PN-CC01 (ETHER) NOTE1: When the power is on, flip the MB switch to ON (UP position) before plugging/unplug- ging the Circuit card. NOTE2: Each equipment must have a unique MAC address to distinguish between systems. Therefore, when more than one PBX is installed in the same network, assign the lower 4 digits of the following MAC address by SW1 and SW2 to prevent duplicate address- 00004CA4 XX XX (HEX)
  • Page 84 THIS PAGE LEFT BLANK INTENTIONALLY. – 78 – 9G074-10...
  • Page 85 APPENDIX DEFINITION OF V.24 SIGNAL LEADS APPENDIX DEFINITION OF V.24 SIGNAL LEADS This appendix contains the definition of V.24 signal leads. DEFINITION OF V.24 SIGNAL LEADS ........– 79 – 9G079-10...
  • Page 86 APPENDIX: DEFINITION OF V.24 SIGNAL LEADS SIGNAL-NAME DIRECTION MEANING JIS C CCITT OF SIGNAL RS-232C ANOTHER 6361 V.24 (FG) Frame Ground Send Data Receive Data Request to Send Clear to Send Data Set Ready Signal Ground Data Channel Receive Carrier Detect Not used Not used...
