WS200
WS200_OwnersManual_120082_20230807
TREADMILL
Online Support
If you require assistance or are
experiencing issues with your
XTERRA Machine, please contact
customer care for additional help.
1-800-258-8511
questions@xterrafitness.com
Warranty Registration
Scan to quickly and easily
register your new XTERRA
Fitness machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS200 and is the answer not in the manual?

Questions and answers

Related Manuals for Xterra WS200

Summary of Contents for Xterra WS200

  • Page 1 Online Support If you require assistance or are experiencing issues with your XTERRA Machine, please contact customer care for additional help. 1-800-258-8511 questions@xterrafitness.com Warranty Registration Scan to quickly and easily register your new XTERRA WS200 Fitness machine. TREADMILL WS200_OwnersManual_120082_20230807...

  • Page 3: Table Of Contents

    Safety Stop Key ..............16 Technology and Features About Your Machine ............17 Console Screen - Overview ..........18 Window Display ..............19 Functions ................20 How to use the Treadmill ..........21 Using the XTERRA+ App ..........22 Wearing the Chest Strap ..........23...

  • Page 4: Product Registration

    Congratulations on your new treadmill, and welcome to the XTERRA WARRANTY REGISTRATION Fitness family! Thank you for your purchase of this quality unit from XTERRA Fitness. Your new unit was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.

  • Page 5: Product Labels

    PRODUCT LABELS SERIAL NUMBER STICKER SERIAL NUMBER This sticker will be found on the rear of the motor cover. Please record the number below the barcode for the purpose of registering your treadmill’s warranty. X XXXXXXXXX X (870) 336-4286 PROPOSITION 65 WARNING This sticker will be found on the rear of the motor cover.

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be 8. Never operate the appliance with the air openings blocked. Keep the air followed, including the following. Read all instructions before using this openings free of lint, hair, and the like. appliance.

  • Page 7: Electrical Safety

    ELECTRICAL SAFETY WARNING! Route the power cord away from any moving part of the unit Optimally the unit should be the only device plugged into the including the elevation mechanism and transport wheels. circuit. Our units have surge suppressors built in to help avoid nuisance tripping.

  • Page 8: Grounding & Location Requirements

    GROUNDING & LOCATION REQUIREMENTS This product must be grounded. If the unit should malfunction or Location Requirements breakdown, grounding provides a path of least resistance for electric current, reducing the risk of electric shock. This product is equipped with a After assembling your treadmill, you’ll need to make sure you’ve cord having an equipment-grounding plug.

  • Page 9: Parts Of Your Treadmill

    PARTS OF YOUR TREADILL A. Tablet Holder B. USB Type A & C Charger Port* C. LED Screen D. Safety stop key E. Hand pulse sensors F. Uprights G. Motor cover H. Belt I. Side rails J. Levelers K. Transport Handlebar L.

  • Page 10: Pack List

    PACK LIST Description Quantity 4.2 x 19mm Bolts 5mm Allen Key 6mm Allen Key Wrench Tablet Holder Power Cord Safety Key Silicone Oil Manual...

  • Page 11: Assembly

    ASSEMBLY Take out the treadmill from the carton and lay it aside on the smooth ground. Lift the Upright Crossbar (as shown in A) until it clicks into place at the top height. Upright Crossbar...
  • Page 12 ASSEMBLY - CONTINUED Press and hold the red button on the handle with your thumb as shown in step (B), and at the same time lift the handle up until the handle is locked, and release the button during the process of lifting the handle; (the same operation on the other side) As shown in step (C), rotate the left and right Handlebar Stoppers to the bottom of the main frame in the direction of the arrow so that they are not exposed to avoid damage.
  • Page 13 ASSEMBLY - CONTINUED Fix the Tablet Holder (D) to the underside of the Console using 6 cross-recessed countersunk head screws, and place the red Safety Key (E) onto the yellow area of the underside of the Console; Adjust the angle of the Tablet Holder, as shown in the image, slide the back panel of the bracket in the direction of the arrow to adjust the angle, turning it to a suitable angle.

  • Page 14: Setting Up Your Treadmill

    SETTING UP YOUR TREADMILL Plugging in and Powering On As shown in the figure below, insert the power cord into the socket on the right side of the treadmill. Plug in the power supply and turn on the power switch of the machine. The treadmill will now enter standby state.
  • Page 15 SETTING UP YOUR TREADMILL - CONTINUED Folding Your Treadmill As shown in step (A), press and hold the red button on the handle with your thumb, at the same time fold the handle in the direction of the arrow until the handle is locked, and release the button during the process of raising your hand; (the other side can do the same). As shown in step (B), fold the Handlebar down and make it parallel to the running platform.

  • Page 16: Moving Your Treadmill

    SETTING UP YOUR TREADMILL - CONTINUED Moving Your Treadmill Using the Rear Handlebar, lift from the base and roll the unit away.

  • Page 17: Safety Stop Key

    SAFETY STOP KEY A safety tether cord is provided with this unit. It is a simple magnetic design that should be used at all times. It is for your safety should you fall or move too far back on the tread-belt.

  • Page 18: About Your Machine

    Downloading the XTERRA+ app will help unlock more fea- tures - such as tracking workouts and sharing data via Goo- gle Fit and Apple Fitness. Simply search for “XTERRA+” in Be sure to follow XTERRA Fitness on your favorite social the app store on your smartphone or tablet, or scan the QR media platforms to view and share the latest fitness videos,...

  • Page 19: Console Screen - Overview

    CONSOLE SCREEN - OVERVIEW Start / Pause Button Message Center Stop Button Speed Buttons Direct Speed Buttons...

  • Page 20: Window Display

    WINDOW DISPLAY Start/Pause/Resume: Short Press the button to start the Display and Key Distribution Specs treadmill, Press the button to pause or resume the treadmill during running. The LED windows displays the following functions: Stop: short press the button to stop the treadmill during Window Display: Time, Speed, Distance, Calories, Heart Rate, running.

  • Page 21: Functions

    (as it was in the original carton). Bluetooth FTMS Connection Open the desired app (Zwift, Kinomap, etc). Click connect treadmill (Treadmill Bluetooth Name: WS200). The app will automatically search and connect the treadmill. If the connection times out, return to the previous round of operation.

  • Page 22: How To Use The Treadmill

    HOW TO USE THE TREADMILL 1. Turn on the power and check whether the machine is working properly. 2. The machine will begin at a speed of 1.0-13.0Km/h (0.6-8.0mph) 3. Clip the safety key into place on the console and to the front of your clothing. 4.

  • Page 23: Using The Xterra+ App

    2. Open the App on your device (phone or tablet) and make sure Bluetooth® is enabled on your device (phone or tablet). 3. In the App click the Bluetooth® icon to search for your XTERRA + equipment. 4. Under the Bluetooth® scan result list, select the machine for connect. When the App and equipment are synced, the Bluetooth®...

  • Page 24: Wearing The Chest Strap

    BLUETOOTH HEART RATE CHEST STRAP* (NOT INCLUDED) 1. Attach the transmitter to the elastic strap using the Note: The transmitter is automatically activated when it detects interlocking key. activity from the user’s heart. Additionally, it automatically 2. Adjust the strap as tightly as possible as long as the strap deactivates when it does not receive any activity.

  • Page 25: Heart Rate Exertion

    HEART RATE EXERTION The old motto, “no pain, no gain”, is a myth that has been The two most popular reasons for, or goals, of exercise are cardiovascular overpowered by the benefits of exercising comfortably. A great deal fitness (training for the heart and lungs) and weight control. The black of this success has been promoted by the use of heart rate monitors.
  • Page 26 HEART RATE - PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot You can get an approximate heart rate level for each rating by of advantages. There are more variables involved in how hard simply adding a zero to each rating.

  • Page 27: Maintenance & Care

    MAINTENANCE & CARE Sanitizing Your XTERRA Fitness Equipment Post-Workout Machine Care • Unupholstered high-contact surfaces (hard plastics) can be 1. Store your machine according to the folding instructions sanitized using a 75% isopropyl alcohol solution and a clean, dry when not in use.

  • Page 28: Belt Adjustments

    MAINTENANCE & CARE - CONTINUED Belt Adjustments If running belt slips while walking on it, users can adjust tension of the running belt by turning screws on rear rollers of both DO NOT OVERTIGHTEN – Over tightening will cause belt sides with 5mm Allen Wrench, which is included in hardware damage and premature bearing failure.

  • Page 29: Deck Lubrication

    1. Ensure that your machine is off, and that the power cord is before first use. unplugged to minimize risk of injury. Do not lubricate with anything other than XTERRA Fitness 2. Reach between the running belt and the top of the treadmill approved lubricant. Your treadmill comes with one tube of base to verify that lubrication is present.

  • Page 30: Belt & Deck Cleaning

    BELT AND DECK CLEANING Belt & Deck Cleaning To clean your treadmill belt: 1. Ensure that your machine is off, and that the power cord is unplugged to minimize risk of injury. 2. Grab one edge of the treadmill belt, and lift slightly to expose the area between the top of the treadmill base and the running belt.

  • Page 31: Exploded View Diagram

    EXPLODED VIEW DIAGRAM...

  • Page 32: Warranty

    Effective August 07 2023- WS200 Treadmill LIMITED WARRANTY XTERRA Fitness Inc. warrants all its home use treadmill parts for a period of time listed below, from the date of retail sale, as deter- mined by a sales receipt or in the absence of a sales receipt, eighteen (18) months from the original factory shipping date. XTERRA Fitness’s responsibilities include providing new or remanufactured parts, at XTERRA Fitness’s option, and technical support to our in-...
  • Page 33 9. Warranties outside of the United States may vary. Please contact your local dealer for details. Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by XTERRA Fitness, Inc. This warranty...
  • Page 34 4. XTERRA Fitness’ obligation under this warranty is limited to repairing or replacing, at XTERRA Fitness’ option, the product through one of our authorized service centers. All repairs must be preauthorized by XTERRA Fitness. If the product is shipped to a service center freight charges to and from the service center will be the customer’s responsibility.

  • Page 35: Troubleshooting

    TROUBLESHOOTING...
  • Page 36 TROUBLESHOOTING - CONTINUED...

  • Page 37: Fcc Warning

    FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 39 3000 Nestle Road Jonesboro, AR 72401 | Phone: 800-258-8511 | Fax: 870-935-7611 www.xterrafitness.com ©2023 All Rights Reserved. WS200 Owner’s Manual...
