WARNING:
! !
IMPORTANT: READ THESE INSTRUCTIONS AND ALL
WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND
ALL OPERATING PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL
INJURY AND/OR PERSONAL PROPERTY DAMAGE.
3.5-Ton SUV
Floor Jack — SD
Owner's Manual
MODEL NO.: 352SUV
AFF 352SUV_INST_4.1.25-v1.1
Advertisement
Table of Contents
Related Manuals for AFF 352SUV
Summary of Contents for AFF 352SUV
- Page 1 MODEL NO.: 352SUV 3.5-Ton SUV Floor Jack — SD Owner’s Manual WARNING: IMPORTANT: READ THESE INSTRUCTIONS AND ALL WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND ALL OPERATING PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL INJURY AND/OR PERSONAL PROPERTY DAMAGE.
-
Page 2: General Description
GENERAL DESCRIPTION PRODUCT DESCRIPTION Hydraulic floor jacks are designed to lift, but not support, one end of a vehicle. Immediately after lifting, loads must be supported by a pair of appropriately rated jack stands. SAFETY INFORMATION Locate the jack in a suitable working area. Inspect the jack before each use. - Page 3 ASSEMBLY IMPORTANT RECEIVING INSTRUCTIONS Visually inspect all components for shipping damage. If any shipping damage is found, notify carrier at once. Shipping damage is NOT covered by warranty. The carrier is responsible for all repair or replacement cost resulting from damage in shipment. 3.1.1 CHECK THE PARTS IN THE CARTON Visually inspect all components for any missing parts or damage.
-
Page 4: Hydraulic System Purging
HYDRAULIC SYSTEM PURGING Open the release valve by turning it two full turns counter-clockwise. Pump the handle a minimum of four full strokes quickly. Close the release valve by turning it clockwise. Pumping the handle with full strokes to check if it can reach the maximum height by eight pumps. If it can’t reach the maximum height by eight pumps, please refer to the following special purging process: Open the release valve by turning counter-clockwise and lower the lifting arm to the minimum height. -
Page 5: Monthly Maintenance
MAINTENANCE MONTHLY MAINTENANCE Periodic lubrication is critical to jacks. Any restriction due to dirt or rust can cause either slow jack movement, or extremely rapid jerks, causing damage to the internal components. To keep the jack well lubricated, carry out the following steps. -
Page 6: Adding Oil
6.3.3 With the jack in the level position, remove the oil filler plug. 6.3.4 The proper oil volume should be the maximum distance from the oil surface level to the top of pump and should be less than 11 mm. If there is not enough oil, please add hydraulic oil according to Section 6.4. 6.3.5 Replace the oil filler plug. -
Page 7: Troubleshooting
6.4.4 Fill with oil through the oil hole and make sure the oil surface level to the top of oil tank is less than 11 mm. 6.4.5 Replace the oil filler plug, purge air from the hydraulic unit as required. Refer to Section 4. 6.4.6 Replace the top plate and tighten the four screws. - Page 8 12 13 15 16 7 14 11 12 13 PARTS LIST: 3.5-TON SUV FLOOR JACK — SD — PARTS BREAKDOWN MOD. NO. 352SUV PART ORDER PART ORDER KIT DESCRIPTION REF. # KIT INCLUDES KIT DESCRIPTION REF. # KIT INCLUDES NUMBER...
- Page 9 DIAGRAM FOR REFERENCE ONLY affjaxx.com...
- Page 10 NOTES affjaxx.com...
-
Page 11: Limited Warranty
PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS. SureWerx USA will repair or replace its SureWerx USA AFF-branded products which fail to give satisfactory service due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed to that specific product. - Page 12 SureWerx, USA Inc., 325 Corporate Drive, Elgin, IL USA 60123 surewerx.com/usa affjaxx.com 800-323-7402 352SUV-INST-0325 affjaxx.com...
