4-Ton Heavy-Duty
Trolley Jack
Owner's Manual
WARNING:
! !
IMPORTANT: READ THESE INSTRUCTIONS AND ALL
WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND
ALL OPERATING PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL
INJURY AND/OR PERSONAL PROPERTY DAMAGE.
MODEL NO.: 400SS
AFF 400SS-INST_4-Ton Heavy-Duty Trolley Jack
Advertisement
Related Manuals for AFF 400SS
Summary of Contents for AFF 400SS
- Page 1 IMPORTANT: READ THESE INSTRUCTIONS AND ALL WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND ALL OPERATING PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL INJURY AND/OR PERSONAL PROPERTY DAMAGE. AFF 400SS-INST_4-Ton Heavy-Duty Trolley Jack...
- Page 2 ® GENERAL DESCRIPTION PRODUCT DESCRIPTION The hydraulic trolley jack is designed to lift, but not support, one end of a vehicle. Immediately after lifting, loads must be supported by a pair of appropriately rated jack stands. Capacity 4 TON Minimum Height 4.25"...
- Page 3 ® ASSEMBLY IMPORTANT RECEIVING INSTRUCTIONS Visually inspect all components for shipping damage. If any shipping damage is found, notify carrier at once. Shipping damage is NOT covered by warranty. The carrier is responsible for all repair or replacement cost resulting from damage in shipment.
- Page 4 ® 3.2.3 The handle socket is pressed down and supported by a nylon supporting block in the package during transportation. Before assembling, please take out the nylon supporting block. 3.2.4 Undo the screw (B) in the handle socket, until it no longer protrudes into the handle socket. 3.2.5 Insert the pump handle into the handle socket hole completely.
- Page 5 ® HYDRAULIC SYSTEM PURGING Open the release valve by turning it two full turns counterclockwise. Pump the handle a minimum four full strokes quickly. Close the release valve by turning it clockwise. Pump the handle with full strokes to check if it can reach the maximum height by seven pumps. If it can’t reach the maximum height by seven pumps, please refer to the following special purging process: Open the release valve by turning counter-clockwise and lower the lifting arm to the minimum height.
- Page 6 ® MAINTENANCE MONTHLY MAINTENANCE Periodic lubrication is critical to jacks since they support heavy loads. Any restriction due to dirt or rust can cause either slow jack movement or extremely rapid jerks, causing damage to the internal components. To keep the jack well lubricated, carry out the following steps.
- Page 7 ® 6.3.3 With the jack in the level position, remove the oil filler plug. 6.3.4 The proper oil volume should be no more than 13 mm from the top of the oil tank to the oil surface. If it is too low, please add high-quality hydraulic oil according to Section 6.4.
- Page 8 ® 6.4.4 Fill with oil through the oil hole and make sure the oil surface level to the top of oil tank should be less than 11 mm. Replace the oil filler plug and purge air from the hydraulic unit as required. Refer to Section 4. 6.4.5 6.4.6 Replace the top plate, ensuring the four retaining screws line up as shown in the following picture,...
- Page 9 ® affjaxx.com...
- Page 10 ® affjaxx.com...
- Page 11 ® PARTS LIST: 4-TON HEAVY-DUTY TROLLEY JACK — PARTS BREAKDOWN — Prod. No. 400SS PART KIT DESCRIPTION REF. # KIT INCLUDES NUMBER 400SS-2-1 Handle Handle 400SS-2-4 Handle Protection Handle Protection 400SS-2-35 Saddle Complete Saddle Complete Bolt Bolt Saddle Pad Saddle Pad...
- Page 12 PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS. SureWerx USA will repair or replace its SureWerx USA “AFF” branded products which fail to give satisfactory service due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed to that specific product.
