CONTENTS:
Page 1
Specifications
Page 2
Page 3-4
Page 4-5
Page 5
Page 6
Page 7
Page 8
Capacity
Low Height
High Height
Screw Adjustment
Adapters
Ram Travel
Handle Length
Overall Length
Overall Width
Weight
SPECIFICATIONS
22 Ton
8.85"
17.50" (w/o adjustment)
4.10"
.8"/2.4"/3.9"
4.70"
49.84"
69.49"
13.46"
86 lbs
Page 1
22 Ton Air/Hydraulic Truck Axle Jack
OWNER'S MANUAL
Model 3322
Advertisement
Table of Contents
Related Manuals for AFF 3322
Summary of Contents for AFF 3322
- Page 1 Model 3322 22 Ton Air/Hydraulic Truck Axle Jack OWNER'S MANUAL CONTENTS: Page 1 Specifications Page 2 Warning Information Page 3-4 Assembly Page 4-5 Operating Instructions Page 5 Preventative Maintenance and Troubleshooting Page 6 Diagram Page 7 Replacement Parts Page 8...
- Page 2 WARNING: Read all instructions and safety warnings before operating this equipment. Failure to follow the instructions and safety warnings may result in personal injury or property damage. WARNING The use of portable automotive lifting devices is subject to certain hazards that can not be prevented by mechanical means, but only by the use of care and common sense.
- Page 3 ASSEMBLY PLEASE REFER TO THE EXPLODED VIEW DRAWINGS ON PAGE 6 IN ORDER TO IDENTIFY PARTS 1. Feed the orange hose (#63) and black hose (#64) coming out of the bottom of the handle connector (#79) thru the handle-2 (#52) while at the same time lining up the hole in the handle-1 (#52) with the hole in the handle connector (#55.) Secure them together with the screw (#54.) Thread two nuts (#53) all the way on the bottom of the tie rod (#50.) Thread the bottom of the tie rod all the way inside the slotted pin (#49.) Now tighten one nut (#53) down on top of the slotted pin...
- Page 4 WARNING: Ensure that you read and understand all safety instructions and warnings before use. OPERATING INSTRUCTIONS Become familiar with the identification and function of the jack components: a. The ram (#32) is the shaft that comes out of the jack when you rotate the air lever to the left.
- Page 5 Leaking hydraulic ram Kinked or damaged air line 3. Air passes thru jack but air motor does not Insufficient air pressure operate Torn or damaged air air hose 4. Unit still does not operate Contact an AFF authorized repair depot Page 5...
- Page 6 Page 6...
- Page 7 Check out an excellent selection of garage accessories on our website.
