AFF 202HD Owner's Manual

2-ton floor jack - heavy duty
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2-Ton Floor Jack —
Heavy Duty
Owner's Manual
WARNING:
! !
IMPORTANT: READ THESE INSTRUCTIONS AND ALL
WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND
ALL OPERATING PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL
INJURY AND/OR PERSONAL PROPERTY DAMAGE.
MODEL NO.: 202HD
AFF 202HD-INST-3.24.23-FA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 202HD and is the answer not in the manual?

Questions and answers

Related Manuals for AFF 202HD

Summary of Contents for AFF 202HD

  • Page 1 MODEL NO.: 202HD 2-Ton Floor Jack — Heavy Duty Owner’s Manual WARNING: IMPORTANT: READ THESE INSTRUCTIONS AND ALL WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND ALL OPERATING PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL INJURY AND/OR PERSONAL PROPERTY DAMAGE.

  • Page 2: General Description

    GENERAL DESCRIPTION PRODUCT DESCRIPTION The hydraulic trolley jack is designed to lift, but not support, one end of a vehicle. Immediately after lifting, loads must be supported by a pair of appropriately rated jack stands. Capacity 2 TON Minimum Height 3"...

  • Page 3: Important Receiving Instructions

    ASSEMBLY IMPORTANT RECEIVING INSTRUCTIONS Visually inspect all components for shipping damage. If any shipping damage is found, notify the carrier at once. Shipping damage is NOT covered by warranty. The carrier is responsible for all repair or replacement costs resulting from damage in shipment.
  • Page 4 3.2.3 The handle socket is pressed down and supported by nylon supporting block in the package during transportation. Before assembling, please take out the nylon supporting block. 3.2.4 Undo the screw (B) in the handle socket, until it no longer protrudes into the handle socket 3.2.5 Insert the pump handle into the handle socket hole completely.

  • Page 5: Hydraulic System Purging

    HYDRAULIC SYSTEM PURGING Open the release valve by turning it two full turns counterclockwise. Pump the handle a minimum four full strokes quickly. Close the release valve by turning it clockwise. Pump the handle with full strokes to check if it can reach the maximum height by seven pumps. If it can’t reach the maximum height by seven pumps, please refer to the following special purging process: Open the release valve by turning counterclockwise and lower the lifting arm to the minimum height.

  • Page 6: Monthly Maintenance

    MAINTENANCE MONTHLY MAINTENANCE Periodic lubrication is critical to jacks since they support heavy loads. Any restriction due to dirt or rust can cause either slow jack movement or extremely rapid jerks, causing damage to the internal components. To keep the jack well lubricated, carry out the following steps.

  • Page 7: Troubleshooting

    6.3.3 With the jack in the level position, remove the oil filler plug. 6.3.4 The proper oil volume should be no more than 13 mm from the top of the oil tank to the oil surface. If it is too low, please add high-quality hydraulic oil according to Section 6.4.
  • Page 8 affjaxx.com...
  • Page 9 affjaxx.com...
  • Page 10 PARTS LIST: 2-TON FLOOR JACK — HEAVY DUTY — PARTS BREAKDOWN — Prod. No. 202HD PART KIT DESCRIPTION REF. # KIT INCLUDES PART KIT DESCRIPTION REF. # KIT INCLUDES NUMBER NUMBER 202HD-1 Upper Handle Handle 202HD-26 Wheel Wheel Lower Handle...

  • Page 12: Limited Warranty

    PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS. SureWerx USA will repair or replace its SureWerx USA “AFF” branded products which fail to give satisfactory service due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed to that specific product.
