AFF 202LCJ Owner's Manual

2-ton long chassis floor jack — super duty
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING:
! !
IMPORTANT: READ THESE INSTRUCTIONS AND ALL
WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND
ALL OPERATING PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL
INJURY AND/OR PERSONAL PROPERTY DAMAGE.
2-Ton Long Chassis
Floor Jack —
Super Duty
Owner's Manual
MODEL NO.: 202LCJ
AFF 202LCJ-INST-3.23.23-FA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 202LCJ and is the answer not in the manual?

Questions and answers

Related Manuals for AFF 202LCJ

Summary of Contents for AFF 202LCJ

  • Page 1 MODEL NO.: 202LCJ 2-Ton Long Chassis Floor Jack — Super Duty Owner’s Manual WARNING: IMPORTANT: READ THESE INSTRUCTIONS AND ALL WARNINGS PRIOR TO USING THIS EQUIPMENT. UNDERSTAND ALL OPERATING PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD CAUSE AN ACCIDENT RESULTING IN SERIOUS OR FATAL INJURY AND/OR PERSONAL PROPERTY DAMAGE.

  • Page 2: General Description

    GENERAL DESCRIPTION PRODUCT DESCRIPTION Hydraulic floor jacks are designed to lift, but not support, one end of a vehicle. Immediately after lifting, loads must be supported by a pair of appropriately rated jack stands. SAFETY INFORMATION Locate the jack in a suitable working area. Inspect the jack before each use.

  • Page 3: Important Receiving Instructions

    ASSEMBLY IMPORTANT RECEIVING INSTRUCTIONS Visually inspect all components for shipping damage. If any shipping damage is found, notify carrier at once. Shipping damage is NOT covered by warranty. The carrier is responsible for all repair or replacement cost resulting from damage in shipment. 3.1.1 CHECK THE PARTS IN THE CARTON Visually inspect all components for any missing parts or damage.

  • Page 4: Hydraulic System Purging

    3.2.3 Undo the screw (B) in the handle socket, until it no longer protrudes into the handle socket. 3.2.4 Insert the pump handle into the handle socket hole completely. 3.2.5 Ensure that the handle is completely inserted into the socket, then tighten the handle socket screw (B). Please make sure that the handle can be turned smoothly HYDRAULIC SYSTEM PURGING Open the release valve by turning it two full turns counter-clockwise.

  • Page 5: Raising A Vehicle

    OPERATING INSTRUCTIONS Before use ensure you have read and understood Section 2, Safety Information. IMPORTANT Before use, the operator is to visually inspect the jack for cracked welds, damaged or missing parts or hydraulic leak. RAISING A VEHICLE 5.1.1 Ensure that the jack and the vehicle are on a hard, level surface. 5.1.2 Always ensure that the vehicle handbrake is engaged and that the vehicle wheels are chocked.

  • Page 6: Monthly Maintenance

    MAINTENANCE MONTHLY MAINTENANCE Periodic lubrication is critical to jacks. Any restriction due to dirt or rust can cause either slow jack movement, or extremely rapid jerks, causing damage to the internal components. To keep the jack well lubricated, carry out the following steps. 6.1.1 Lubricate the linkages the saddle and pump mechanism with light oil.

  • Page 7: Adding Oil

    6.3.3 With the jack in the level position, remove the oil filler plug. 6.3.4 The proper oil volume should be the maximum distance from the oil surface level to the top of pump and should be less than 11 mm. If there is not enough oil, please add hydraulic oil according to Section 6.4. 6.3.5 Replace the oil filler plug.

  • Page 8: Troubleshooting

    6.4.5 Replace the oil filler plug, purge air from the hydraulic unit as required. Refer to Section 4. 6.4.6 Replace the top plate and tighten the four screws. TROUBLESHOOTING PROBLEM CAUSE REMEDY Jack will not lift to full height 1. Oil level low 1.
  • Page 9 PARTS LIST: 2-TON LONG CHASSIS FLOOR JACK — PARTS BREAKDOWN — Prod. No. 202LCJ PART KIT DESCRIPTION REF. # KIT INCLUDES PART KIT DESCRIPTION REF. # KIT INCLUDES NUMBER NUMBER 202LCJ-24 Handle Upper Handle 202LCJ-27 Oiler Bowl Oiler Bowl Lower Handle...
  • Page 10 affjaxx.com...
  • Page 11 PARTS LIST: 2-TON LONG CHASSIS FLOOR JACK — PARTS BREAKDOWN — Prod. No. 202LCJ PART KIT DESCRIPTION REQ. PART KIT DESCRIPTION REQ. PART KIT DESCRIPTION REQ. NUMBER NUMBER NUMBER Tank Nut Washer Screw O-Ring 36 x 3.5 Washer Ball 10...

  • Page 12: Limited Warranty

    PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS. SureWerx USA will repair or replace its SureWerx USA “AFF” branded products which fail to give satisfactory service due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed to that specific product.
