HP SureStore DAT
Installation Guide

Step 5: Install the Drive

Note Write the model name, product number, serial number, and SCSI ID of
your drive in the front of this guide for future reference. The model name
is on the front of the drive and the product and serial numbers are on a
label on the bottom of the drive.
1 Attach the power cable extension to the rear of the tape drive, as shown in
figure 1.10.
Figure 1.10 Attaching the power cable extension
2 Slide the tape drive into the open bay, aligning the tray or rails with the
slots in the bay, as shown in figure 1.11.
If your computer does not use mounting hardware, check that the holes in
the chassis are aligned with the holes in the side of the tape drive.
Do not secure the drive with screws at this point because you may have to
move the drive to get the cables into place.
1-16
