Summary of Contents for EcoFlow WAVE 3
- Page 1 USER MANUAL V1.0 EcoFlow WAVE 3 Add-on Battery For more details, check the latest user manuals or related documents. https://www.ecoflow.com/support/download...
- Page 2 About This Manual Overview Safety Instructions Disclaimer Safety Instructions Appearance Get Started Power On/Off Use USB Output Connect to WAVE 3 Charge the Add-on Battery Storage and Maintenance Storage Cleaning Battery Health LED Indicators Main Status LEDs USB Status LED...
- Page 3 1024Wh. It is designed to pets. If the product is to be used near children, power the EcoFlow WAVE 3 portable air conditioner they should be closely supervised. (hereinafter referred to as "EcoFlow WAVE 3", "WAVE Keep the product away from fumes, smoke, 3", or "the air conditioner"), providing extended...
- Page 4 If the product gets wet, stop using it immediately and refrain from further operation or powering it on. Place the product in a secure, waterproof, and well-ventilated area, then contact EcoFlow Customer Service for assistance. If the product falls into water, place it in a secure, waterproof, and well-ventilated area, and keep it away from contact until it is completely dry.
- Page 5 Power On/Off Press and hold the power button for 1 second until the main indicator lights up or turns off. Once the battery is connected to WAVE 3, turning on or off either one will activate or deactivate the other accordingly.
- Page 6 Connect to WAVE 3 Assemble the Battery 1. Align WAVE 3 with the markings on the top of the battery and place it down. 2. Push it forward until you hear a "click" sound to complete the assembly. 3. Plug in the provided EcoFlow WAVE 3 Add-on Battery Cable.
- Page 7 Disassemble the Battery 1. Press and hold the power button to turn off the battery, then unplug the EcoFlow WAVE 3 Add-on Battery Cable. 2. Press the unlock button and slide WAVE 3 backward to remove it. ❸ ❶ ❷...
- Page 8 From a Wall Outlet 1. Connect the battery to the XT150 port of WAVE 3 (or a compatible EcoFlow power station) using the provided EcoFlow WAVE 3 Add-on Battery Cable. 2. Then connect WAVE 3 to an AC wall outlet.
- Page 9 From EcoFlow Alternator Charger EcoFlow 500W Alternator Charger Connect the XT60 Output Cable from the Portable Power Station Port of the charger to the solar charging port (XT60i) of the battery. Once connected, you can charge the add-on battery with the car battery (requires setup on the Alternator Charger app device homepage).
- Page 10 Maintenance and Care Storage • Store the batterye in an environment between -10°C and 45°C, with a recommended range of approximately 0°C to 30°C to maintain battery health. • Keep the product in a dry, cool, well-ventilated area that is secure and reduces the risk of falling.
- Page 11 Low Temperature Move the battery to a warmer location to ensure usage Warning within the appropriate temperature range. USB Port Please contact EcoFlow Customer Service. Malfunction Permanent Failure Please contact EcoFlow Customer Service. USB Status LED The USB output ports are enabled.
- Page 12 1000W Max Solar Input 11-60V⎓13A Max, 400W Max Car Input 12V/24V⎓8A Max, 200W Max Battery Runtime 2-8 hours EcoFlow WAVE 3 Add-on Battery Cable Battery Specifications Battery Cell Material LFP (LiFePO Cycle Life 80%+ capacity after 4000 cycles IP Rating...
- Page 13 EU(RoHS), (EU) 2015/863(RoHS). The full text of the EU declaration :of conformity is available at the following Internet address Deutsch: Hiermit erklart EcoFlow Inc., dass der typ des Akku der Hereby, EcoFlow Inc. declares that the battery is in compliance with Richtlinie 2014/30/EU, 2011/65/EU(RoHS), (EU) 2015/863(RoHs) .Regulation (EU) 2023/1542 of the European Parliament...
- Page 14 产品中有害物质的名称及含量 有害物质 部件名称 多溴二苯醚 )铅)Pb )汞)Hg )镉)Cd ))六价铬)Cr)VI )多溴联苯)PBB ))PBDE 塑料结构件 ○ ○ ○ ○ ○ ○ 金属结构件 ○ ○ ○ ○ ○ ○ 电池 ○ ○ ○ ○ ○ ○ ╳ ○ ○ ○ ○ ○ 电路板组件 ╳ ○ ○...
- Page 15 © 2025 EcoFlow Inc. All rights reserved.
