About This Manual
This user manual is applicable to the following products: RIVER 3 Plus Smart
Extra Battery EB300 (286Wh) and RIVER 3 Plus Smart Extra Battery EB600
(572Wh).
The terms "RIVER 3 Plus Smart Extra Battery EB300 (286Wh)", "RIVER 3
Plus Smart Extra Battery EB600 (572Wh)" and "RIVER 3 Plus" in this
manual shall refer to EcoFlow RIVER series products.
Please note that this manual may be updated without prior notice. If you are
reading this manual in PDF format, please note that you can access it online
at
EcoFlow Support
for a better experience and the latest updates.
The illustrations in this manual use RIVER 3 Plus Smart Extra Battery EB300
(286Wh) as examples and references. Please refer to the actual product
received.
The availability of certain accessories and features described in this manual
may vary depending on your country or region.
Overview
The RIVER 3 Plus Smart Extra Battery EB300 (286Wh) and RIVER 3 Plus Smart
Extra Battery EB600 (572Wh) (hereinafter referred to as "the extra battery,"
"the battery," or "the product") are LiFePO4 batteries designed to wirelessly
connect to the RIVER 3 Plus portable power station. This connection expands
the power station's battery capacity, providing extended power support.
Appearance
After-sales
Community
Policy

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RIVER 3 Plus EB300 and is the answer not in the manual?

Questions and answers

Summary of Contents for EcoFlow RIVER 3 Plus EB300

  • Page 1: Table Of Contents

    The terms "RIVER 3 Plus Smart Extra Battery EB300 (286Wh)", "RIVER 3 Disclaimer Plus Smart Extra Battery EB600 (572Wh)" and "RIVER 3 Plus" in this manual shall refer to EcoFlow RIVER series products. Safety Instructions Please note that this manual may be updated without prior notice. If you are...
  • Page 2: Led Indicators

    Main Power Button Status LED USB-C Input/Output Port Extra Battery Port Unlock Button LED Indicators Main Power LED...
  • Page 3 Status Description The battery is powered off. Breathing White The battery is powered on and functioning normally. Flashing White The battery is performing a firmware update. Status LED The status LED displays an outwards running pattern when the extra battery is powering on.
  • Page 4 When the status LED light is solid, the number of LEDs that are lit up indicate the current battery level. When a part of the status LED is blinking, it indicates the battery is charging. When the entire status LED is blinking, it indicates that an error has occurred.
  • Page 5: Get Started

    Get Started Standalone Use Power On/Off Power On: Short press the main power button Power Off: Long press the main power button for 3 seconds Power Your Appliances Connect your devices directly to the USB-C input/output port on the extra battery.
  • Page 6: Use With River 3 Plus

    Charge Your Extra Battery Connect the USB-C input/output port of the extra battery to a power source for charging. Use with RIVER 3 Plus The extra battery can expand the power station's battery capacity by storing more power. It also functions as a backup power source for loads when the power station's battery is low.
  • Page 7 icon is displayed on the screen of the power station. Notice: 1. The RIVER 3 Plus portable power station supports connecting up to one RIVER 3 Plus Smart Extra Battery to expand capacity. 2. Ensure to align the groove of the power station with the protruding structure on the extra battery to avoid loose connection.
  • Page 8 Power On/Off After connecting the extra battery to the power station, you can use the main power button on either device to control the power on/off status of both products simultaneously. Power On: Short press once Power Off: Long press for 3 seconds Turn On/Off Power Station's Screen: Short press once after power-on Power Your Appliances...
  • Page 9 Charge Your Extra Battery After connecting the extra battery to the power station, you can connect the input ports on either device to a power source to charge your extra battery. Tip: After the extra battery is connected to the power station, if there is a significant difference in their battery levels, the device with the lower charge will be prioritized for charging during power input, while the device with the higher charge will prioritize discharging during power...
  • Page 10: Storage And Maintenance

    EcoFlow is not liable for any loss caused by the user's failure to use the product in compliance with the product document. In compliance with laws and regulations, EcoFlow reserves the right to the final interpretation of this document and all documents related to the product.
  • Page 11 6. Do not insert wires or other metal objects into the product to prevent short circuits. 7. Do not use any unofficial or unrecommended components or accessories. For any replacements, please contact EcoFlow for further assistance. 8. Do not operate this product with a damaged cord or plug, or a damaged output cable.
  • Page 12: Regulatory Compliance

    4. If the product catches fire, we recommend that you use the fire extinguishers in the following order: water or water mist, sand, fire blanket, dry powder, and finally a carbon dioxide fire extinguisher. Recycling and Disposal 1. The product with severe damage, malfunction, or depleted battery life should be properly disposed of or recycled.
  • Page 13: Appendix

    Hereby, EcoFlow Inc. declares that the equipment type battery is in compliance with Directives 2014/35/EU, 2014/30/EU, 2011/65/EU(RoHS), (EU) 2015/863(RoHS). The full text of the EU declaration of conformity is available at the following Internet address: http://www.ecoflow.com/eu/eu-compliance Battery Directive Hereby, EcoFlow Inc. declares that the equipment type battery is in compliance with Regulation (EU) 2023/1542 of the European Parliament.
  • Page 14: Specifications

    1. EcoFlow RIVER 3 Plus Smart Extra Battery ×1 2. Manuals & Warranty Card ×1 Tip: If any item is damaged or missing, contact EcoFlow Customer Service for assistance. Specifications General EB300 (286Wh): EF-RV-E01-1 Model EB600 (572Wh): EF-RV-E02-1 EB300 (286Wh): Approx.
  • Page 15: Extra Battery Eb600 (572Wh)

    Type Low Voltage Protection, Overcurrent Protection Environment Temperature Optimal Operating 20°C-30°C (68°F-86°F) Temperature Charge 0°C-45°C (32°F-113°F) Temperature Discharge −10°C to 45°C (14°F-113°F) Temperature Storage −10°C to 45°C (optimal: 20°C-30°C) Temperature 14°F-113°F (optimal: 68°F-86°F) Copyright © 2024 EcoFlow. All Rights Reserved.
