About This Manual
FAQ
EcoFlow App
About This Manual
This manual contains an introduction to this power station, and details on its
operation, management, and maintenance. Please note that this manual may
be updated without prior notice.
The availability of certain accessories and features described in this manual
may vary depending on your country or region.
All images displayed in this manual are for demonstrative purposes only.
The type and appearance of the AC power cord (pluggable/embedded) may
vary depending on local regulations. Please refer to the actual product
received. The following examples are based on the embedded AC power
cord version.
If you are reading this manual in PDF format, please note that you can
access it online at
EcoFlow Support
updates.
After-sales
Community
Policy
for a better experience and the latest

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAVE 3 and is the answer not in the manual?

Questions and answers

Related Manuals for EcoFlow WAVE 3

Summary of Contents for EcoFlow WAVE 3

  • Page 1: Table Of Contents

    All images displayed in this manual are for demonstrative purposes only. Button Operation The type and appearance of the AC power cord (pluggable/embedded) may Control via EcoFlow App vary depending on local regulations. Please refer to the actual product received. The following examples are based on the embedded AC power Storage and Maintenance cord version.

  • Page 2: Tutorial Video

    Tutorial Video Overview EcoFlow WAVE 3 (hereinafter referred to as "WAVE 3" or "the product") is a portable air conditioner that allows you to easily switch between Automatic, Cooling, Heating, Fan, and Dehumidification functions with the control panel. Connect to the EcoFlow app for remote control and access to features such as Timer and Pet Mode.
  • Page 3 1 Display screen & control panel Adjusts primary settings and displays operating details. 2 Front air outlet Face this side towards the interior (install the exhaust kit for outdoor use). Lift the fan blade during use, and close it during storage to prevent dust buildup. 3 Ambient light Displays operating status.

  • Page 4: Control Panel

    The type and appearance of the AC power cord (pluggable/embedded) may vary depending on local regulations. 9 Extra battery port (XT150) Connects the product to the WAVE 3 Add-on Battery or other compatible EcoFlow products for power. 10 Rear air inlet & filter Install the exhaust kit for indoor use.

  • Page 5: Display Screen

    Wi-Fi connection successful. Flashing: Wi-Fi connected to the power station is not available. Off: Wi-Fi disconnected. ※ Please refer to the "Control via EcoFlow App" chapter for more details. Bluetooth status Bluetooth connection successful. Flashing: Bluetooth pairing in progress. Off: ①...
  • Page 6 Pet care mode is activated in the EcoFlow app. Timer At least one pending timer is configured in the EcoFlow app. Automatic / Cooling / Heating / Fan / Dehumidification function The current function is activated. Flashing: The current function is selected and loading. Press the function button again to switch to the next one.

  • Page 7: Ambient Light

    Breathing orange Heating status Breathing white Fan status Breathing purple Dehumidification status Solid red Error alarm. An error has occurred. Check the EcoFlow in-app instructions for troubleshooting. Carousel white Firmware update Get Started Components Assembly Exhaust Duct & Adapter Cover Before using this product, ensure that the exhaust ducts and adapter covers are properly assembled to the product;...
  • Page 8 The diagrams below show the standard air circulation method. In limited spaces, the air inlet components can be temporarily removed to allow continued use of the air conditioner. Please note that this may impact operating performance. Outdoor Scenarios Indoor Scenarios For optimal performance, use the product in a space of 11–17 m²...
  • Page 9 1. Install the adapter covers Align them with the edges of the air inlet and outlet, insert the clasps, and push down until you hear a ''click'' sound. 2. Attach the exhaust ducts Align the markings on the ducts with the adapter covers, snap them into place, and rotate clockwise.
  • Page 10 1. Install the adapter covers Align them with the edges of the air inlet and outlet, insert the clasps, and push down until you hear a ''click'' sound. 2. Attach the exhaust ducts Align the markings on the ducts with the adapter covers, snap them into place, and rotate clockwise.
  • Page 11 1. Trace the shapes of the exhaust ducts onto the foam board. 2. Cut along the traced lines. 3. Insert the ducts into the board. 4. Place the board in the window and seal the edges with adhesive tape. Drain Pipe The product generates condensate during operation.

  • Page 12: Power Connection

    3. Wrap the cable around the winder. Power Connection The WAVE 3 features an AC port and an XT150 DC Extra Battery port. Slide the cover open, plug in the power cord, then press and hold the Power button to start.
  • Page 13 AC power cord for power supply. AC power cord types (pluggable/embedded) may vary based on local regulations. Please refer to the actual product. Via the Extra Battery Port The product is compatible with multiple EcoFlow power stations and extra batteries.

  • Page 14: Button Operation

    EcoFlow Extra Battery Cable, EcoFlow Smart EcoFlow DELTA Pro 3 Generator Adapter Compatible models and accessories may be updated. Please check with the official EcoFlow Customer Service for the latest information. Button Operation Temperature / Humidity control button (+/-) Press once: Set the target temperature or humidity.

  • Page 15: Control Via Ecoflow App

    Control, monitor and customize your product from afar with the EcoFlow App. Monitor: Remote monitoring of current battery level, power usage, and charging status of the extra battery connected to EcoFlow WAVE 3; remote monitoring of the water tank level and full water level notifications. Control: Remote control to turn on the product (when on standby) and switch functions or modes.

  • Page 16: Storage And Maintenance

    To bind a new EcoFlow device 1. Visit the EcoFlow app and log in to your EcoFlow account. 2. Tap the Add Device button or icon in the top right corner to search for new EcoFlow devices.

  • Page 17: Safety Instructions And Compliances

    EcoFlow is not liable for any loss caused by the user's failure to use the product in compliance with the product document. In compliance with laws and regulations, EcoFlow reserves the right to the final interpretation of this document and all documents related to the product.

  • Page 18: In Case Of Emergency

    If they need to be replaced, please purchase them through the official EcoFlow distribution channels. 19. Please keep the product out of the reach of pets. Children should not operate this product without supervision. 20. Electromagnetic fields created by this product may affect the normal functioning of medical implants or personal medical devices, such as pacemakers, cochlear implants, hearing aids, defibrillators and so on.
  • Page 19 FCC Compliance Statement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 20: Technical Specifications

    The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by EcoFlow Inc. is under license. Other trademarks and trade names are those of their respective owners. Hereby, EcoFlow Inc. declares that the radio equipment type portable power station is in compliance with Directive 2014/53/EU.

  • Page 21: What's In The Box

    Maximum Cooling/Heating Power 700W Input Specifications AC Input 100-240V~50/60Hz, 820W Max DC Input (Extra Bttery Port) 700W Max Other Specifications Operating Altitude < 2000 m (6562 ft) Overflow Shutdown Function Supported IP Rating IPX4 Noise Level 44-58 dB Permissible Pressure Range (High 2.24MPa/0.74MPa Pressure/Low Pressure) Operating Temperature...
  • Page 22 5. Drain pipe 6. Winder 7. Manuals and Warranty Card If any item is damaged or missing, contact EcoFlow Customer Service for assistance. The type and appearance of the AC power cord (pluggable or embedded) may vary depending on local regulations. Please refer to the actual product for details.
