Leg
D
Side rail
C
Put on
A
Head board
ASSEMBLY INSTRUCTIONS
BP700THW/ TFW/ TRW
BP800THB/ TFB/ TRB
TWIN PANEL BED
Head board
A
Slat
E
Leg
D
Lock washer
I
G
Flat washer
Bolt
Allen key
Screw
J
Side rail
C
H
NO.
A
B
C
D
F
E
F
G
H
I
J
Foot board
B
QTY.
DESCRIPTION
Head board
Foot board
Side rail
Leg
Slat
Allen key
Bolt (5/16"x38mm)
Lock washer (5/16")
Flat washer (5/16")
Screw (25mm)
1
1
2
2
4
1
4
4
4
8
